Computer Vision YOLO Scaling Strategy — วิธี
YOLO Object Detection
YOLO You Only Look Once Real-time Object Detection ตรวจจับวัตถุครั้งเดียว YOLOv8 Ultralytics Detection Segmentation Pose Estimation CCTV Autonomous Driving
เนื้อหาเกี่ยวข้อง — ดูเพิ่มเติมเรื่อง Apache Kafka Streams Observability Stack — คู่มือฉบับสมบูรณ์ 2026
Scale ได้หลายระดับ Model Nano Small Medium Large GPU TensorRT Kubernetes Batch Processing Edge Device Jetson Raspberry Pi
เนื้อหาเกี่ยวข้อง — บทความที่เกี่ยวข้อง: Certificate Manager DevSecOps Integration
| Model | Parameters | mAP | Speed (ms) | เหมาะกับ |
|---|---|---|---|---|
| YOLOv8n | 3.2M | 37.3 | 1.2 | Edge / Mobile |
| YOLOv8s | 11.2M | 44.9 | 2.1 | Edge / Light Server |
| YOLOv8m | 25.9M | 50.2 | 4.7 | Server |
| YOLOv8l | 43.7M | 52.9 | 7.1 | Server GPU |
| YOLOv8x | 68.2M | 53.9 | 10.8 | High Accuracy |
YOLO Inference Pipeline
# yolo_pipeline.py — YOLO Inference Pipeline
# pip install ultralytics opencv-python
from ultralytics import YOLO
import cv2
import numpy as np
from dataclasses import dataclass
from typing import List, Tuple
import time
@dataclass
class Detection:
class_name: str
confidence: float
bbox: Tuple[int, int, int, int] # x1, y1, x2, y2
class YOLOPipeline:
"""YOLO Inference Pipeline with Scaling Options"""
def __init__(self, model_size: str = "n", device: str = "cpu"):
self.model_name = f"yolov8{model_size}.pt"
self.device = device
# self.model = YOLO(self.model_name)
# self.model.to(device)
print(f" Loaded {self.model_name} on {device}")
def detect(self, image_path: str, conf: float = 0.25) -> List[Detection]:
"""ตรวจจับวัตถุในภาพ"""
# results = self.model(image_path, conf=conf, device=self.device)
# detections = []
# for result in results:
# for box in result.boxes:
# detections.append(Detection(
# class_name=result.names[int(box.cls)],
# confidence=float(box.conf),
# bbox=tuple(map(int, box.xyxy[0])),
# ))
# return detections
print(f" Detecting objects in {image_path}")
return []
def batch_detect(self, image_paths: List[str],
batch_size: int = 8) -> dict:
"""Batch Detection — ประมวลผลหลายภาพพร้อมกัน"""
results = {}
for i in range(0, len(image_paths), batch_size):
batch = image_paths[i:i+batch_size]
# batch_results = self.model(batch, device=self.device)
for path in batch:
results[path] = self.detect(path)
return results
def export_tensorrt(self):
"""Export เป็น TensorRT Engine"""
# self.model.export(format="engine", half=True, device=0)
print(f" Exported {self.model_name} to TensorRT FP16")
def export_onnx(self):
"""Export เป็น ONNX"""
# self.model.export(format="onnx", opset=12, simplify=True)
print(f" Exported {self.model_name} to ONNX")
# Scaling Options
scaling_options = {
"Model Size": {
"description": "เลือกขนาด Model ตามความต้องการ",
"options": {
"Nano (n)": "Edge Device, Mobile, Raspberry Pi",
"Small (s)": "Edge Server, Jetson, Light Workload",
"Medium (m)": "Server, General Purpose",
"Large (l)": "GPU Server, High Accuracy",
"XLarge (x)": "Multi-GPU, Maximum Accuracy",
},
},
"Export Format": {
"description": "Export Model เป็นรูปแบบที่เร็วขึ้น",
"options": {
"TensorRT": "NVIDIA GPU เร็วขึ้น 2-5x (FP16/INT8)",
"ONNX": "Cross-platform CPU/GPU",
"OpenVINO": "Intel CPU/GPU เร็วขึ้น 2-3x",
"CoreML": "Apple Silicon M1/M2/M3",
"TFLite": "Mobile Android/iOS Edge TPU",
},
},
"Batch Processing": {
"description": "ประมวลผลหลายภาพพร้อมกัน",
"options": {
"Batch Size 8": "GPU Memory 4-8 GB",
"Batch Size 16": "GPU Memory 8-16 GB",
"Batch Size 32": "GPU Memory 16-24 GB",
},
},
}
print("YOLO Scaling Options:")
for category, info in scaling_options.items():
print(f"\n [{category}]")
print(f" {info['description']}")
for opt, desc in info["options"].items():
print(f" {opt}: {desc}")Kubernetes Scaling
# k8s_yolo.py — Kubernetes Deployment for YOLO
# apiVersion: apps/v1
# kind: Deployment
# metadata:
# name: yolo-inference
# spec:
# replicas: 3
# selector:
# matchLabels:
# app: yolo-inference
# template:
# metadata:
# labels:
# app: yolo-inference
# spec:
# containers:
# - name: yolo
# image: ultralytics/yolov8:latest-gpu
# ports:
# - containerPort: 8080
# resources:
# limits:
# nvidia.com/gpu: 1
# memory: 8Gi
# cpu: 4
# requests:
# memory: 4Gi
# cpu: 2
# env:
# - name: MODEL_SIZE
# value: "m"
# - name: DEVICE
# value: "cuda"
# - name: BATCH_SIZE
# value: "8"
# apiVersion: autoscaling/v2
# kind: HorizontalPodAutoscaler
# metadata:
# name: yolo-hpa
# spec:
# scaleTargetRef:
# apiVersion: apps/v1
# kind: Deployment
# name: yolo-inference
# minReplicas: 2
# maxReplicas: 10
# metrics:
# - type: Resource
# resource:
# name: cpu
# target:
# type: Utilization
# averageUtilization: 70
# - type: Pods
# pods:
# metric:
# name: inference_queue_length
# target:
# type: AverageValue
# averageValue: "5"
from dataclasses import dataclass
from typing import List
@dataclass
class ScalingTier:
name: str
replicas: str
gpu: str
model: str
throughput: str
cost: str
class YOLOScaling:
"""YOLO Scaling Strategy"""
def __init__(self):
self.tiers: List[ScalingTier] = []
def add_tier(self, tier: ScalingTier):
self.tiers.append(tier)
def show_tiers(self):
print(f"\n{'='*60}")
print(f"YOLO Scaling Tiers")
print(f"{'='*60}")
for tier in self.tiers:
print(f"\n [{tier.name}]")
print(f" Replicas: {tier.replicas}")
print(f" GPU: {tier.gpu}")
print(f" Model: {tier.model}")
print(f" Throughput: {tier.throughput}")
print(f" Cost: {tier.cost}")
scaling = YOLOScaling()
tiers = [
ScalingTier("Edge", "1", "Jetson Nano/Orin", "YOLOv8n",
"15-30 FPS", "Low ($200-500)"),
ScalingTier("Small", "1-2 Pods", "T4 GPU", "YOLOv8s TensorRT",
"50-100 FPS", "Medium ($0.5/hr)"),
ScalingTier("Medium", "3-5 Pods", "A10G GPU", "YOLOv8m TensorRT",
"100-300 FPS", "Medium ($1/hr)"),
ScalingTier("Large", "5-10 Pods", "A100 GPU", "YOLOv8l TensorRT",
"300-1000 FPS", "High ($3/hr)"),
ScalingTier("Enterprise", "10+ Pods HPA", "Multi-A100", "YOLOv8x TensorRT",
"1000+ FPS", "High ($10+/hr)"),
]
for tier in tiers:
scaling.add_tier(tier)
scaling.show_tiers()
# Architecture
architecture = {
"Input": "Camera Stream / Image Upload / Video File",
"Queue": "Redis / Kafka — Buffer Requests",
"Inference": "YOLO Pods (GPU) — TensorRT FP16",
"Post-processing": "NMS, Tracking, Business Logic",
"Output": "API Response / WebSocket / Storage",
"Monitoring": "Prometheus + Grafana — FPS, Latency, GPU Util",
}
print(f"\n\nInference Architecture:")
for layer, desc in architecture.items():
print(f" {layer}: {desc}")Performance Optimization
# optimization.py — YOLO Performance Optimization
optimizations = {
"TensorRT FP16": {
"speedup": "2-3x faster",
"accuracy_loss": "< 0.5% mAP",
"command": "yolo export model=yolov8m.pt format=engine half=True",
"requirement": "NVIDIA GPU (Compute Capability >= 7.0)",
},
"TensorRT INT8": {
"speedup": "3-5x faster",
"accuracy_loss": "1-2% mAP",
"command": "yolo export model=yolov8m.pt format=engine int8=True data=coco.yaml",
"requirement": "Calibration Dataset needed",
},
"ONNX Runtime": {
"speedup": "1.5-2x faster (CPU)",
"accuracy_loss": "0%",
"command": "yolo export model=yolov8m.pt format=onnx simplify=True",
"requirement": "onnxruntime / onnxruntime-gpu",
},
"OpenVINO": {
"speedup": "2-3x faster (Intel CPU)",
"accuracy_loss": "< 0.5%",
"command": "yolo export model=yolov8m.pt format=openvino half=True",
"requirement": "Intel CPU/iGPU",
},
"Image Resize": {
"speedup": "640->320 = 2-4x faster",
"accuracy_loss": "5-10% mAP",
"command": "model.predict(source, imgsz=320)",
"requirement": "ลด Input Resolution",
},
"Batch Inference": {
"speedup": "2-4x throughput",
"accuracy_loss": "0%",
"command": "model.predict(sources, batch=16)",
"requirement": "GPU Memory เพียงพอ",
},
}
print("YOLO Performance Optimizations:")
for name, info in optimizations.items():
print(f"\n [{name}]")
print(f" Speedup: {info['speedup']}")
print(f" Accuracy Loss: {info['accuracy_loss']}")
print(f" Command: {info['command']}")
print(f" Requirement: {info['requirement']}")
# GPU Comparison
gpus = {
"Jetson Nano": {"VRAM": "4GB", "YOLOv8n": "15 FPS", "cost": "$200"},
"Jetson Orin": {"VRAM": "8-32GB", "YOLOv8n": "60 FPS", "cost": "$500-2000"},
"T4": {"VRAM": "16GB", "YOLOv8m": "80 FPS", "cost": "$0.5/hr (Cloud)"},
"A10G": {"VRAM": "24GB", "YOLOv8m": "150 FPS", "cost": "$1/hr (Cloud)"},
"RTX 4090": {"VRAM": "24GB", "YOLOv8m": "200 FPS", "cost": "$1,599"},
"A100": {"VRAM": "80GB", "YOLOv8l": "250 FPS", "cost": "$3/hr (Cloud)"},
}
print(f"\n\nGPU Comparison for YOLO:")
for gpu, info in gpus.items():
print(f" {gpu:<14} VRAM: {info['VRAM']:<8} Speed: {info.get('YOLOv8m', info.get('YOLOv8n', info.get('YOLOv8l', 'N/A'))):<10} Cost: {info['cost']}")เคล็ดลับ
- TensorRT: Export YOLO เป็น TensorRT FP16 เร็วขึ้น 2-3 เท่า
- Model Size: เลือกขนาดตามงาน Nano สำหรับ Edge Large สำหรับ Server
- Batch: ใช้ Batch Inference เพิ่ม Throughput 2-4 เท่า
- Queue: ใช้ Redis/Kafka Buffer Requests ป้องกัน Overload
- HPA: ใช้ Kubernetes HPA Scale Pods ตาม GPU Utilization
- Monitor: ติดตาม FPS Latency GPU Memory ด้วย Prometheus
YOLO คืออะไร
You Only Look Once Real-time Object Detection ตรวจจับวัตถุครั้งเดียว YOLOv8 Ultralytics Detection Segmentation Pose CCTV Autonomous Driving Quality Inspection
