Ceph Storage Cluster Security Hardening

Ceph Security Hardening

Ceph Storage Cluster Security Hardening CephX Encryption Network Firewall Access Control Audit SELinux dmcrypt TLS ป้องกันแฮก

เนื้อหาเกี่ยวข้อง — แนะนำให้อ่าน Python Pydantic CQRS Event Sourcing

Layer	Threat	Mitigation	Priority
Authentication	Unauthorized Access	CephX + Least Privilege	Critical
Encryption (Transit)	Traffic Sniffing	msgr2 secure + TLS	Critical
Encryption (Rest)	Disk Theft	dmcrypt + SSE-KMS	High
Network	Network Attack	Firewall + Separate Networks	Critical
Access Control	Over-privilege	Per-pool Capabilities	High
Audit	Undetected Breach	Logging + Monitoring	High

CephX Authentication

# === CephX Authentication Hardening ===



# สร้าง User เฉพาะ Application (Least Privilege)

# ceph auth get-or-create client.webapp \

#   mon 'allow r' \

#   osd 'allow rw pool=webapp-data' \

#   -o /etc/ceph/ceph.client.webapp.keyring

#

# สร้าง User สำหรับ Backup (Read-only)

# ceph auth get-or-create client.backup \

#   mon 'allow r' \

#   osd 'allow r pool=webapp-data' \

#   -o /etc/ceph/ceph.client.backup.keyring

#

# ตรวจสอบ User ทั้งหมด

# ceph auth ls

#

# ลบ User ที่ไม่ใช้

# ceph auth del client.oldapp

#

# ตั้ง Keyring Permission

# chmod 600 /etc/ceph/ceph.client.webapp.keyring

# chown ceph:ceph /etc/ceph/ceph.client.webapp.keyring

#

# ceph.conf Security Settings

# [global]

# auth_cluster_required = cephx

# auth_service_required = cephx

# auth_client_required = cephx

# cephx_require_signatures = true

# cephx_cluster_require_signatures = true

# cephx_service_require_signatures = true



from dataclasses import dataclass



@dataclass

class CephUser:

    user: str

    mon_cap: str

    osd_cap: str

    purpose: str

    risk: str



users = [

    CephUser("client.admin",

        "allow *", "allow *",

        "Cluster Administration เท่านั้น",

        "CRITICAL - ไม่ใช้กับ Application"),

    CephUser("client.webapp",

        "allow r", "allow rw pool=webapp-data",

        "Application อ่านเขียนเฉพาะ Pool",

        "LOW - จำกัดเฉพาะ Pool"),

    CephUser("client.backup",

        "allow r", "allow r pool=webapp-data",

        "Backup Read-only",

        "LOW - อ่านได้อย่างเดียว"),

    CephUser("client.monitoring",

        "allow r", "allow r",

        "Monitoring ดูสถานะ Cluster",

        "LOW - Read-only ทุก Pool"),

    CephUser("client.rgw.gateway",

        "allow rwx", "allow rwx pool=.rgw.*",

        "RGW Service Account",

        "MEDIUM - จำกัดเฉพาะ RGW Pools"),

]



print("=== Ceph Users (Least Privilege) ===")

for u in users:

    print(f"  [{u.user}] Risk: {u.risk}")

    print(f"    mon: '{u.mon_cap}' | osd: '{u.osd_cap}'")

    print(f"    Purpose: {u.purpose}")

Encryption Configuration

# === Ceph Encryption Setup ===



# Data in Transit - msgr2 secure mode

# ceph.conf:

# [global]

# ms_cluster_mode = secure

# ms_service_mode = secure

# ms_client_mode = secure

# ms_mon_cluster_mode = secure

#

# Dashboard TLS

# ceph dashboard set-ssl-certificate -i dashboard.crt

# ceph dashboard set-ssl-certificate-key -i dashboard.key

# ceph mgr module enable dashboard

#

# RGW TLS (via Beast frontend)

# [client.rgw.gateway]

# rgw_frontends = beast ssl_port=443 ssl_certificate=/etc/ceph/rgw.pem

#

# Data at Rest - OSD dmcrypt

# ceph-volume lvm create --dmcrypt --data /dev/sdb

# # Key stored in Monitor automatically

#

# RGW Server-Side Encryption with Vault

# [client.rgw.gateway]

# rgw_crypt_s3_kms_backend = vault

# rgw_crypt_vault_addr = https://vault.example.com:8200

# rgw_crypt_vault_token = s.xxxxxxxxxxxx

# rgw_crypt_vault_secret_engine = kv

# rgw_crypt_vault_prefix = /v1/secret/data



@dataclass

class EncryptionConfig:

    layer: str

    method: str

    config: str

    key_management: str



encryption = [

    EncryptionConfig("Data in Transit (Cluster)",

        "msgr2 Secure Mode",

        "ms_cluster_mode = secure",

        "CephX Keys (automatic)"),

    EncryptionConfig("Data in Transit (Client)",

        "msgr2 Secure Mode",

        "ms_client_mode = secure",

        "CephX Keys (automatic)"),

    EncryptionConfig("Data at Rest (OSD)",

        "LUKS/dmcrypt",

        "ceph-volume lvm create --dmcrypt",

        "Keys in Monitor Keyring"),

    EncryptionConfig("Data at Rest (RGW)",

        "SSE-KMS (Vault)",

        "rgw_crypt_s3_kms_backend = vault",

        "HashiCorp Vault KMS"),

    EncryptionConfig("Dashboard",

        "TLS Certificate",

        "ceph dashboard set-ssl-certificate",

        "PKI / Let's Encrypt"),

    EncryptionConfig("RGW API",

        "TLS (Beast SSL)",

        "rgw_frontends = beast ssl_port=443",

        "PKI / Let's Encrypt"),

]



print("=== Encryption Configuration ===")

for e in encryption:

    print(f"  [{e.layer}] {e.method}")

    print(f"    Config: {e.config}")

    print(f"    Key: {e.key_management}")

Network & Firewall

# === Network Security & Firewall Rules ===



# Firewall Rules (firewalld)

# # Monitor nodes

# firewall-cmd --zone=ceph --add-port=3300/tcp --permanent  # msgr2

# firewall-cmd --zone=ceph --add-port=6789/tcp --permanent  # msgr1

#

# # OSD nodes

# firewall-cmd --zone=ceph --add-port=6800-7300/tcp --permanent

#

# # Dashboard

# firewall-cmd --zone=mgmt --add-port=8443/tcp --permanent

#

# # RGW

# firewall-cmd --zone=public --add-port=443/tcp --permanent

#

# # Restrict source IPs

# firewall-cmd --zone=ceph --add-source=10.0.0.0/24 --permanent

# firewall-cmd --reload

#

# ceph.conf Network Separation

# [global]

# public_network = 10.0.1.0/24

# cluster_network = 10.0.2.0/24



@dataclass

class FirewallRule:

    service: str

    port: str

    zone: str

    source: str

    note: str



rules = [

    FirewallRule("Monitor (msgr2)", "3300/tcp",

        "ceph", "10.0.0.0/24 (Ceph nodes + Clients)",

        "จำกัดเฉพาะ Ceph Network"),

    FirewallRule("Monitor (msgr1)", "6789/tcp",

        "ceph", "10.0.0.0/24",

        "Legacy protocol ปิดถ้าใช้ msgr2 อย่างเดียว"),

    FirewallRule("OSD", "6800-7300/tcp",

        "cluster", "10.0.2.0/24 (Cluster Network only)",

        "เปิดเฉพาะ Cluster Network ไม่เปิด Public"),

    FirewallRule("Dashboard", "8443/tcp",

        "mgmt", "10.0.100.0/24 (Management Network)",

        "เข้าผ่าน VPN หรือ Bastion Host เท่านั้น"),

    FirewallRule("RGW (S3 API)", "443/tcp",

        "public", "Application Subnet",

        "ผ่าน Load Balancer + WAF ถ้าเปิด Public"),

]



print("=== Firewall Rules ===")

for r in rules:

    print(f"  [{r.service}] Port: {r.port}")

    print(f"    Zone: {r.zone} | Source: {r.source}")

    print(f"    Note: {r.note}")
