SonarQube Analysis Machine Learning Pipeline

SonarQube ML Pipeline

SonarQube Machine Learning Pipeline Code Quality Bug Vulnerability Coverage Data Validation Feature Engineering Model Training Serving CI/CD

ML Code Quality Rules

# === ML-specific Quality Rules ===

from dataclasses import dataclass

@dataclass
class MLQualityRule:
    rule_id: str
    name: str
    severity: str
    category: str
    bad_example: str
    good_example: str

rules = [
    MLQualityRule("ML001",
        "ห้าม Hardcode File Path",
        "MAJOR",
        "Data Ingestion",
        "df = pd.read_csv('/home/user/data/train.csv')",
        "df = pd.read_csv(config.DATA_PATH / 'train.csv')"),
    MLQualityRule("ML002",
        "ต้องตั้ง Random Seed",
        "CRITICAL",
        "Model Training",
        "model = RandomForestClassifier()",
        "model = RandomForestClassifier(random_state=config.SEED)"),
    MLQualityRule("ML003",
        "ห้าม print() ใน Production Code",
        "MINOR",
        "All",
        "print(f'Training loss: {loss}')",
        "logger.info(f'Training loss: {loss}')"),
    MLQualityRule("ML004",
        "ต้อง Validate Input ใน API",
        "CRITICAL",
        "Model Serving",
        "prediction = model.predict(request.json['data'])",
        "validated = InputSchema(**request.json); prediction = model.predict(validated.data)"),
    MLQualityRule("ML005",
        "ห้าม Data Leak (ใช้ Test Data ก่อน Split)",
        "BLOCKER",
        "Feature Engineering",
        "scaler.fit(all_data); X_train = scaler.transform(X_train)",
        "scaler.fit(X_train); X_test = scaler.transform(X_test)"),
    MLQualityRule("ML006",
        "ต้อง Handle Missing Values",
        "MAJOR",
        "Feature Engineering",
        "features = df[['col1', 'col2']].values",
        "features = df[['col1', 'col2']].fillna(strategy).values"),
]

print("=== ML Quality Rules ===")
for r in rules:
    print(f"\n  [{r.rule_id}] {r.name} ({r.severity})")
    print(f"    Category: {r.category}")
    print(f"    Bad:  {r.bad_example}")
    print(f"    Good: {r.good_example}")

CI/CD Integration

# === ML Pipeline CI/CD with SonarQube ===

# GitHub Actions for ML Pipeline
# name: ML Pipeline Quality
# on: [pull_request]
# jobs:
#   quality:
#     runs-on: ubuntu-latest
#     steps:
#       - uses: actions/checkout@v4
#       - name: Setup Python
#         uses: actions/setup-python@v5
#         with: { python-version: '3.10' }
#       - name: Install Dependencies
#         run: pip install -r requirements.txt
#       - name: Run Tests with Coverage
#         run: pytest tests/ --cov=src --cov-report=xml
#       - name: Data Validation Tests
#         run: great_expectations checkpoint run ml_data_check
#       - name: SonarQube Scan
#         uses: SonarSource/sonarqube-scan-action@v2
#         env:
#           SONAR_TOKEN: }
#       - name: Quality Gate
#         uses: SonarSource/sonarqube-quality-gate-action@v1

@dataclass
class PipelineStage:
    stage: str
    tools: str
    checks: str
    gate: str

stages = [
    PipelineStage("1. PR Quality Check",
        "SonarQube + pytest + Great Expectations",
        "Code Quality, Unit Tests, Data Schema Validation",
        "Quality Gate Pass + Tests Pass + Data Valid"),
    PipelineStage("2. Integration Test",
        "pytest + MLflow + Docker",
        "End-to-end Pipeline Test, Model Training Smoke Test",
        "All Tests Pass, Model Metrics > Baseline"),
    PipelineStage("3. Model Training",
        "MLflow + DVC + SonarQube",
        "Data Quality, Training Metrics, Model Validation",
        "Accuracy > Threshold, No Data Drift"),
    PipelineStage("4. Model Registry",
        "MLflow Model Registry",
        "Model Artifact, Metrics, Lineage, Version",
        "Model Approved by Reviewer"),
    PipelineStage("5. Staging Deploy",
        "Kubernetes + Seldon/BentoML",
        "API Tests, Load Test, Security Scan (DAST)",
        "Response Time < 100ms, No Vulnerabilities"),
    PipelineStage("6. Production Deploy",
        "Kubernetes + Canary/Blue-Green",
        "Canary Metrics, A/B Test, Model Monitor",
        "No Degradation in Business Metrics"),
]

print("=== ML CI/CD Pipeline ===")
for s in stages:
    print(f"\n  [{s.stage}]")
    print(f"    Tools: {s.tools}")
    print(f"    Checks: {s.checks}")
    print(f"    Gate: {s.gate}")

Testing Strategy

# === ML Testing Strategy ===

@dataclass
class TestCategory:
    category: str
    what_to_test: str
    tools: str
    coverage_target: str

test_categories = [
    TestCategory("Unit Tests (Data)",
        "Data Loading, Transformation, Validation, Encoding",
        "pytest + pandas testing + Great Expectations",
        "> 80% Coverage"),
    TestCategory("Unit Tests (Feature)",
        "Feature Engineering, Scaling, Selection, Encoding",
        "pytest + numpy testing",
        "> 70% Coverage"),
    TestCategory("Unit Tests (Model)",
        "Model Init, Predict Shape, Save/Load, Config",
        "pytest + sklearn metrics",
        "> 50% Coverage (Training ยากทดสอบ)"),
    TestCategory("Integration Tests",
        "End-to-end Pipeline, Data→Feature→Model→Predict",
        "pytest + Docker + Sample Data",
        "> 60% Coverage"),
    TestCategory("API Tests",
        "Endpoint, Input Validation, Error Handling, Auth",
        "pytest + httpx + FastAPI TestClient",
        "> 80% Coverage"),
    TestCategory("Data Quality Tests",
        "Schema, Null, Range, Distribution, Freshness",
        "Great Expectations + Monte Carlo",
        "100% Critical Checks"),
]

print("=== ML Testing Strategy ===")
for t in test_categories:
    print(f"  [{t.category}]")
    print(f"    Test: {t.what_to_test}")
    print(f"    Tools: {t.tools}")
    print(f"    Target: {t.coverage_target}")

เคล็ดลับ

• Coverage: ML Training Code Coverage ต่ำกว่า Web App เป็นปกติ ตั้ง 50-70%
• Custom Rules: สร้าง Custom Rules สำหรับ ML เช่น Data Leak Random Seed
• Notebook: แปลง Notebook เป็น .py ก่อน Scan ด้วย nbconvert
• Profile: แยก Quality Profile สำหรับ ML Code กับ App Code
• Data Test: ใช้ Great Expectations ตรวจ Data Quality ควบคู่ Code Quality

การนำไปใช้งานจริงในองค์กร

สำหรับองค์กรขนาดกลางถึงใหญ่ แนะนำให้ใช้หลัก Three-Tier Architecture คือ Core Layer ที่เป็นแกนกลางของระบบ Distribution Layer ที่ทำหน้าที่กระจาย Traffic และ Access Layer ที่เชื่อมต่อกับผู้ใช้โดยตรง การแบ่ง Layer ชัดเจนช่วยให้การ Troubleshoot ง่ายขึ้นและสามารถ Scale ระบบได้ตามความต้องการ

เรื่อง Network Security ก็สำคัญไม่แพ้กัน ควรติดตั้ง Next-Generation Firewall ที่สามารถ Deep Packet Inspection ได้ ใช้ Network Segmentation แยก VLAN สำหรับแต่ละแผนก ติดตั้ง IDS/IPS เพื่อตรวจจับการโจมตี และทำ Regular Security Audit อย่างน้อยปีละ 2 ครั้ง

สรุป

SonarQube ML Pipeline Code Quality Custom Rules Data Leak Random Seed Coverage API Security Great Expectations MLflow CI/CD Production
