Linkerd Service Mesh Security Hardening

Linkerd Service Mesh Security

Linkerd Service Mesh Kubernetes mTLS Rust Go CNCF Security Hardening Authorization Policy Traffic Encryption Zero Trust Observability

Linkerd Installation และ mTLS

=== Linkerd Installation & Security ===

อ่านเพิ่ม: Let's Encrypt SSL ฟรี ติดตั้ง HTTPS บน Server Linux · ดูรายละเอียด Let's Encrypt SSL ฟรี ติดตั้ง HTTPS บน Server Linux · อ่านเพิ่ม: Zabbix Network Monitoring ตั้งค่าดูแล Network ทั้งออฟฟิศ

Install CLI

curl -fsL https://run.linkerd.io/install | sh

export PATH=$HOME/.linkerd2/bin:$PATH

linkerd version

Pre-check

linkerd check --pre

Install Control Plane

linkerd install --crds | kubectl apply -f -

linkerd install | kubectl apply -f -

linkerd check

Inject Sidecar (Auto mTLS)

kubectl get deploy -n my-app -o yaml | linkerd inject - | kubectl apply -f -

หรือ

kubectl annotate namespace my-app linkerd.io/inject=enabled

Verify mTLS

linkerd viz edges po -n my-app

linkerd viz tap deploy/my-api -n my-app

ดู tls=true ในผลลัพธ์

Check Identity (Certificates)

linkerd identity

linkerd check --proxy

เนื้อหาเกี่ยวข้อง — อ่านต่อ: Vector Database Pinecone Internal Developer

Authorization Policy (Server + ServerAuthorization)

apiVersion: policy.linkerd.io/v1beta2

kind: Server

metadata:

name: api-server

namespace: my-app

spec:

podSelector:

matchLabels:

app: my-api

port: 8080

แนะนำเพิ่มเติม — บทวิเคราะห์จาก XM Signal

proxyProtocol: HTTP/2

---

apiVersion: policy.linkerd.io/v1beta2

kind: ServerAuthorization

metadata:

name: allow-web-to-api

namespace: my-app

spec:

server:

name: api-server

client:

meshTLS:

serviceAccounts:

• name: web-frontend

namespace: my-app

from dataclasses import dataclass, field

from typing import List

@dataclass

class MeshService:

name: str

namespace: str

meshed: bool

mtls: bool

success_rate: float

เนื้อหาเกี่ยวข้อง — แนะนำให้อ่าน react-helmet คือ — ข้อมูลครบถ้วน 2026

latency_p99_ms: float

rps: float

services = [

MeshService("web-frontend", "my-app", True, True, 99.95, 45, 250),

MeshService("api-server", "my-app", True, True, 99.98, 22, 500),

MeshService("auth-service", "my-app", True, True, 99.99, 15, 300),

MeshService("db-proxy", "my-app", True, True, 100.0, 5, 800),

MeshService("cache-service", "my-app", True, True, 100.0, 2, 1200),

MeshService("legacy-service", "legacy", False, False, 98.5, 120, 50),

]

print("=== Linkerd Mesh Status ===")

for s in services:

mesh = "Meshed" if s.meshed else "NOT Meshed"

tls = "mTLS" if s.mtls else "NO TLS"

แนะนำเพิ่มเติม — SiamCafeBook

print(f" [{mesh}] {s.name}.{s.namespace}")

print(f" {tls} | SR: {s.success_rate}% | P99: {s.latency_p99_ms}ms | "

f"RPS: {s.rps}")

Authorization Policies

# === Security Hardening Policies ===

# Default Deny Policy
# apiVersion: policy.linkerd.io/v1beta2
# kind: Server
# metadata:
#   name: default-deny
#   namespace: my-app
# spec:
#   podSelector: {}  # All pods
#   port: 8080
#
# # No ServerAuthorization = Deny All
# # Then create specific Allow rules

# Network Policy (Kubernetes)
# apiVersion: networking.k8s.io/v1
# kind: NetworkPolicy
# metadata:
#   name: deny-all
#   namespace: my-app
# spec:
#   podSelector: {}
#   policyTypes:
#   - Ingress
#   - Egress
#
# ---
# apiVersion: networking.k8s.io/v1
# kind: NetworkPolicy
# metadata:
#   name: allow-web-to-api
#   namespace: my-app
# spec:
#   podSelector:
#     matchLabels:
#       app: api-server
#   ingress:
#   - from:
#     - podSelector:
#         matchLabels:
#           app: web-frontend
#     ports:
#     - port: 8080

@dataclass
class AuthPolicy:
    name: str
    server: str
    allowed_clients: List[str]
    protocol: str
    action: str

policies = [
    AuthPolicy("allow-web-to-api", "api-server:8080",
        ["web-frontend"], "HTTP/2", "Allow"),
    AuthPolicy("allow-api-to-db", "db-proxy:5432",
        ["api-server"], "TCP", "Allow"),
    AuthPolicy("allow-api-to-cache", "cache-service:6379",
        ["api-server"], "TCP", "Allow"),
    AuthPolicy("allow-api-to-auth", "auth-service:8080",
        ["api-server", "web-frontend"], "HTTP/2", "Allow"),
    AuthPolicy("deny-all-default", "all:*",
        [], "Any", "Deny (Default)"),
]

print("\n=== Authorization Policies ===")
for p in policies:
    clients = ", ".join(p.allowed_clients) if p.allowed_clients else "None"
    print(f"  [{p.action}] {p.name}")
    print(f"    Server: {p.server} ({p.protocol})")
    print(f"    Clients: {clients}")

# Security Checklist
security = {
    "mTLS": ["Verify all pods are meshed", "Check certificate rotation", "Monitor TLS errors"],
    "Authorization": ["Default deny all", "Explicit allow rules only", "Service account per service"],
    "Network": ["NetworkPolicy deny all first", "Allow only required traffic", "Egress control"],
    "Observability": ["Monitor success rates", "Alert on mTLS failures", "Audit access logs"],
    "Supply Chain": ["Scan container images", "Pin image versions", "Sign with cosign"],
}

print(f"\n\nSecurity Hardening Checklist:")
for category, items in security.items():
    print(f"\n  [{category}]")
    for item in items:
        print(f"    - {item}")

Observability และ Monitoring

=== Linkerd Observability ===

linkerd viz install | kubectl apply -f -

linkerd viz dashboard &

# Live Traffic

linkerd viz top deploy/api-server -n my-app

linkerd viz tap deploy/api-server -n my-app

# Routes

linkerd viz routes deploy/api-server -n my-app

เนื้อหาเกี่ยวข้อง — ดูเพิ่มเติมเรื่อง Azure Front Door Automation Script

# Service Profile (Retry + Timeout)

apiVersion: linkerd.io/v1alpha2

kind: ServiceProfile

metadata:

name: api-server.my-app.svc.cluster.local

namespace: my-app

spec:

routes:

• name: GET /api/users

condition:

method: GET

pathRegex: /api/users

timeout: 5s

isRetryable: true

• name: POST /api/orders

condition:

method: POST

pathRegex: /api/orders

timeout: 10s

isRetryable: false

Prometheus Metrics

linkerd_request_total

linkerd_response_total

linkerd_response_latency_ms_bucket

linkerd_tcp_open_total

linkerd_identity_cert_expiration_timestamp

golden_signals = {

"Latency": {

"metric": "linkerd_response_latency_ms_bucket",

"alert": "P99 > 500ms for 5 min",

เนื้อหาเกี่ยวข้อง — บทความที่เกี่ยวข้อง: Nginx Plus Community Building

"dashboard": "Latency percentiles per route",

},

"Traffic": {

"metric": "linkerd_request_total",

"alert": "RPS drop > 50% in 5 min",

"dashboard": "RPS per service and route",

},

"Errors": {

"metric": "linkerd_response_total{classification='failure'}",

"alert": "Error rate > 1% for 3 min",

"dashboard": "Error rate per service",

},

"Saturation": {

"metric": "container_memory_usage_bytes",

"alert": "Memory > 90% for 5 min",

"dashboard": "CPU and Memory per proxy",

},

}

print("Golden Signals Monitoring:")

for signal, info in golden_signals.items():

print(f"\n [{signal}]")

for k, v in info.items():

print(f" {k}: {v}")

เคล็ดลับ

• mTLS: Linkerd เปิด mTLS อัตโนมัติ ไม่ต้อง Config เพิ่ม
• Default Deny: ตั้ง Server without Authorization = Deny All
• Inject: ใช้ Namespace Annotation auto-inject สะดวกกว่า Manual
• Profile: สร้าง ServiceProfile ตั้ง Timeout Retry ทุก Route
• Monitor: ดู Golden Signals ทุก Service ตั้ง Alert ที่เหมาะสม

Linkerd คืออะไร

Open Source Service Mesh Kubernetes Rust Go เบา เร็ว mTLS อัตโนมัติ Traffic Splitting Observability CNCF Graduated
