Immutable OS Fedora CoreOS Performance Tuning

Fedora CoreOS Tuning

Fedora CoreOS Immutable OS Performance Tuning Ignition Kernel Container Runtime Network Storage Boot Kubernetes Edge Production

Tuning Area	Default	Optimized	Impact	Risk
TCP Buffer	4096 87380 6291456	4096 262144 16777216	Network throughput +30%	Low
Conntrack Max	65536	1048576	More concurrent connections	Low (more RAM)
File Descriptors	1024	1048576	More open files/sockets	Low
Huge Pages	Disabled	Enabled (2MB pages)	Memory access +10-20%	Medium
Swappiness	60	10	Less swapping, more RAM for apps	Low
I/O Scheduler	mq-deadline	none (NVMe) / mq-deadline (SSD)	I/O latency -20%	Low

Ignition and Kernel Tuning

# === Butane Config for Performance ===

# config.bu (Butane YAML)
# variant: fcos
# version: 1.5.0
# storage:
#   files:
#     - path: /etc/sysctl.d/99-performance.conf
#       mode: 0644
#       contents:
#         inline: |
#           # Network
#           net.core.rmem_max=16777216
#           net.core.wmem_max=16777216
#           net.ipv4.tcp_rmem=4096 262144 16777216
#           net.ipv4.tcp_wmem=4096 262144 16777216
#           net.core.somaxconn=65535
#           net.core.netdev_max_backlog=65536
#           net.ipv4.tcp_max_syn_backlog=65536
#           net.nf_conntrack_max=1048576
#           # Memory
#           vm.swappiness=10
#           vm.overcommit_memory=1
#           vm.max_map_count=262144
#           # File System
#           fs.file-max=2097152
#           fs.inotify.max_user_watches=524288
#     - path: /etc/security/limits.d/99-nofile.conf
#       mode: 0644
#       contents:
#         inline: |
#           * soft nofile 1048576
#           * hard nofile 1048576
# kernel_arguments:
#   should_exist:
#     - mitigations=auto
#     - transparent_hugepage=madvise
# systemd:
#   units:
#     - name: performance-tuning.service
#       enabled: true
#       contents: |
#         [Unit]
#         Description=Apply Performance Tuning
#         After=network.target
#         [Service]
#         Type=oneshot
#         ExecStart=/usr/sbin/sysctl --system
#         [Install]
#         WantedBy=multi-user.target

# Convert to Ignition
# butane --pretty --strict config.bu > config.ign

from dataclasses import dataclass

@dataclass
class KernelParam:
    param: str
    default: str
    tuned: str
    purpose: str
    category: str

params = [
    KernelParam("net.core.rmem_max", "212992", "16777216", "Max receive buffer", "Network"),
    KernelParam("net.core.wmem_max", "212992", "16777216", "Max send buffer", "Network"),
    KernelParam("net.core.somaxconn", "4096", "65535", "Max listen backlog", "Network"),
    KernelParam("net.nf_conntrack_max", "65536", "1048576", "Max tracked connections", "Network"),
    KernelParam("vm.swappiness", "60", "10", "Reduce swap usage", "Memory"),
    KernelParam("vm.max_map_count", "65530", "262144", "Max memory map areas", "Memory"),
    KernelParam("fs.file-max", "524288", "2097152", "Max open files system-wide", "FileSystem"),
    KernelParam("fs.inotify.max_user_watches", "8192", "524288", "Max inotify watches", "FileSystem"),
]

print("=== Kernel Parameters ===")
for p in params:
    print(f"  [{p.category}] {p.param}")
    print(f"    Default: {p.default} → Tuned: {p.tuned}")
    print(f"    Purpose: {p.purpose}")

Container Runtime Optimization

# === Container and Podman Tuning ===

# Podman/CRI-O config for CoreOS
# /etc/containers/storage.conf
# [storage]
# driver = "overlay"
# [storage.options.overlay]
# mountopt = "nodev, metacopy=on"

# /etc/containers/containers.conf
# [engine]
# cgroup_manager = "systemd"
# events_logger = "journald"
# runtime = "crun"     # Faster than runc
# [engine.runtimes]
# crun = ["/usr/bin/crun"]

# CPU Pinning for critical containers
# podman run --cpuset-cpus="0-3" --memory="4g" --memory-swap="4g" myapp

# Kubernetes kubelet config on CoreOS
# /etc/kubernetes/kubelet-config.yaml
# apiVersion: kubelet.config.k8s.io/v1beta1
# kind: KubeletConfiguration
# cgroupDriver: systemd
# maxPods: 250
# kubeReserved:
#   cpu: "500m"
#   memory: "512Mi"
# systemReserved:
#   cpu: "500m"
#   memory: "512Mi"
# evictionHard:
#   memory.available: "200Mi"
#   nodefs.available: "10%"

@dataclass
class ContainerTuning:
    setting: str
    value: str
    impact: str
    applies_to: str

tunings = [
    ContainerTuning("Runtime: crun", "crun instead of runc",
        "Container startup 50% faster, less memory",
        "Podman / CRI-O"),
    ContainerTuning("Overlay metacopy", "metacopy=on",
        "Faster layer operations, less disk I/O",
        "Storage driver"),
    ContainerTuning("CPU Pinning", "--cpuset-cpus=0-3",
        "Dedicated CPU cores, no context switching",
        "Latency-sensitive containers"),
    ContainerTuning("Memory Limit = Swap", "--memory=4g --memory-swap=4g",
        "No swap for container, predictable performance",
        "All production containers"),
    ContainerTuning("cgroup v2", "systemd cgroup driver",
        "Better resource accounting, pressure stall info",
        "CoreOS default"),
    ContainerTuning("Read-only rootfs", "--read-only",
        "Security + slight performance improvement",
        "Stateless containers"),
]

print("=== Container Tuning ===")
for t in tunings:
    print(f"  [{t.setting}] Value: {t.value}")
    print(f"    Impact: {t.impact}")
    print(f"    Applies to: {t.applies_to}")

Monitoring and Updates

# === CoreOS Update and Monitoring ===

# Auto-update with Zincati
# /etc/zincati/config.d/55-updates-strategy.toml
# [updates]
# strategy = "periodic"
# [[updates.periodic.window]]
# days = [ "Sun" ]
# start_time = "02:00"
# length_minutes = 120

# rpm-ostree commands
# rpm-ostree status              # Current deployment status
# rpm-ostree upgrade             # Manual upgrade
# rpm-ostree rollback            # Rollback to previous
# rpm-ostree install htop        # Layer package (avoid if possible)
# rpm-ostree kargs --append=key=value  # Add kernel argument

# Monitoring with Prometheus Node Exporter
# podman run -d --name node-exporter \
#   --net=host --pid=host \
#   -v /:/host:ro, rslave \
#   quay.io/prometheus/node-exporter --path.rootfs=/host

@dataclass
class MonitorMetric:
    metric: str
    source: str
    alert_threshold: str
    action: str

metrics = [
    MonitorMetric("CPU Usage", "node_cpu_seconds_total",
        "> 80% for 5 min", "Scale up or optimize workload"),
    MonitorMetric("Memory Usage", "node_memory_MemAvailable_bytes",
        "< 500 MB available", "Check container limits, OOM risk"),
    MonitorMetric("Disk Usage", "node_filesystem_avail_bytes",
        "< 15% free", "Clean images, expand disk"),
    MonitorMetric("Network Errors", "node_network_receive_errs_total",
        "> 0 for 5 min", "Check NIC, cable, driver"),
    MonitorMetric("Container Restarts", "kube_pod_container_status_restarts",
        "> 3 in 1 hour", "Check logs, fix crash loop"),
    MonitorMetric("OS Update Pending", "rpm_ostree_pending_update",
        "Update available > 7 days", "Schedule maintenance window"),
    MonitorMetric("Boot Time", "node_boot_time_seconds",
        "Unexpected reboot", "Check crash, kernel panic"),
]

print("=== Monitoring Metrics ===")
for m in metrics:
    print(f"  [{m.metric}] Source: {m.source}")
    print(f"    Alert: {m.alert_threshold}")
    print(f"    Action: {m.action}")

เคล็ดลับ

crun: ใช้ crun แทน runc Container Start เร็วขึ้น 50%
Layer: อย่า rpm-ostree install มากเกินไป ใช้ Container แทน
Rollback: ทดสอบ Rollback ก่อน Deploy จริง rpm-ostree rollback
Ignition: เก็บ Ignition Config ใน Git เป็น Infrastructure as Code
Zincati: ตั้ง Update Window นอกเวลาใช้งาน ป้องกัน Downtime

Fedora CoreOS คืออะไร

Immutable OS Container rpm-ostree Atomic Update Rollback Ignition Provisioning Zincati Auto-update Kubernetes Edge IoT Boot เร็ว ขนาดเล็ก
