Database Replication คือ — คู่มือ Replication

Database Replication

Database Replication คือ Master-Slave Multi-Master Synchronous Asynchronous WAL Binary Log Failover HA Read Scaling Disaster Recovery

เนื้อหาเกี่ยวข้อง — ดูเพิ่มเติมเรื่อง SASE Security Capacity Planning

Type	Write	Read	Consistency	Use Case
Master-Slave	Master only	Master + Slaves	Eventual (Async)	Read-heavy, Simple HA
Multi-Master	All nodes	All nodes	Eventual/Strong	Multi-region Write
Synchronous	Primary	Primary + Standby	Strong	Zero data loss
Semi-sync	Primary	Primary + Replicas	Near-strong	Balance Safety/Speed
Cascading	Primary	Primary + Chain	Eventual	Many replicas

MySQL Replication

# === MySQL Master-Slave Replication Setup ===



# Master Configuration (my.cnf)

# [mysqld]

# server-id = 1

# log_bin = mysql-bin

# binlog_format = ROW

# binlog_do_db = myapp

# gtid_mode = ON

# enforce_gtid_consistency = ON

# sync_binlog = 1

# innodb_flush_log_at_trx_commit = 1



# Create Replication User on Master

# CREATE USER 'repl'@'10.0.0.%' IDENTIFIED BY 'strong_password';

# GRANT REPLICATION SLAVE ON *.* TO 'repl'@'10.0.0.%';

# FLUSH PRIVILEGES;



# Slave Configuration (my.cnf)

# [mysqld]

# server-id = 2

# relay_log = relay-bin

# read_only = ON

# gtid_mode = ON

# enforce_gtid_consistency = ON



# Start Replication on Slave

# CHANGE MASTER TO

#   MASTER_HOST='10.0.0.1',

#   MASTER_USER='repl',

#   MASTER_PASSWORD='strong_password',

#   MASTER_AUTO_POSITION=1;

# START SLAVE;

# SHOW SLAVE STATUS\G



from dataclasses import dataclass



@dataclass

class ReplicationConfig:

    database: str

    config_key: str

    master_value: str

    slave_value: str

    purpose: str



configs = [

    ReplicationConfig("MySQL",

        "server-id", "1", "2 (unique per node)",

        "ระบุตัวตน Node ต้องไม่ซ้ำ"),

    ReplicationConfig("MySQL",

        "log_bin", "mysql-bin", "ไม่ต้อง (ยกเว้น Chain)",

        "เก็บ Binary Log สำหรับ Replication"),

    ReplicationConfig("MySQL",

        "binlog_format", "ROW", "ROW",

        "ROW-based Replication ปลอดภัยที่สุด"),

    ReplicationConfig("MySQL",

        "gtid_mode", "ON", "ON",

        "Global Transaction ID ง่ายต่อ Failover"),

    ReplicationConfig("MySQL",

        "sync_binlog", "1", "-",

        "Sync binlog ทุก Transaction ไม่สูญหาย"),

    ReplicationConfig("MySQL",

        "read_only", "OFF", "ON",

        "Slave อ่านอย่างเดียว ป้องกัน Write ผิดตัว"),

]



print("=== MySQL Replication Config ===")

for c in configs:

    print(f"  [{c.config_key}] Master: {c.master_value} | Slave: {c.slave_value}")

    print(f"    Purpose: {c.purpose}")

PostgreSQL Replication

# === PostgreSQL Streaming Replication ===



# Primary Configuration (postgresql.conf)

# wal_level = replica

# max_wal_senders = 5

# wal_keep_size = 1GB

# synchronous_commit = on  # or 'remote_apply' for sync

# synchronous_standby_names = 'replica1'



# pg_hba.conf (Allow Replication)

# host replication repl_user 10.0.0.0/24 scram-sha-256



# Create Replication User

# CREATE ROLE repl_user WITH REPLICATION LOGIN PASSWORD 'strong_pass';

# SELECT * FROM pg_create_physical_replication_slot('replica1_slot');



# Standby Setup

# pg_basebackup -h primary -U repl_user -D /var/lib/postgresql/data -Fp -Xs -P -R

# # -R creates standby.signal + primary_conninfo automatically



# standby postgresql.conf

# primary_conninfo = 'host=10.0.0.1 port=5432 user=repl_user password=strong_pass'

# primary_slot_name = 'replica1_slot'

# hot_standby = on



# Check Replication Status

# SELECT * FROM pg_stat_replication;

# SELECT pg_last_wal_receive_lsn(), pg_last_wal_replay_lsn(),

#        pg_last_xact_replay_timestamp();



@dataclass

class PGReplication:

    param: str

    value: str

    purpose: str

    impact: str



pg_configs = [

    PGReplication("wal_level",

        "replica (or logical)",

        "กำหนดระดับ WAL logging",

        "replica สำหรับ Physical, logical สำหรับ Logical Replication"),

    PGReplication("max_wal_senders",

        "5 (ขึ้นกับจำนวน Replica)",

        "จำนวน Connection สำหรับ Streaming",

        "ตั้งมากกว่าจำนวน Replica + 1-2 สำหรับ Backup"),

    PGReplication("synchronous_commit",

        "on / remote_apply / remote_write",

        "ระดับ Consistency",

        "on=local, remote_apply=strong (ช้ากว่า 2-5x)"),

    PGReplication("wal_keep_size",

        "1GB-10GB",

        "เก็บ WAL ไว้เผื่อ Replica หลุด",

        "ใหญ่เกิน = ใช้ Disk มาก เล็กเกิน = Replica ต้อง Rebuild"),

    PGReplication("hot_standby",

        "on",

        "อ่านข้อมูลจาก Standby ได้",

        "ใช้ Standby สำหรับ Read Query ลด Load Primary"),

]



print("=== PostgreSQL Replication ===")

for p in pg_configs:

    print(f"  [{p.param}] = {p.value}")

    print(f"    Purpose: {p.purpose}")

    print(f"    Impact: {p.impact}")

Monitoring & Failover

# === Replication Monitoring & Automated Failover ===



@dataclass

class MonitorMetric:

    metric: str

    query: str

    threshold: str

    action: str



monitoring = [

    MonitorMetric("Replication Lag (MySQL)",

        "SHOW SLAVE STATUS → Seconds_Behind_Master",

        "> 5 seconds → Warning, > 30s → Critical",

        "Check slow queries on Slave, Network, Disk I/O"),

    MonitorMetric("Replication Lag (PostgreSQL)",

        "SELECT extract(epoch from now()-pg_last_xact_replay_timestamp())",

        "> 5 seconds → Warning, > 30s → Critical",

        "Check WAL throughput, Network, Slave resources"),

    MonitorMetric("Slave IO/SQL Thread",

        "SHOW SLAVE STATUS → Slave_IO_Running, Slave_SQL_Running",

        "No → Critical",

        "Check connectivity, Error log, SKIP counter"),

    MonitorMetric("WAL Sender State (PG)",

        "SELECT state FROM pg_stat_replication",

        "NULL (disconnected) → Critical",

        "Check network, Standby status, Slot"),

    MonitorMetric("Replication Slot Lag",

        "SELECT pg_wal_lsn_diff(pg_current_wal_lsn(), confirmed_flush_lsn)",

        "> 1GB → Warning",

        "Slot retained WAL ใช้ Disk มาก ลบ Slot ถ้า Replica ตาย"),

]



@dataclass

class FailoverTool:

    tool: str

    database: str

    method: str

    rpo_rto: str



failover_tools = [

    FailoverTool("Orchestrator",

        "MySQL",

        "Auto-detect failure + Promote best Slave + Reroute traffic",

        "RPO: ~0s (GTID), RTO: 10-30s"),

    FailoverTool("Patroni + etcd",

        "PostgreSQL",

        "Leader election via etcd + Auto-promote Standby",

        "RPO: 0s (sync) / ~1s (async), RTO: 10-30s"),

    FailoverTool("PgBouncer",

        "PostgreSQL",

        "Connection pooling + Route to new Primary",

        "ลด Connection overhead + Seamless failover"),

    FailoverTool("ProxySQL",

        "MySQL",

        "Query routing + Read/Write split + Auto-failover",

        "Application ไม่ต้องเปลี่ยน Connection String"),

]



print("=== Monitoring ===")

for m in monitoring:

    print(f"  [{m.metric}]")

    print(f"    Query: {m.query}")

    print(f"    Threshold: {m.threshold}")



print("\n=== Failover Tools ===")

for f in failover_tools:

    print(f"  [{f.tool}] {f.database}")

    print(f"    Method: {f.method}")

    print(f"    RPO/RTO: {f.rpo_rto}")

เคล็ดลับ

GTID: ใช้ GTID (MySQL) สำหรับ Failover ง่ายกว่า Position-based
Slot: ใช้ Replication Slot (PostgreSQL) ป้องกัน WAL ถูกลบ
Monitor: ตั้ง Alert Replication Lag > 5 วินาที เสมอ
Failover: ใช้ Orchestrator/Patroni Automated Failover
Test: ทดสอบ Failover เป็นระยะ Disaster Recovery Drill

Database Replication คืออะไร

สำเนาข้อมูลอัตโนมัติ HA Read Scaling DR Synchronous Asynchronous Semi-sync Master-Slave Multi-Master WAL Binary Log Failover
