Crossplane Composition CQRS Event Sourcing —

Crossplane CQRS Event Sourcing

Crossplane Composition CQRS Event Sourcing Kubernetes Infrastructure Cloud AWS Azure GCP GitOps ArgoCD Audit Trail Production

เนื้อหาเกี่ยวข้อง — ดูเพิ่มเติมเรื่อง Calico Network Policy Docker Container Deploy

Crossplane Composition

# === Crossplane Composition Example ===



# CompositeResourceDefinition (XRD)

# apiVersion: apiextensions.crossplane.io/v1

# kind: CompositeResourceDefinition

# metadata:

#   name: xdatabases.platform.example.com

# spec:

#   group: platform.example.com

#   names:

#     kind: XDatabase

#     plural: xdatabases

#   claimNames:

#     kind: Database

#     plural: databases

#   versions:

#     - name: v1alpha1

#       schema:

#         openAPIV3Schema:

#           type: object

#           properties:

#             spec:

#               type: object

#               properties:

#                 engine: { type: string, enum: [postgres, mysql] }

#                 size: { type: string, enum: [small, medium, large] }

#                 region: { type: string }



# Composition

# apiVersion: apiextensions.crossplane.io/v1

# kind: Composition

# metadata:

#   name: xdatabase-aws

# spec:

#   compositeTypeRef:

#     apiVersion: platform.example.com/v1alpha1

#     kind: XDatabase

#   resources:

#     - name: rds-instance

#       base:

#         apiVersion: rds.aws.upbound.io/v1beta1

#         kind: Instance

#         spec:

#           forProvider:

#             engine: postgres

#             instanceClass: db.t3.medium

#             allocatedStorage: 20



from dataclasses import dataclass



@dataclass

class CompositionResource:

    claim_param: str

    small: str

    medium: str

    large: str



sizes = [

    CompositionResource("Instance Class",

        "db.t3.micro (2 vCPU 1GB)",

        "db.t3.medium (2 vCPU 4GB)",

        "db.r6g.large (2 vCPU 16GB)"),

    CompositionResource("Storage",

        "20GB gp3",

        "100GB gp3",

        "500GB io2"),

    CompositionResource("Backup Retention",

        "7 days",

        "14 days",

        "30 days"),

    CompositionResource("Multi-AZ",

        "false (Single AZ)",

        "true (Multi-AZ)",

        "true (Multi-AZ + Read Replica)"),

    CompositionResource("Monitoring",

        "Basic (CloudWatch)",

        "Enhanced (60s interval)",

        "Enhanced (1s) + Performance Insights"),

]



print("=== Database Composition Sizes ===")

for s in sizes:

    print(f"  [{s.claim_param}]")

    print(f"    Small: {s.small}")

    print(f"    Medium: {s.medium}")

    print(f"    Large: {s.large}")

CQRS + Event Sourcing

# === CQRS Event Sourcing for Infrastructure ===



# Event Types

# @dataclass

# class InfraEvent:

#     event_id: str

#     resource_id: str

#     event_type: str

#     payload: dict

#     user: str

#     timestamp: datetime

#

# events = [

#     InfraEvent("evt-001", "db-prod-01", "ResourceCreated",

#         {"engine": "postgres", "size": "medium", "region": "ap-southeast-1"},

#         "dev-team", datetime(2025,1,15,10,0)),

#     InfraEvent("evt-002", "db-prod-01", "ResourceScaled",

#         {"old_size": "medium", "new_size": "large", "reason": "traffic spike"},

#         "platform-team", datetime(2025,1,20,14,30)),

# ]



@dataclass

class EventType:

    event: str

    trigger: str

    payload: str

    read_model_update: str



events = [

    EventType("ResourceCreated",

        "Claim สร้างใหม่ → Crossplane สร้าง Resources",

        "resource_id engine size region team",

        "เพิ่ม Resource ใน Inventory + Dashboard"),

    EventType("ResourceUpdated",

        "Claim แก้ไข → Crossplane อัพเดท Resources",

        "resource_id old_config new_config changed_by",

        "อัพเดท Config History + Timeline"),

    EventType("ResourceScaled",

        "Scale Request → Composition Patch",

        "resource_id old_size new_size reason",

        "อัพเดท Capacity Dashboard + Cost"),

    EventType("ResourceFailed",

        "Crossplane detect Resource unhealthy",

        "resource_id error_message severity",

        "อัพเดท Health Dashboard + Alert"),

    EventType("DriftDetected",

        "Crossplane detect Configuration Drift",

        "resource_id expected_state actual_state",

        "อัพเดท Compliance Dashboard + Alert"),

    EventType("ResourceDeleted",

        "Claim ลบ → Crossplane ลบ Resources",

        "resource_id deleted_by reason",

        "ลบจาก Inventory + Archive Event"),

]



print("=== Infrastructure Events ===")

for e in events:

    print(f"  [{e.event}] Trigger: {e.trigger}")

    print(f"    Payload: {e.payload}")

    print(f"    Read Model: {e.read_model_update}")

Production Architecture

# === Production Stack ===



@dataclass

class ArchComponent:

    component: str

    tool: str

    role: str

    scaling: str



architecture = [

    ArchComponent("GitOps",

        "ArgoCD + Git Repository",

        "Source of Truth สำหรับ Crossplane Compositions Claims",

        "ArgoCD HA 3 replicas"),

    ArchComponent("Control Plane",

        "Crossplane + Providers",

        "Reconcile Claims → Cloud Resources",

        "Crossplane Pods HA + Provider Pods"),

    ArchComponent("Event Capture",

        "Custom Controller (Kubebuilder)",

        "Watch Crossplane Resources → Publish Events",

        "Controller HA 2 replicas"),

    ArchComponent("Event Store",

        "Apache Kafka (3 brokers)",

        "Store Infrastructure Events Durable Ordered",

        "Kafka Cluster 3+ brokers"),

    ArchComponent("Read Model",

        "PostgreSQL + Materialized Views",

        "Optimized Read Model สำหรับ Dashboard API",

        "PostgreSQL HA Primary + Replica"),

    ArchComponent("Dashboard",

        "Grafana + Custom UI (React)",

        "Infrastructure Inventory Timeline Audit Compliance",

        "Grafana HA + CDN for UI"),

]



print("=== Production Architecture ===")

for a in architecture:

    print(f"  [{a.component}] Tool: {a.tool}")

    print(f"    Role: {a.role}")

    print(f"    Scale: {a.scaling}")

เคล็ดลับ

• Composition: สร้าง Composition Template สำหรับทุก Resource ที่ใช้บ่อย
• Claim: ให้ Developer ใช้ Claim ไม่ต้องรู้ Implementation
• Events: เก็บทุก Event ใน Kafka สำหรับ Audit Trail
• GitOps: ใช้ ArgoCD Sync Crossplane Resources จาก Git
• Drift: ตรวจ Drift อัตโนมัติ Alert เมื่อ State ไม่ตรง

Crossplane คืออะไร

Open Source IaC Kubernetes API Cloud AWS Azure GCP Providers Compositions XRD Claim Self-service GitOps ArgoCD Multi-cloud
