CrewAI Multi-Agent Data Pipeline ETL

CrewAI Multi-Agent ETL

CrewAI Python Multi-Agent AI System Agents Role Goal Tools LLM ETL Extract Transform Load Data Pipeline Orchestration Airflow dbt Spark

CrewAI Agent Design

# === CrewAI ETL Pipeline ===

# pip install crewai crewai-tools

# from crewai import Agent, Task, Crew, Process
# from crewai_tools import (
#     FileReadTool, CSVSearchTool, JSONSearchTool,
#     DatabaseTool, WebScraperTool
# )
#
# # Define Agents
# extractor = Agent(
#     role="Data Extraction Specialist",
#     goal="Extract data from multiple sources accurately",
#     backstory="""You are an expert data engineer who specializes in
#     extracting data from APIs, databases, and files. You handle
#     pagination, rate limits, and error recovery.""",
#     tools=[WebScraperTool(), FileReadTool(), DatabaseTool()],
#     verbose=True,
#     allow_delegation=False,
# )
#
# validator = Agent(
#     role="Data Quality Analyst",
#     goal="Validate data quality and flag anomalies",
#     backstory="""You are a meticulous data quality analyst who checks
#     schema compliance, null values, duplicates, and business rules.
#     You never let bad data pass through.""",
#     tools=[CSVSearchTool()],
#     verbose=True,
# )
#
# transformer = Agent(
#     role="Data Transformation Engineer",
#     goal="Transform raw data into clean analytical format",
#     backstory="""You are a skilled data engineer who transforms messy
#     data into clean, normalized, enriched datasets ready for analysis.
#     You handle type casting, joins, and aggregations.""",
#     tools=[CSVSearchTool(), JSONSearchTool()],
#     verbose=True,
# )
#
# monitor = Agent(
#     role="Pipeline Monitor",
#     goal="Monitor pipeline health and report status",
#     backstory="""You monitor data pipeline execution, track metrics,
#     detect failures, and send alerts. You ensure SLA compliance.""",
#     verbose=True,
# )

from dataclasses import dataclass, field
from typing import List, Dict, Optional
from enum import Enum

class AgentStatus(Enum):
    IDLE = "idle"
    RUNNING = "running"
    COMPLETED = "completed"
    FAILED = "failed"

@dataclass
class ETLAgent:
    name: str
    role: str
    tools: List[str]
    status: AgentStatus = AgentStatus.IDLE
    records_processed: int = 0
    errors: int = 0

@dataclass
class ETLPipeline:
    name: str
    agents: List[ETLAgent] = field(default_factory=list)
    schedule: str = ""
    source: str = ""
    destination: str = ""

    def run(self):
        for agent in self.agents:
            agent.status = AgentStatus.RUNNING
            print(f"  Running: {agent.name} ({agent.role})")
            agent.status = AgentStatus.COMPLETED
            agent.records_processed = 1000

pipeline = ETLPipeline(
    name="daily-sales-etl",
    schedule="0 2 * * *",
    source="PostgreSQL + REST API",
    destination="BigQuery",
    agents=[
        ETLAgent("extractor", "Data Extraction", ["API Client", "DB Connector", "File Reader"]),
        ETLAgent("validator", "Data Quality", ["Schema Validator", "Rule Engine"]),
        ETLAgent("transformer", "Data Transform", ["Pandas", "SQL", "dbt"]),
        ETLAgent("loader", "Data Loading", ["BigQuery Client", "Bulk Insert"]),
        ETLAgent("monitor", "Pipeline Monitor", ["Prometheus", "Slack Alert"]),
    ],
)

print("=== ETL Pipeline ===")
print(f"  Name: {pipeline.name}")
print(f"  Schedule: {pipeline.schedule}")
print(f"  Source: {pipeline.source} -> Dest: {pipeline.destination}")
print(f"\n  Agents:")
for agent in pipeline.agents:
    print(f"    [{agent.name}] {agent.role} — Tools: {', '.join(agent.tools)}")

Task Orchestration

# === Task Orchestration ===

# from crewai import Task
#
# extract_task = Task(
#     description="""Extract sales data from the following sources:
#     1. PostgreSQL database (orders, products, customers tables)
#     2. REST API (inventory endpoint, paginated)
#     3. CSV files from SFTP server
#     Combine all data into a unified raw dataset.""",
#     expected_output="Raw dataset with all records from all sources",
#     agent=extractor,
# )
#
# validate_task = Task(
#     description="""Validate the extracted data:
#     1. Check schema compliance (column names, types)
#     2. Check for null values in required fields
#     3. Check for duplicates on primary keys
#     4. Validate business rules (price > 0, quantity >= 0)
#     5. Flag anomalies (values outside 3 std dev)""",
#     expected_output="Validation report with pass/fail and anomalies",
#     agent=validator,
#     context=[extract_task],
# )
#
# transform_task = Task(
#     description="""Transform validated data:
#     1. Normalize customer names (trim, title case)
#     2. Convert currencies to THB
#     3. Calculate derived fields (total, profit margin)
#     4. Join orders with products and customers
#     5. Aggregate daily summaries""",
#     expected_output="Clean transformed dataset ready for loading",
#     agent=transformer,
#     context=[validate_task],
# )
#
# # Create Crew
# crew = Crew(
#     agents=[extractor, validator, transformer, monitor],
#     tasks=[extract_task, validate_task, transform_task],
#     process=Process.sequential,
#     verbose=True,
# )
#
# result = crew.kickoff()

@dataclass
class TaskResult:
    task: str
    agent: str
    status: str
    records_in: int
    records_out: int
    duration_sec: float
    errors: int

results = [
    TaskResult("Extract", "extractor", "completed", 0, 50000, 120.5, 3),
    TaskResult("Validate", "validator", "completed", 50000, 49850, 45.2, 150),
    TaskResult("Transform", "transformer", "completed", 49850, 49850, 89.7, 0),
    TaskResult("Load", "loader", "completed", 49850, 49850, 30.1, 0),
    TaskResult("Monitor", "monitor", "completed", 0, 0, 5.0, 0),
]

print("\n=== Pipeline Execution Results ===")
total_time = 0
for r in results:
    total_time += r.duration_sec
    print(f"  [{r.status.upper()}] {r.task} by {r.agent}")
    print(f"    Records: {r.records_in} -> {r.records_out} | "
          f"Time: {r.duration_sec}s | Errors: {r.errors}")

print(f"\n  Total Time: {total_time:.1f}s ({total_time/60:.1f} min)")
print(f"  Final Records: {results[-2].records_out:,}")

# ETL vs ELT
comparison = {
    "ETL (Extract Transform Load)": {
        "flow": "Source -> Transform -> Warehouse",
        "transform": "ก่อนโหลด (ETL Server)",
        "use_case": "Legacy Systems, On-premise",
        "tools": "Informatica, Talend, SSIS",
    },
    "ELT (Extract Load Transform)": {
        "flow": "Source -> Warehouse -> Transform",
        "transform": "หลังโหลด (ใน Warehouse)",
        "use_case": "Cloud Warehouse, Big Data",
        "tools": "dbt, Fivetran, Airbyte + BigQuery/Snowflake",
    },
}

print(f"\n\nETL vs ELT:")
for approach, info in comparison.items():
    print(f"\n  [{approach}]")
    for k, v in info.items():
        print(f"    {k}: {v}")

Production Deployment

# === Production ETL Architecture ===

architecture = {
    "Orchestration": {
        "tools": "Apache Airflow, Prefect, Dagster",
        "desc": "กำหนด Schedule, Dependencies, Retry Logic",
    },
    "Data Sources": {
        "tools": "PostgreSQL, MySQL, REST API, S3, SFTP",
        "desc": "แหล่งข้อมูลต้นทาง หลายรูปแบบ",
    },
    "Processing": {
        "tools": "CrewAI Agents, Spark, Pandas, dbt",
        "desc": "Extract Validate Transform ด้วย AI Agents",
    },
    "Storage": {
        "tools": "BigQuery, Snowflake, Redshift, Delta Lake",
        "desc": "Data Warehouse สำหรับ Analytics",
    },
    "Monitoring": {
        "tools": "Prometheus, Grafana, PagerDuty, Slack",
        "desc": "ติดตาม Pipeline Health Alerts",
    },
    "Data Quality": {
        "tools": "Great Expectations, dbt tests, Soda",
        "desc": "ตรวจสอบคุณภาพข้อมูลอัตโนมัติ",
    },
}

print("Production ETL Architecture:")
for layer, info in architecture.items():
    print(f"\n  [{layer}]")
    print(f"    Tools: {info['tools']}")
    print(f"    {info['desc']}")

# Best Practices
practices = [
    "Idempotent — รันซ้ำได้ผลเหมือนเดิม",
    "Incremental — โหลดเฉพาะข้อมูลใหม่/เปลี่ยนแปลง",
    "Schema Evolution — รองรับ Schema เปลี่ยนแปลง",
    "Data Quality Checks — ตรวจทุกขั้นตอน",
    "Retry Logic — ลองใหม่อัตโนมัติเมื่อล้มเหลว",
    "Alerting — แจ้งเตือนทันทีเมื่อมีปัญหา",
    "Lineage — ติดตามที่มาของข้อมูล",
]

print(f"\n\nETL Best Practices:")
for i, p in enumerate(practices, 1):
    print(f"  {i}. {p}")

เคล็ดลับ

• Agent Design: แต่ละ Agent ทำหน้าที่เดียว Single Responsibility
• Idempotent: Pipeline รันซ้ำได้ผลเหมือนเดิม
• Incremental: โหลดเฉพาะข้อมูลที่เปลี่ยนแปลง ไม่ Full Load ทุกครั้ง
• Testing: ใช้ Great Expectations ตรวจ Data Quality ทุกขั้นตอน
• Monitoring: ตรวจ Row Count, Schema, Freshness ทุก Run

CrewAI คืออะไร

Python Framework Multi-Agent AI System Agents Role Goal Tools LLM Collaboration Task Orchestration งานซับซ้อนหลายทักษะ

สรุป

CrewAI Multi-Agent ETL Pipeline Extract Transform Load Agent Design Task Orchestration Data Quality Airflow dbt Spark Incremental Idempotent Monitoring Great Expectations Production
