Ceph Storage Cluster Hexagonal Architecture —

Hexagonal + Ceph

Ceph Storage Cluster Hexagonal Architecture Ports Adapters Pattern Domain Business Logic Storage Port Ceph Adapter S3 Local Testing Mock Production

Layer	Component	Responsibility	Dependencies	Testability
Domain	Business Logic	Storage Policy Validation	None (pure)	Unit Test easy
Port	StoragePort	Interface Contract	None (abstract)	Contract Test
Adapter	CephAdapter	Ceph RADOS/S3 access	librados/boto3	Integration Test
Adapter	S3Adapter	AWS S3 access	boto3	Integration Test
Adapter	LocalAdapter	Local filesystem	os module	Unit Test
Adapter	InMemoryAdapter	Testing only	dict	Unit Test fast

Domain and Ports

=== Hexagonal Architecture — Storage Domain ===

from abc import ABC, abstractmethod

from dataclasses import dataclass

from typing import Optional, List

from datetime import datetime

# --- Value Objects ---

@dataclass(frozen=True)

class StorageObject:

key: str

data: bytes

content_type: str

size: int

checksum: str

created_at: datetime

@dataclass(frozen=True)

class StorageMetadata:

key: str

size: int

content_type: str

last_modified: datetime

# --- Port (Interface) ---

class StoragePort(ABC):

@abstractmethod

def store(self, key: str, data: bytes, content_type: str) -> StorageObject:

pass

@abstractmethod

def retrieve(self, key: str) -> Optional[StorageObject]:

pass

@abstractmethod

def delete(self, key: str) -> bool:

pass

@abstractmethod

def list_objects(self, prefix: str = "") -> List[StorageMetadata]:

pass

@abstractmethod

def exists(self, key: str) -> bool:

pass

เนื้อหาเกี่ยวข้อง — ทำความเข้าใจ Prometheus Federation Stream Processing

# --- Domain Service ---

class StorageService:

def init(self, storage: StoragePort, max_size: int = 100_000_000):

self._storage = storage

self._max_size = max_size

def upload(self, key: str, data: bytes, content_type: str) -> StorageObject:

if len(data) > self._max_size:

raise ValueError(f"File too large: {len(data)} > {self._max_size}")

if not key or "/" not in key:

raise ValueError("Key must include bucket prefix: bucket/filename")

return self._storage.store(key, data, content_type)

def download(self, key: str) -> Optional[StorageObject]:

return self._storage.retrieve(key)

def remove(self, key: str) -> bool:

if not self._storage.exists(key):

raise FileNotFoundError(f"Object not found: {key}")

แนะนำเพิ่มเติม — หนังสือเทรดที่ SiamCafeBook

return self._storage.delete(key)

from dataclasses import dataclass

@dataclass

class PortMethod:

method: str

params: str

returns: str

description: str

methods = [

PortMethod("store", "key, data, content_type", "StorageObject", "Upload object to storage"),

PortMethod("retrieve", "key", "Optional[StorageObject]", "Download object by key"),

PortMethod("delete", "key", "bool", "Remove object from storage"),

PortMethod("list_objects", "prefix", "List[StorageMetadata]", "List objects by prefix"),

PortMethod("exists", "key", "bool", "Check if object exists"),

PortMethod("get_metadata", "key", "StorageMetadata", "Get object metadata only"),

]

print("=== StoragePort Interface ===")

for m in methods:

print(f" {m.method}({m.params}) -> {m.returns}")

print(f" Description: {m.description}")

Adapters

=== Storage Adapters ===

Ceph RADOS Adapter

import rados

เนื้อหาเกี่ยวข้อง — บทความที่เกี่ยวข้อง: Agile คืออะไร — คู่มือฉบับสมบูรณ์ 2026

class CephRadosAdapter(StoragePort):

def init(self, conf_file="/etc/ceph/ceph.conf", pool="data"):

self.cluster = rados.Rados(conffile=conf_file)

self.cluster.connect()

self.ioctx = self.cluster.open_ioctx(pool)

def store(self, key, data, content_type):

self.ioctx.write_full(key, data)

self.ioctx.set_xattr(key, "content-type", content_type.encode())

return StorageObject(key=key, data=data, ...)

def retrieve(self, key):

try:

size, _ = self.ioctx.stat(key)

data = self.ioctx.read(key, size)

ct = self.ioctx.get_xattr(key, "content-type").decode()

return StorageObject(key=key, data=data, content_type=ct, ...)

except rados.ObjectNotFound:

return None

S3 Adapter (Ceph RGW or AWS S3)

import boto3

class S3Adapter(StoragePort):

def init(self, endpoint, access_key, secret_key, bucket):

self.s3 = boto3.client("s3",

endpoint_url=endpoint,

aws_access_key_id=access_key,

แนะนำเพิ่มเติม — ติดตาม XM Signal

aws_secret_access_key=secret_key)

self.bucket = bucket

def store(self, key, data, content_type):

self.s3.put_object(Bucket=self.bucket, Key=key,

Body=data, ContentType=content_type)

return StorageObject(...)

In-Memory Adapter (for testing)

class InMemoryAdapter(StoragePort):

def init(self):

self._store = {}

def store(self, key, data, content_type):

obj = StorageObject(key=key, data=data, content_type=content_type, ...)

self._store[key] = obj

return obj

def retrieve(self, key):

return self._store.get(key)

@dataclass

class AdapterComparison:

adapter: str

backend: str

เนื้อหาเกี่ยวข้อง — อ่านต่อ: Delta Lake SSL TLS Certificate —

performance: str

use_case: str

config: str

adapters = [

AdapterComparison("CephRadosAdapter", "Ceph RADOS", "Very high (native)", "Production high-perf", "ceph.conf + pool name"),

AdapterComparison("CephS3Adapter", "Ceph RGW (S3)", "High", "Production S3-compatible", "endpoint + keys + bucket"),

AdapterComparison("AWSS3Adapter", "AWS S3", "High (network)", "Cloud production", "region + keys + bucket"),

AdapterComparison("LocalAdapter", "Local filesystem", "Fast (disk)", "Development", "base_path directory"),

AdapterComparison("InMemoryAdapter", "Python dict", "Very fast", "Unit testing", "None"),

AdapterComparison("MinioAdapter", "MinIO S3", "High", "Self-hosted S3", "endpoint + keys + bucket"),

]

print("\n=== Adapter Comparison ===")

for a in adapters:

print(f" [{a.adapter}] Backend: {a.backend}")

print(f" Perf: {a.performance} | Use: {a.use_case}")

print(f" Config: {a.config}")

Testing Strategy

=== Testing Hexagonal Storage ===

Unit Test — Domain with Mock

def test_upload_validates_size():

storage = InMemoryAdapter()

service = StorageService(storage, max_size=1000)

with pytest.raises(ValueError):

service.upload("bucket/file.txt", b"x" * 1001, "text/plain")

def test_upload_validates_key():

storage = InMemoryAdapter()

service = StorageService(storage)

with pytest.raises(ValueError):

service.upload("no-bucket", b"data", "text/plain")

def test_upload_stores_object():

storage = InMemoryAdapter()

service = StorageService(storage)

result = service.upload("bucket/test.txt", b"hello", "text/plain")

assert result.key == "bucket/test.txt"

assert storage.exists("bucket/test.txt")

Integration Test — Real Ceph

เนื้อหาเกี่ยวข้อง — ทำความเข้าใจ HTTP/3 QUIC GreenOps Sustainability —

@pytest.fixture

def ceph_adapter():

adapter = CephS3Adapter(

endpoint="http://ceph-rgw:7480",

access_key="test", secret_key="test", bucket="test-bucket")

yield adapter

# Cleanup

def test_ceph_store_retrieve(ceph_adapter):

ceph_adapter.store("test/file.txt", b"hello", "text/plain")

obj = ceph_adapter.retrieve("test/file.txt")

assert obj.data == b"hello"

@dataclass

class TestType:

test_type: str

adapter_used: str

speed: str

coverage: str

ci_friendly: bool

test_types = [

TestType("Unit Test (Domain)", "InMemoryAdapter", "< 1ms", "Business logic", True),

TestType("Unit Test (Adapter)", "InMemoryAdapter", "< 1ms", "Adapter logic", True),

TestType("Contract Test", "All Adapters", "Varies", "Port compliance", True),

TestType("Integration Test", "CephS3Adapter", "100-500ms", "Real Ceph access", False),

TestType("E2E Test", "Production Adapter", "1-5s", "Full flow", False),

TestType("Performance Test", "CephRadosAdapter", "Minutes", "Throughput latency", False),

]

print("Testing Strategy:")

for t in test_types:

ci = "CI-friendly" if t.ci_friendly else "Requires infra"

print(f" [{t.test_type}] Adapter: {t.adapter_used}")

print(f" Speed: {t.speed} | Coverage: {t.coverage} | {ci}")

เคล็ดลับ

Port First: ออกแบบ Port ก่อน แล้วค่อยสร้าง Adapter
InMemory: ใช้ InMemoryAdapter สำหรับ Unit Test เร็วมาก
Config: เปลี่ยน Adapter ผ่าน Config ไม่แก้ Code
Contract: ทดสอบ Contract ทุก Adapter ต้อง Pass เหมือนกัน
Domain Pure: Domain ไม่ Import External Library เด็ดขาด

Hexagonal Architecture คืออะไร

Ports Adapters Pattern แยก Domain จาก External Port Interface Adapter Implementation เปลี่ยน Adapter ไม่กระทบ Domain ทดสอบง่าย Mock
