Ceph Cost Optimization

Ceph Storage Cluster Cost Optimization Erasure Coding Replication Tiering Compression HDD SSD NVMe CRUSH OSD RBD RGW CephFS Kubernetes OpenStack

Cluster Design

# === Ceph Cluster Design ===

# Hardware Recommendations
# OSD Nodes (Storage):
#   CPU: 2x Intel Xeon 16-core
#   RAM: 128GB (16GB per OSD recommended)
#   HDD: 12x 16TB SATA (for capacity)
#   SSD: 2x 1TB NVMe (for WAL+DB)
#   Network: 2x 25GbE (public + cluster)
#
# Monitor Nodes:
#   CPU: 8-core
#   RAM: 32GB
#   SSD: 500GB NVMe
#   Network: 10GbE
#   Count: 3 or 5 (odd number)
#
# Manager Nodes (co-located with MON):
#   Dashboard, Prometheus, Grafana

# ceph.conf
# [global]
# fsid = a1b2c3d4-e5f6-7890-abcd-ef1234567890
# mon_initial_members = mon1, mon2, mon3
# mon_host = 10.0.0.1, 10.0.0.2, 10.0.0.3
# public_network = 10.0.0.0/24
# cluster_network = 10.0.1.0/24
#
# [osd]
# osd_memory_target = 4294967296  # 4GB per OSD
# bluestore_cache_size = 3221225472  # 3GB
# osd_max_backfills = 2
# osd_recovery_max_active = 2

from dataclasses import dataclass

@dataclass
class ClusterNode:
    role: str
    count: int
    cpu_cores: int
    ram_gb: int
    storage: str
    network: str
    cost_per_node: float

nodes = [
    ClusterNode("OSD (HDD)", 6, 32, 128, "12x 16TB HDD + 2x 1TB NVMe", "2x 25GbE", 8000),
    ClusterNode("OSD (SSD)", 3, 16, 64, "8x 4TB NVMe", "2x 25GbE", 12000),
    ClusterNode("MON/MGR", 3, 8, 32, "500GB NVMe", "10GbE", 2000),
    ClusterNode("RGW (S3)", 2, 8, 32, "500GB NVMe", "25GbE", 2500),
]

print("=== Cluster Hardware ===")
total_cost = 0
for n in nodes:
    cost = n.cost_per_node * n.count
    total_cost += cost
    print(f"  [{n.role}] x{n.count}")
    print(f"    CPU: {n.cpu_cores}c | RAM: {n.ram_gb}GB | Storage: {n.storage}")
    print(f"    Network: {n.network} | Cost: ")
print(f"\n  Total Hardware: ")

Erasure Coding และ Compression

# === Erasure Coding & Compression ===

# Create EC Pool
# ceph osd erasure-code-profile set ec-4-2 \
#   k=4 m=2 \
#   crush-failure-domain=host
# ceph osd pool create ec-data 128 erasure ec-4-2
# ceph osd pool set ec-data allow_ec_overwrites true
#
# # Enable Compression
# ceph osd pool set ec-data compression_algorithm zstd
# ceph osd pool set ec-data compression_mode aggressive
# ceph osd pool set ec-data compression_required_ratio 0.875
#
# # Create Replicated Pool (for hot data)
# ceph osd pool create hot-data 64 replicated
# ceph osd pool set hot-data size 3 min_size 2
#
# # CRUSH Rules — Separate SSD and HDD
# ceph osd crush rule create-replicated ssd-rule default host ssd
# ceph osd crush rule create-replicated hdd-rule default host hdd
# ceph osd pool set hot-data crush_rule ssd-rule
# ceph osd pool set ec-data crush_rule hdd-rule

@dataclass
class StorageSaving:
    strategy: str
    raw_tb: float
    usable_tb: float
    savings_pct: float
    monthly_cost: float

# Example: 100TB raw data
savings = [
    StorageSaving("3x Replication (baseline)", 300, 100, 0, 3000),
    StorageSaving("2x Replication", 200, 100, 33, 2000),
    StorageSaving("EC k=4 m=2", 150, 100, 50, 1500),
    StorageSaving("EC k=4 m=2 + Compression", 105, 100, 65, 1050),
    StorageSaving("EC k=8 m=3 + Compression", 96, 100, 68, 960),
]

print("\n=== Cost Savings (100TB usable) ===")
for s in savings:
    print(f"  [{s.strategy}]")
    print(f"    Raw: {s.raw_tb}TB | Usable: {s.usable_tb}TB | Savings: {s.savings_pct}% | Cost: /mo")

Monitoring และ Capacity

# === Monitoring & Capacity Planning ===

# Ceph Dashboard
# ceph mgr module enable dashboard
# ceph dashboard create-self-signed-cert
# ceph dashboard ac-user-create admin -i /tmp/password administrator

# Prometheus Integration
# ceph mgr module enable prometheus
# # Scrape endpoint: http://mgr-host:9283/metrics

# Key Metrics to Monitor
# - ceph_osd_utilization (target < 75%)
# - ceph_pool_stored_raw (actual data)
# - ceph_osd_apply_latency_ms (target < 10ms SSD, < 50ms HDD)
# - ceph_osd_commit_latency_ms
# - ceph_pg_degraded (should be 0)
# - ceph_health_status (HEALTH_OK)

# Capacity Planning
# ceph df detail
# ceph osd df tree

@dataclass
class PoolMetric:
    pool: str
    type: str
    stored_tb: float
    raw_tb: float
    usage_pct: float
    iops: int
    latency_ms: float

pools = [
    PoolMetric("kubernetes-rbd", "3x Replica", 8.5, 25.5, 72, 15000, 2.5),
    PoolMetric("object-storage", "EC 4+2", 45.0, 67.5, 58, 3000, 8.0),
    PoolMetric("backup-archive", "EC 8+3", 120.0, 165.0, 65, 500, 25.0),
    PoolMetric("cephfs-data", "3x Replica", 5.0, 15.0, 45, 8000, 3.0),
    PoolMetric("vm-images", "2x Replica", 12.0, 24.0, 60, 5000, 5.0),
]

print("Pool Dashboard:")
total_stored = 0
total_raw = 0
for p in pools:
    total_stored += p.stored_tb
    total_raw += p.raw_tb
    print(f"  [{p.pool}] {p.type}")
    print(f"    Stored: {p.stored_tb}TB | Raw: {p.raw_tb}TB | Usage: {p.usage_pct}%")
    print(f"    IOPS: {p.iops:,} | Latency: {p.latency_ms}ms")

print(f"\n  Total Stored: {total_stored:.1f}TB | Total Raw: {total_raw:.1f}TB")
print(f"  Effective Ratio: {total_raw/total_stored:.2f}x")

# Cost Optimization Checklist
checklist = [
    "EC สำหรับ Object Storage และ Archive ลด 50%+",
    "Compression zstd สำหรับ Text/Log Data ลด 30-50%",
    "CRUSH Tiering: SSD Hot / HDD Cold",
    "PG Autoscaler เปิด ไม่ต้อง Manual",
    "OSD Memory Target ปรับตาม RAM ที่มี",
    "Network แยก Public/Cluster ลด Congestion",
    "Capacity Alert ตั้งที่ 75% วางแผนซื้อล่วงหน้า",
]

print(f"\n\nOptimization Checklist:")
for i, c in enumerate(checklist, 1):
    print(f"  {i}. {c}")

เคล็ดลับ

• EC: ใช้ Erasure Coding สำหรับ Cold Data ประหยัด 50%+
• Compression: เปิด zstd Compression ลดอีก 30%
• Tiering: SSD สำหรับ Hot Data HDD สำหรับ Cold Data
• Monitor: ดู OSD Utilization ไม่เกิน 75%
• Network: แยก Public/Cluster Network ใช้ 25GbE
