Weights Biases Hexagonal Architecture

Weights & Biases Hexagonal Architecture คืออะไร

Weights & Biases (W&B) เป็น MLOps platform สำหรับ experiment tracking, model versioning, dataset management และ collaboration ในทีม ML Hexagonal Architecture (Ports and Adapters) เป็นรูปแบบการออกแบบซอฟต์แวร์ที่แยก business logic ออกจาก external dependencies ผ่าน ports (interfaces) และ adapters (implementations) การรวมสองแนวคิดนี้ช่วยสร้าง ML systems ที่ testable, maintainable และเปลี่ยน infrastructure ได้ง่าย เช่น สลับจาก W&B ไป MLflow โดยไม่แก้ core logic

Hexagonal Architecture Fundamentals

# hexagonal.py — Hexagonal Architecture for ML
import json

class HexagonalArchitecture:
    LAYERS = {
        "domain": {
            "name": "Domain (Core Business Logic)",
            "description": "ML training logic, model evaluation, data processing — ไม่ depend บน framework ใดๆ",
            "examples": "TrainingService, ModelEvaluator, DataProcessor",
            "rule": "ไม่ import external libraries โดยตรง — ใช้ interfaces",
        },
        "ports": {
            "name": "Ports (Interfaces)",
            "description": "Contracts ที่ domain กำหนด — external world ต้อง implement",
            "types": {
                "inbound": "Driving ports — UI, API, CLI เรียกเข้ามา (e.g., TrainModelUseCase)",
                "outbound": "Driven ports — domain เรียกออกไป (e.g., ExperimentTracker, ModelRegistry)",
            },
        },
        "adapters": {
            "name": "Adapters (Implementations)",
            "description": "Concrete implementations ของ ports — connect กับ external systems",
            "types": {
                "inbound": "FastAPI controller, CLI handler, Airflow DAG",
                "outbound": "WandbTracker, MLflowTracker, S3ModelStore, LocalFileStore",
            },
        },
    }

    def show_layers(self):
        print("=== Hexagonal Architecture ===\n")
        for key, layer in self.LAYERS.items():
            print(f"[{layer['name']}]")
            print(f"  {layer['description']}")
            if 'types' in layer:
                for t, desc in layer['types'].items():
                    print(f"  {t}: {desc}")
            print()

hex_arch = HexagonalArchitecture()
hex_arch.show_layers()

Ports — Interfaces

# ports.py — Port definitions (interfaces)
from abc import ABC, abstractmethod
from dataclasses import dataclass
from typing import Dict, List, Optional
import numpy as np

# Domain Models
@dataclass
class Experiment:
    name: str
    config: Dict
    tags: Dict[str, str] = None

@dataclass
class MetricLog:
    name: str
    value: float
    step: int

@dataclass
class ModelArtifact:
    name: str
    version: str
    path: str
    metrics: Dict[str, float]

# Outbound Ports (Driven)
class ExperimentTrackerPort(ABC):
    """Port สำหรับ track experiments — W&B, MLflow, etc."""

    @abstractmethod
    def init_experiment(self, experiment: Experiment) -> str:
        """Initialize experiment run, return run_id"""
        pass

    @abstractmethod
    def log_metrics(self, metrics: Dict[str, float], step: int) -> None:
        pass

    @abstractmethod
    def log_params(self, params: Dict) -> None:
        pass

    @abstractmethod
    def log_artifact(self, path: str, name: str) -> None:
        pass

    @abstractmethod
    def finish(self) -> None:
        pass

class ModelRegistryPort(ABC):
    """Port สำหรับ model versioning"""

    @abstractmethod
    def register_model(self, artifact: ModelArtifact) -> str:
        pass

    @abstractmethod
    def get_model(self, name: str, version: str) -> ModelArtifact:
        pass

    @abstractmethod
    def promote_model(self, name: str, version: str, stage: str) -> None:
        pass

class DataLoaderPort(ABC):
    """Port สำหรับ load data"""

    @abstractmethod
    def load_train_data(self) -> tuple:
        pass

    @abstractmethod
    def load_test_data(self) -> tuple:
        pass

# Inbound Ports (Driving)
class TrainModelUseCase(ABC):
    """Use case: Train a model"""

    @abstractmethod
    def execute(self, config: Dict) -> ModelArtifact:
        pass

class EvaluateModelUseCase(ABC):
    """Use case: Evaluate a model"""

    @abstractmethod
    def execute(self, model_name: str, version: str) -> Dict[str, float]:
        pass

print("Ports defined — ready for adapter implementations")

W&B Adapter

# wandb_adapter.py — Weights & Biases adapter
import json

class WandbAdapter:
    CODE = """
# adapters/wandb_tracker.py
import wandb
from ports import ExperimentTrackerPort, Experiment

class WandbExperimentTracker(ExperimentTrackerPort):
    def __init__(self, project: str, entity: str = None):
        self.project = project
        self.entity = entity
        self.run = None

    def init_experiment(self, experiment: Experiment) -> str:
        self.run = wandb.init(
            project=self.project,
            entity=self.entity,
            name=experiment.name,
            config=experiment.config,
            tags=list(experiment.tags.values()) if experiment.tags else None,
        )
        return self.run.id

    def log_metrics(self, metrics: dict, step: int) -> None:
        wandb.log(metrics, step=step)

    def log_params(self, params: dict) -> None:
        wandb.config.update(params)

    def log_artifact(self, path: str, name: str) -> None:
        artifact = wandb.Artifact(name, type='model')
        artifact.add_file(path)
        self.run.log_artifact(artifact)

    def finish(self) -> None:
        if self.run:
            wandb.finish()

# adapters/wandb_registry.py
class WandbModelRegistry(ModelRegistryPort):
    def __init__(self, project: str, entity: str = None):
        self.api = wandb.Api()
        self.project = project
        self.entity = entity

    def register_model(self, artifact: ModelArtifact) -> str:
        run = wandb.init(project=self.project, job_type='register')
        art = wandb.Artifact(artifact.name, type='model')
        art.add_file(artifact.path)
        art.metadata = artifact.metrics
        run.log_artifact(art)
        wandb.finish()
        return f"{artifact.name}:latest"

    def get_model(self, name: str, version: str) -> ModelArtifact:
        artifact = self.api.artifact(f"{self.entity}/{self.project}/{name}:{version}")
        path = artifact.download()
        return ModelArtifact(name=name, version=version, path=path, metrics=artifact.metadata)

    def promote_model(self, name: str, version: str, stage: str) -> None:
        artifact = self.api.artifact(f"{self.entity}/{self.project}/{name}:{version}")
        artifact.aliases.append(stage)
        artifact.save()
"""

    MLFLOW_ADAPTER = """
# adapters/mlflow_tracker.py — Alternative adapter
import mlflow

class MLflowExperimentTracker(ExperimentTrackerPort):
    def __init__(self, tracking_uri: str):
        mlflow.set_tracking_uri(tracking_uri)

    def init_experiment(self, experiment: Experiment) -> str:
        mlflow.set_experiment(experiment.name)
        run = mlflow.start_run()
        mlflow.log_params(experiment.config)
        return run.info.run_id

    def log_metrics(self, metrics: dict, step: int) -> None:
        mlflow.log_metrics(metrics, step=step)

    def log_params(self, params: dict) -> None:
        mlflow.log_params(params)

    def log_artifact(self, path: str, name: str) -> None:
        mlflow.log_artifact(path)

    def finish(self) -> None:
        mlflow.end_run()
"""

    def show_wandb(self):
        print("=== W&B Adapter ===")
        print(self.CODE[:600])

    def show_mlflow(self):
        print(f"\n=== MLflow Adapter (swap!) ===")
        print(self.MLFLOW_ADAPTER[:400])

adapter = WandbAdapter()
adapter.show_wandb()
adapter.show_mlflow()

Domain Service — Training

# domain_service.py — Core training service
import json

class DomainService:
    CODE = """
# domain/training_service.py — Core ML training logic
from ports import (
    ExperimentTrackerPort, ModelRegistryPort,
    DataLoaderPort, TrainModelUseCase,
    Experiment, ModelArtifact
)

class TrainingService(TrainModelUseCase):
    '''Core training logic — ไม่ depend บน W&B, MLflow, etc.'''

    def __init__(
        self,
        tracker: ExperimentTrackerPort,
        registry: ModelRegistryPort,
        data_loader: DataLoaderPort,
    ):
        self.tracker = tracker
        self.registry = registry
        self.data_loader = data_loader

    def execute(self, config: dict) -> ModelArtifact:
        # 1. Init experiment
        experiment = Experiment(
            name=config.get('experiment_name', 'default'),
            config=config,
            tags={'type': 'training'}
        )
        run_id = self.tracker.init_experiment(experiment)
        self.tracker.log_params(config)

        # 2. Load data
        X_train, y_train = self.data_loader.load_train_data()
        X_test, y_test = self.data_loader.load_test_data()

        # 3. Train model (framework-agnostic logic)
        model = self._build_model(config)

        for epoch in range(config.get('epochs', 10)):
            loss = self._train_epoch(model, X_train, y_train)
            val_metrics = self._evaluate(model, X_test, y_test)

            # Log via port — ไม่สนว่าเป็น W&B หรือ MLflow
            self.tracker.log_metrics({
                'train_loss': loss,
                **val_metrics
            }, step=epoch)

        # 4. Save & register model
        model_path = self._save_model(model, config)
        self.tracker.log_artifact(model_path, 'trained_model')

        artifact = ModelArtifact(
            name=config['model_name'],
            version='latest',
            path=model_path,
            metrics=val_metrics,
        )
        self.registry.register_model(artifact)

        # 5. Cleanup
        self.tracker.finish()
        return artifact

    def _build_model(self, config):
        # Pure domain logic — no external dependencies
        pass

    def _train_epoch(self, model, X, y):
        # Training logic
        return 0.5  # loss

    def _evaluate(self, model, X, y):
        return {'accuracy': 0.95, 'f1': 0.93}

    def _save_model(self, model, config):
        return f"/tmp/{config['model_name']}.pkl"
"""

    COMPOSITION_ROOT = """
# main.py — Composition root (dependency injection)
from domain.training_service import TrainingService
from adapters.wandb_tracker import WandbExperimentTracker, WandbModelRegistry
from adapters.csv_data_loader import CSVDataLoader

# Wire dependencies — เปลี่ยน adapter ที่นี่จุดเดียว
tracker = WandbExperimentTracker(project='my-ml-project')
registry = WandbModelRegistry(project='my-ml-project')
data_loader = CSVDataLoader(train_path='data/train.csv', test_path='data/test.csv')

# Inject into domain service
training_service = TrainingService(
    tracker=tracker,
    registry=registry,
    data_loader=data_loader,
)

# Execute — domain ไม่รู้เลยว่าใช้ W&B
result = training_service.execute({
    'model_name': 'classifier_v1',
    'experiment_name': 'baseline',
    'epochs': 50,
    'learning_rate': 0.001,
    'batch_size': 32,
})

# เปลี่ยนเป็น MLflow? แก้แค่ composition root!
# tracker = MLflowExperimentTracker(tracking_uri='http://mlflow:5000')
# registry = MLflowModelRegistry(tracking_uri='http://mlflow:5000')
"""

    def show_code(self):
        print("=== Training Service ===")
        print(self.CODE[:600])

    def show_composition(self):
        print(f"\n=== Composition Root ===")
        print(self.COMPOSITION_ROOT[:500])

ds = DomainService()
ds.show_code()
ds.show_composition()

Testing Strategy

# testing.py — Testing hexagonal ML system
import json

class TestingStrategy:
    CODE = """
# tests/test_training_service.py
import pytest
from domain.training_service import TrainingService
from ports import ExperimentTrackerPort, ModelRegistryPort, DataLoaderPort

# Fake adapters for testing — ไม่ต้อง connect W&B จริง!
class FakeTracker(ExperimentTrackerPort):
    def __init__(self):
        self.logged_metrics = []
        self.logged_params = {}
        self.artifacts = []

    def init_experiment(self, experiment):
        return 'fake-run-id'

    def log_metrics(self, metrics, step):
        self.logged_metrics.append({'metrics': metrics, 'step': step})

    def log_params(self, params):
        self.logged_params.update(params)

    def log_artifact(self, path, name):
        self.artifacts.append({'path': path, 'name': name})

    def finish(self):
        pass

class FakeRegistry(ModelRegistryPort):
    def __init__(self):
        self.models = {}

    def register_model(self, artifact):
        self.models[artifact.name] = artifact
        return f"{artifact.name}:v1"

    def get_model(self, name, version):
        return self.models.get(name)

    def promote_model(self, name, version, stage):
        pass

class FakeDataLoader(DataLoaderPort):
    def load_train_data(self):
        import numpy as np
        return np.random.randn(100, 10), np.random.randint(0, 2, 100)

    def load_test_data(self):
        import numpy as np
        return np.random.randn(20, 10), np.random.randint(0, 2, 20)

# Tests — fast, no external dependencies!
class TestTrainingService:
    def setup_method(self):
        self.tracker = FakeTracker()
        self.registry = FakeRegistry()
        self.data_loader = FakeDataLoader()
        self.service = TrainingService(
            tracker=self.tracker,
            registry=self.registry,
            data_loader=self.data_loader,
        )

    def test_training_logs_metrics(self):
        config = {'model_name': 'test_model', 'epochs': 5, 'learning_rate': 0.01}
        result = self.service.execute(config)

        assert len(self.tracker.logged_metrics) == 5  # 5 epochs
        assert 'learning_rate' in self.tracker.logged_params

    def test_training_registers_model(self):
        config = {'model_name': 'test_model', 'epochs': 3}
        result = self.service.execute(config)

        assert 'test_model' in self.registry.models
        assert result.name == 'test_model'

    def test_training_logs_artifact(self):
        config = {'model_name': 'test_model', 'epochs': 1}
        self.service.execute(config)

        assert len(self.tracker.artifacts) == 1
"""

    def show_tests(self):
        print("=== Testing Strategy ===")
        print(self.CODE[:600])

    def benefits(self):
        print(f"\n=== Hexagonal Testing Benefits ===")
        benefits = [
            "Fast tests — ไม่ต้อง connect W&B/MLflow จริง (fake adapters)",
            "Isolated — test domain logic โดยไม่มี external dependencies",
            "Deterministic — fake data ให้ผลเหมือนกันทุกรอบ",
            "CI/CD friendly — ไม่ต้อง API keys, ไม่ต้อง network",
            "Swappable — เปลี่ยน W&B → MLflow → test ผ่านหมด (same ports)",
        ]
        for b in benefits:
            print(f"  • {b}")

test = TestingStrategy()
test.show_tests()
test.benefits()

FAQ - คำถามที่พบบ่อย

Q: Hexagonal Architecture จำเป็นสำหรับ ML projects ไหม?

A: ไม่จำเป็นทุก project: Small/POC: ไม่จำเป็น — เขียนตรงๆ เร็วกว่า Production ML systems: แนะนำมาก — เปลี่ยน tracking tool, data source, model store ได้ง่าย Team projects: จำเป็น — แบ่ง responsibilities ชัดเจน, test ง่าย กฎ: ถ้า project มีแนวโน้มจะเปลี่ยน infrastructure → ใช้ Hexagonal

Q: W&B กับ MLflow อันไหนดี?

A: W&B: UI สวย, collaboration ดีมาก, hosted (ไม่ต้อง manage), team features MLflow: Open source, self-hosted, free, customizable, community ใหญ่ W&B: เหมาะ teams ที่ต้องการ managed solution ($) MLflow: เหมาะ teams ที่ต้องการ control + ไม่มี budget ด้วย Hexagonal: เปลี่ยนได้ตลอด — ไม่ต้อง commit วันนี้

Q: Ports and Adapters ทำให้ code ซับซ้อนขึ้นไหม?

A: เพิ่ม boilerplate เล็กน้อย (interfaces + adapters) แต่: Tests เร็วขึ้น 10x (fake adapters), เปลี่ยน infrastructure ง่าย, team เข้าใจ boundaries ชัด, debug ง่ายกว่า Trade-off คุ้ม: เพิ่ม code 20% แต่ลด maintenance cost 50%+

Q: Dependency Injection ใน Python ทำยังไง?

A: Simple: Constructor injection (ส่ง dependencies ผ่าน __init__) Libraries: dependency-injector, inject, python-inject Recommended: Constructor injection สำหรับ ML projects — simple, explicit, ไม่ต้อง framework เพิ่ม ใน Composition Root (main.py): wire ทุก dependencies จุดเดียว
