Vector Database Pinecone Remote Work Setup —

Vector Database Pinecone

Vector Database Pinecone Embedding Semantic Search RAG LLM Cosine Similarity Remote Work Knowledge Base AI Chatbot Weaviate Qdrant Milvus Chroma

Vector DB	Type	Free Tier	Scale	เหมาะกับ
Pinecone	Managed	มี	Billion	Production SaaS
Weaviate	Self/Cloud	มี	Billion	Hybrid Search
Qdrant	Self/Cloud	มี	Billion	Performance
Chroma	Self-hosted	ฟรี	Million	Dev/Prototype
pgvector	PostgreSQL ext	ฟรี	Million	Existing PG

Pinecone Setup

=== Pinecone Vector Database ===

pip install pinecone-client openai langchain

import os

from pinecone import Pinecone, ServerlessSpec

import openai

# Initialize Pinecone

pc = Pinecone(api_key=os.environ["PINECONE_API_KEY"])

# Create Index

pc.create_index(

name="company-knowledge",

dimension=1536, # OpenAI text-embedding-3-small

metric="cosine",

spec=ServerlessSpec(

cloud="aws",

region="us-east-1"

)

)

index = pc.Index("company-knowledge")

# Generate Embedding

def get_embedding(text, model="text-embedding-3-small"):

response = openai.embeddings.create(

input=text,

model=model

)

return response.data[0].embedding

# Upsert Documents

documents = [

{"id": "doc1", "text": "วิธีขอลาพักร้อน ส่ง Email ถึง HR..."},

{"id": "doc2", "text": "นโยบาย Remote Work ทำงาน 8 ชม/วัน..."},

{"id": "doc3", "text": "วิธีเข้าใช้ VPN เปิด Cisco AnyConnect..."},

]

vectors = []

for doc in documents:

embedding = get_embedding(doc["text"])

vectors.append({

"id": doc["id"],

"values": embedding,

"metadata": {"text": doc["text"], "source": "wiki"}

})

index.upsert(vectors=vectors, namespace="hr-docs")

# Semantic Search

query = "วิธีทำงานจากบ้าน"

query_embedding = get_embedding(query)

results = index.query(

vector=query_embedding,

top_k=3,

namespace="hr-docs",

include_metadata=True

)

for match in results["matches"]:

print(f"Score: {match['score']:.3f} | {match['metadata']['text'][:80]}")

from dataclasses import dataclass

@dataclass

class VectorIndex:

name: str

dimension: int

vectors: int

namespace: str

queries_day: int

avg_latency_ms: int

indexes = [

VectorIndex("company-knowledge", 1536, 15000, "hr-docs", 500, 25),

VectorIndex("company-knowledge", 1536, 8000, "engineering", 1200, 20),

VectorIndex("company-knowledge", 1536, 3000, "meeting-notes", 300, 22),

VectorIndex("product-docs", 1536, 25000, "user-guides", 2000, 18),

VectorIndex("support-tickets", 1536, 50000, "resolved", 800, 30),

]

print("=== Pinecone Indexes ===")

for idx in indexes:

print(f" [{idx.name}] ns:{idx.namespace}")

print(f" Vectors: {idx.vectors:,} | Dim: {idx.dimension}")

print(f" Queries: {idx.queries_day}/day | Latency: {idx.avg_latency_ms}ms")

RAG Pipeline

=== RAG with LangChain ===

from langchain.embeddings import OpenAIEmbeddings

from langchain.vectorstores import Pinecone

from langchain.chat_models import ChatOpenAI

from langchain.chains import RetrievalQA

from langchain.text_splitter import RecursiveCharacterTextSplitter

# Setup

embeddings = OpenAIEmbeddings(model="text-embedding-3-small")

vectorstore = Pinecone.from_existing_index(

index_name="company-knowledge",

embedding=embeddings,

namespace="hr-docs"

)

# RAG Chain

llm = ChatOpenAI(model="gpt-4o-mini", temperature=0)

qa_chain = RetrievalQA.from_chain_type(

llm=llm,

chain_type="stuff",

retriever=vectorstore.as_retriever(

search_kwargs={"k": 5}

),

return_source_documents=True

)

# Query

result = qa_chain.invoke({"query": "วิธีขอลาพักร้อน"})

print(result["result"])

for doc in result["source_documents"]:

print(f" Source: {doc.metadata['source']}")

Document Ingestion Pipeline

1. Read documents (PDF, Markdown, Notion, Confluence)

2. Split into chunks (500-1000 tokens)

3. Generate embeddings

4. Upsert to Pinecone with metadata

5. Schedule re-index weekly

@dataclass

class RAGApp:

name: str

knowledge_source: str

vectors: int

queries_day: int

accuracy: float

users: int

apps = [

RAGApp("HR Assistant", "HR Wiki + Policy Docs", 15000, 200, 0.92, 150),

RAGApp("Engineering Docs", "Confluence + GitHub Wiki", 25000, 500, 0.89, 80),

RAGApp("Customer Support", "FAQ + Ticket History", 50000, 1000, 0.95, 30),

RAGApp("Meeting Search", "Meeting Transcripts", 8000, 150, 0.85, 120),

RAGApp("Onboarding Guide", "Onboarding Docs + Videos", 5000, 50, 0.91, 20),

]

print("\n=== RAG Applications ===")

for a in apps:

print(f" [{a.name}] {a.users} users")

print(f" Source: {a.knowledge_source}")

print(f" Vectors: {a.vectors:,} | Queries: {a.queries_day}/day | Acc: {a.accuracy:.0%}")

Remote Work Integration

=== Remote Work Knowledge Platform ===

Slack Bot Integration

from slack_bolt import App

app = App(token=os.environ["SLACK_BOT_TOKEN"])

@app.message(re.compile(r"^ask (.+)"))

def handle_question(message, say, context):

question = context["matches"][0]

result = qa_chain.invoke({"query": question})

answer = result["result"]

sources = [d.metadata["source"] for d in result["source_documents"]]

say(f"*Answer:* {answer}\n_Sources: {', '.join(sources)}_")

API Server — FastAPI

from fastapi import FastAPI

app = FastAPI()

@app.post("/search")

async def search(query: str, namespace: str = "all"):

embedding = get_embedding(query)

results = index.query(

vector=embedding, top_k=5,

namespace=namespace,

include_metadata=True

)

return {"results": results["matches"]}

@app.post("/ask")

async def ask(question: str):

result = qa_chain.invoke({"query": question})

return {"answer": result["result"]}

remote_tools = {

"Slack Bot": "ถามคำถามใน Slack ได้ทันที @ask-bot",

"Web Search": "Search Portal ค้นหาเอกสารทั้งองค์กร",

"API": "FastAPI Endpoint สำหรับ Integration",

"Chrome Extension": "ค้นหาจากทุก Tab ด้วย Extension",

"Mobile App": "ค้นหาจากมือถือ Progressive Web App",

"Teams Bot": "Integration กับ Microsoft Teams",

}

print("Remote Work Tools:")

for tool, desc in remote_tools.items():

print(f" [{tool}]: {desc}")

cost_estimate = {

"Pinecone Serverless": "$0.00 (Free Tier: 100K vectors)",

"Pinecone Standard": "$70/mo (1M vectors)",

"OpenAI Embeddings": "$0.02/1M tokens (~$5/mo)",

"OpenAI GPT-4o-mini": "$0.15/1M input tokens (~$15/mo)",

"Total (Small Team)": "~$90/month",

"Total (Enterprise)": "~$500-2000/month",

}

print(f"\n\nCost Estimate:")

for item, cost in cost_estimate.items():

print(f" {item}: {cost}")

เคล็ดลับ

• Chunk: แบ่ง Document เป็น Chunk 500-1000 tokens
• Namespace: แยก Namespace ตาม Category
• Metadata: เก็บ Metadata สำหรับ Filter
• Re-index: อัพเดท Index สม่ำเสมอเมื่อ Doc เปลี่ยน
• Hybrid: ใช้ Hybrid Search (Vector + Keyword) ดีกว่า

Vector Database คืออะไร

ฐานข้อมูล Vector Embedding Semantic Search AI LLM RAG Cosine Similarity Text Image Audio Pinecone Weaviate Qdrant Milvus Chroma
