Uptime Kuma Monitoring Multi-tenant Design

Uptime Kuma

Uptime Kuma Monitoring Multi-tenant Self-hosted Uptime HTTP TCP Ping DNS Docker Notification Telegram Slack Status Page Dashboard Real-time

Installation

# === Uptime Kuma Installation ===

# Docker (Recommended)
# docker run -d \
#   --name uptime-kuma \
#   --restart=always \
#   -p 3001:3001 \
#   -v uptime-kuma:/app/data \
#   louislam/uptime-kuma:latest

# Docker Compose
# version: '3.8'
# services:
#   uptime-kuma:
#     image: louislam/uptime-kuma:latest
#     container_name: uptime-kuma
#     restart: always
#     ports:
#       - "3001:3001"
#     volumes:
#       - uptime-kuma-data:/app/data
#     environment:
#       - NODE_ENV=production
#
# volumes:
#   uptime-kuma-data:

# Nginx Reverse Proxy
# server {
#     listen 443 ssl http2;
#     server_name status.example.com;
#
#     ssl_certificate /etc/letsencrypt/live/status.example.com/fullchain.pem;
#     ssl_certificate_key /etc/letsencrypt/live/status.example.com/privkey.pem;
#
#     location / {
#         proxy_pass http://localhost:3001;
#         proxy_http_version 1.1;
#         proxy_set_header Upgrade $http_upgrade;
#         proxy_set_header Connection "upgrade";
#         proxy_set_header Host $host;
#         proxy_set_header X-Real-IP $remote_addr;
#     }
# }

# Node.js (Without Docker)
# git clone https://github.com/louislam/uptime-kuma.git
# cd uptime-kuma
# npm run setup
# npm run start-server

from dataclasses import dataclass

@dataclass
class MonitorConfig:
    name: str
    monitor_type: str
    url: str
    interval: int
    retry: int
    notification: str
    tags: str

monitors = [
    MonitorConfig("Main Website", "HTTP", "https://www.example.com", 30, 3, "Telegram + Slack", "tenant-a, web"),
    MonitorConfig("API Server", "HTTP", "https://api.example.com/health", 20, 3, "PagerDuty", "tenant-a, api"),
    MonitorConfig("Database", "TCP", "db.example.com:5432", 30, 5, "Slack", "tenant-a, db"),
    MonitorConfig("DNS", "DNS", "example.com (A record)", 60, 3, "Email", "tenant-a, infra"),
    MonitorConfig("Backup Job", "Push", "Push URL (heartbeat)", 3600, 1, "Telegram", "tenant-a, cron"),
    MonitorConfig("Tenant B Web", "HTTP", "https://www.tenant-b.com", 30, 3, "Discord", "tenant-b, web"),
]

print("=== Monitor Configurations ===")
for m in monitors:
    print(f"  [{m.name}] Type: {m.monitor_type}")
    print(f"    URL: {m.url}")
    print(f"    Interval: {m.interval}s | Retry: {m.retry} | Notify: {m.notification}")
    print(f"    Tags: {m.tags}")

Multi-tenant Architecture

# === Multi-tenant Monitoring Design ===

# Approach 1: Single Instance + Tags
# - Use Tags to separate tenants
# - Create Tag per tenant: tenant-a, tenant-b, tenant-c
# - Assign monitors to tenant tags
# - Status Pages per tenant (built-in feature)
# - Pro: Simple, low resource
# - Con: No data isolation, shared admin

# Approach 2: Instance per Tenant (Docker)
# docker-compose.yml per tenant
# services:
#   uptime-kuma-tenant-a:
#     image: louislam/uptime-kuma:latest
#     ports: ["3001:3001"]
#     volumes: [tenant-a-data:/app/data]
#   uptime-kuma-tenant-b:
#     image: louislam/uptime-kuma:latest
#     ports: ["3002:3001"]
#     volumes: [tenant-b-data:/app/data]

# Approach 3: Kubernetes per Tenant
# apiVersion: apps/v1
# kind: Deployment
# metadata:
#   name: uptime-kuma-{{ tenant }}
#   namespace: monitoring
# spec:
#   replicas: 1
#   template:
#     spec:
#       containers:
#         - name: uptime-kuma
#           image: louislam/uptime-kuma:latest
#           ports: [{containerPort: 3001}]
#           volumeMounts:
#             - name: data
#               mountPath: /app/data

@dataclass
class TenantApproach:
    approach: str
    isolation: str
    complexity: str
    resource: str
    max_tenants: str
    use_case: str

approaches = [
    TenantApproach("Single + Tags", "Low (shared DB)", "ง่าย", "1 instance", "5-10", "Small team internal"),
    TenantApproach("Instance per Tenant", "High (separate DB)", "ปานกลาง", "1 container/tenant", "10-50", "MSP small"),
    TenantApproach("K8s per Tenant", "High (separate Pod)", "สูง", "1 Pod/tenant", "50-200", "MSP large"),
    TenantApproach("API Automation", "High + Automated", "สูง", "Dynamic", "200+", "SaaS platform"),
]

print("\n=== Multi-tenant Approaches ===")
for a in approaches:
    print(f"  [{a.approach}] Isolation: {a.isolation}")
    print(f"    Complexity: {a.complexity} | Resource: {a.resource}")
    print(f"    Max Tenants: {a.max_tenants} | Use Case: {a.use_case}")

Notification and Status Page

# === Notification Configuration ===

# Telegram Bot Setup
# 1. Create bot: @BotFather → /newbot
# 2. Get token: 123456:ABC-DEF
# 3. Get chat_id: curl https://api.telegram.org/bot{TOKEN}/getUpdates
# 4. Add in Uptime Kuma: Notification → Telegram
#    Bot Token: 123456:ABC-DEF
#    Chat ID: -1001234567890

# Slack Webhook
# 1. Create Slack App → Incoming Webhooks
# 2. Get URL: https://hooks.slack.com/services/T.../B.../xxx
# 3. Add in Uptime Kuma: Notification → Slack

# Status Page API (Automation)
# curl -X POST http://localhost:3001/api/status-page \
#   -H "Content-Type: application/json" \
#   -H "Authorization: Bearer YOUR_API_KEY" \
#   -d '{
#     "slug": "tenant-a",
#     "title": "Tenant A Status",
#     "description": "System status for Tenant A",
#     "showPoweredBy": false
#   }'

@dataclass
class NotificationChannel:
    channel: str
    setup: str
    latency: str
    reliability: str
    use_case: str

channels = [
    NotificationChannel("Telegram", "Bot Token + Chat ID", "1-3s", "สูงมาก", "Team chat alert"),
    NotificationChannel("Slack", "Webhook URL", "1-3s", "สูงมาก", "DevOps channel"),
    NotificationChannel("Discord", "Webhook URL", "1-3s", "สูง", "Community team"),
    NotificationChannel("Email", "SMTP config", "5-30s", "สูง", "Management report"),
    NotificationChannel("LINE Notify", "Access Token", "1-3s", "สูง", "Thai team"),
    NotificationChannel("PagerDuty", "Integration Key", "1-2s", "สูงมาก", "On-call rotation"),
    NotificationChannel("Webhook", "Custom URL", "1-5s", "ตาม Server", "Custom integration"),
]

print("Notification Channels:")
for c in channels:
    print(f"  [{c.channel}] Setup: {c.setup}")
    print(f"    Latency: {c.latency} | Reliability: {c.reliability}")
    print(f"    Use Case: {c.use_case}")

sla_targets = {
    "Website Uptime": "99.9% (8.76h downtime/year)",
    "API Uptime": "99.95% (4.38h downtime/year)",
    "Database": "99.99% (52.56min downtime/year)",
    "Check Interval": "20-30 seconds",
    "Alert Response": "< 5 minutes",
    "Incident Resolution": "< 1 hour (P1)",
}

print(f"\n\nSLA Targets:")
for k, v in sla_targets.items():
    print(f"  [{k}]: {v}")

เคล็ดลับ

• Docker: ใช้ Docker ติดตั้ง ง่าย Update ง่าย
• Tags: ใช้ Tags แยก Tenant สำหรับ Single Instance
• Status Page: สร้าง Status Page แยกตาม Tenant
• Backup: Backup /app/data ทุกวัน SQLite ไฟล์เดียว
• Notification: ตั้ง Notification หลายช่องทาง ป้องกันพลาด

Uptime Kuma คืออะไร

Open Source Self-hosted Monitoring HTTP TCP Ping DNS Docker Push Notification Telegram Slack Status Page Dashboard Real-time ฟรี

สรุป

Uptime Kuma Monitoring Multi-tenant Self-hosted HTTP TCP Ping DNS Docker Notification Telegram Slack Status Page Tags Instance Kubernetes Production
