Uptime Kuma Monitoring MLOps Workflow

Uptime Kuma MLOps

Uptime Kuma Open Source Self-hosted Monitoring MLOps Workflow ML Pipeline Health Check Alert Telegram Slack Discord Status Page Docker Heartbeat Push Monitor

Installation และ Setup

# === Uptime Kuma Setup ===

# Docker — Single Command
# docker run -d \
#   --restart=always \
#   --name uptime-kuma \
#   -p 3001:3001 \
#   -v uptime-kuma:/app/data \
#   louislam/uptime-kuma:1

# Docker Compose — Production
# version: "3"
# services:
#   uptime-kuma:
#     image: louislam/uptime-kuma:1
#     container_name: uptime-kuma
#     restart: always
#     ports:
#       - "3001:3001"
#     volumes:
#       - ./data:/app/data
#     environment:
#       - NODE_EXTRA_CA_CERTS=/app/data/certs/ca.pem
#
#   caddy:
#     image: caddy:2
#     ports:
#       - "80:80"
#       - "443:443"
#     volumes:
#       - ./Caddyfile:/etc/caddy/Caddyfile
#     depends_on:
#       - uptime-kuma

# Caddyfile — Auto SSL
# status.example.com {
#   reverse_proxy uptime-kuma:3001
# }

# API — Create Monitor Programmatically
# import requests
#
# KUMA_URL = "http://localhost:3001"
# TOKEN = "your-api-token"
#
# def create_monitor(name, url, monitor_type="http"):
#     response = requests.post(
#         f"{KUMA_URL}/api/monitors",
#         headers={"Authorization": f"Bearer {TOKEN}"},
#         json={
#             "name": name,
#             "url": url,
#             "type": monitor_type,
#             "interval": 60,
#             "retryInterval": 30,
#             "maxretries": 3,
#             "accepted_statuscodes": ["200-299"],
#         }
#     )
#     return response.json()

from dataclasses import dataclass

@dataclass
class Monitor:
    name: str
    type: str
    target: str
    interval: int
    uptime_30d: float
    avg_ms: int
    status: str

monitors = [
    Monitor("ML API /predict", "HTTP", "https://ml.example.com/predict", 30, 99.95, 85, "Up"),
    Monitor("ML API /health", "HTTP", "https://ml.example.com/health", 60, 99.99, 12, "Up"),
    Monitor("Model Registry", "HTTP", "https://mlflow.example.com", 60, 99.90, 150, "Up"),
    Monitor("GPU Server SSH", "TCP", "gpu-01:22", 60, 99.85, 5, "Up"),
    Monitor("Training Pipeline", "Push", "Heartbeat every 1h", 3600, 98.5, 0, "Up"),
    Monitor("Inference GPU", "TCP", "gpu-02:8080", 30, 99.92, 8, "Up"),
    Monitor("Data Pipeline", "Push", "Heartbeat every 6h", 21600, 99.0, 0, "Up"),
]

print("=== Uptime Kuma Monitors ===")
for m in monitors:
    print(f"  [{m.status}] {m.name} ({m.type})")
    print(f"    Target: {m.target} | Interval: {m.interval}s")
    print(f"    Uptime: {m.uptime_30d}% | Avg: {m.avg_ms}ms")

MLOps Monitoring

# === MLOps Workflow Monitoring ===

# Push Monitor — Training Pipeline Heartbeat
# import requests
#
# PUSH_URL = "https://status.example.com/api/push/abc123"
#
# def report_training_step(epoch, loss, accuracy):
#     """Send heartbeat after each training epoch"""
#     msg = f"Epoch {epoch}: loss={loss:.4f}, acc={accuracy:.4f}"
#     requests.get(f"{PUSH_URL}?status=up&msg={msg}&ping=")
#
# def report_training_failed(error):
#     """Report training failure"""
#     requests.get(f"{PUSH_URL}?status=down&msg={error}")
#
# # In training loop:
# for epoch in range(100):
#     loss, acc = train_epoch(model, dataloader)
#     report_training_step(epoch, loss, acc)
#
# # Keyword Monitor — Check Model Version
# # Monitor URL: https://ml.example.com/health
# # Expected keyword: "model_version":"v2.1"
# # Alert if model version changed unexpectedly

# HTTP Monitor — Inference Latency
# Monitor: https://ml.example.com/predict
# Method: POST
# Body: {"text": "test input"}
# Expected status: 200
# Max response time: 500ms (alert if exceeded)

@dataclass
class MLWorkflow:
    stage: str
    monitor_type: str
    check: str
    alert_condition: str
    severity: str

workflows = [
    MLWorkflow("Data Ingestion", "Push", "Heartbeat ทุก 1h", "Missing > 2h", "Warning"),
    MLWorkflow("Feature Engineering", "Push", "Heartbeat ทุก 30m", "Missing > 1h", "Warning"),
    MLWorkflow("Model Training", "Push", "Heartbeat ทุก Epoch", "Missing > 2h", "Critical"),
    MLWorkflow("Model Evaluation", "HTTP", "Eval endpoint", "Score < threshold", "Critical"),
    MLWorkflow("Model Registry", "HTTP", "MLflow /health", "Down > 3min", "High"),
    MLWorkflow("Model Serving", "HTTP", "/predict latency", "p99 > 500ms", "Critical"),
    MLWorkflow("GPU Health", "TCP", "GPU server port", "Unreachable", "Critical"),
    MLWorkflow("Data Quality", "Push", "DQ check ทุก 6h", "Missing > 12h", "Warning"),
]

print("\n=== MLOps Workflow Monitors ===")
for w in workflows:
    print(f"  [{w.severity}] {w.stage}")
    print(f"    Type: {w.monitor_type} | Check: {w.check}")
    print(f"    Alert: {w.alert_condition}")

Alert และ Status Page

# === Alert Configuration ===

# Telegram Alert
# Bot Token: from @BotFather
# Chat ID: from @userinfobot
# Setup in Uptime Kuma: Settings > Notifications > Telegram

# Line Notify
# Token: from https://notify-bot.line.me/
# Setup: Notifications > Line Notify > Token

# Discord Webhook
# URL: Server Settings > Integrations > Webhooks
# Setup: Notifications > Discord > Webhook URL

# Status Page
# Uptime Kuma > Status Pages > New
# Public URL: https://status.example.com
# Groups:
#   - ML API Services
#   - Training Pipeline
#   - Infrastructure
# Custom Domain + SSL via Caddy/Nginx

@dataclass
class AlertChannel:
    channel: str
    setup: str
    speed: str
    use_case: str
    enabled: bool

channels = [
    AlertChannel("Telegram", "Bot Token + Chat ID", "< 5s", "Primary on-call", True),
    AlertChannel("Slack", "Webhook URL", "< 5s", "Team channel", True),
    AlertChannel("Discord", "Webhook URL", "< 5s", "Dev team", True),
    AlertChannel("Line Notify", "Token", "< 10s", "Thai team", True),
    AlertChannel("Email", "SMTP config", "< 60s", "Management", True),
    AlertChannel("PagerDuty", "Integration key", "< 5s", "Critical only", False),
    AlertChannel("Webhook", "Custom URL", "< 5s", "Automation", True),
]

print("Alert Channels:")
for c in channels:
    status = "ON" if c.enabled else "OFF"
    print(f"  [{status}] {c.channel}")
    print(f"    Setup: {c.setup} | Speed: {c.speed} | Use: {c.use_case}")

# Maintenance Window
maintenance = [
    "ตั้ง Maintenance Window ก่อน Deploy ป้องกัน False Alert",
    "ใช้ API ตั้ง Maintenance อัตโนมัติจาก CI/CD",
    "Status Page แสดง Scheduled Maintenance ให้ลูกค้า",
    "Backup Data ทุกวัน /app/data/kuma.db",
    "Update Image ทุกเดือน docker pull louislam/uptime-kuma:1",
]

print(f"\n\nMaintenance Tips:")
for i, m in enumerate(maintenance, 1):
    print(f"  {i}. {m}")

เคล็ดลับ

• Docker: ติดตั้ง Docker คำสั่งเดียว ง่ายมาก
• Push: ใช้ Push Monitor สำหรับ ML Pipeline Heartbeat
• Keyword: ตรวจ Model Version ใน Health Response
• SSL: ใช้ Caddy Auto SSL สำหรับ Status Page
• Backup: Backup kuma.db ทุกวัน สำคัญมาก

การนำไปใช้งานจริงในองค์กร

สำหรับองค์กรขนาดกลางถึงใหญ่ แนะนำให้ใช้หลัก Three-Tier Architecture คือ Core Layer ที่เป็นแกนกลางของระบบ Distribution Layer ที่ทำหน้าที่กระจาย Traffic และ Access Layer ที่เชื่อมต่อกับผู้ใช้โดยตรง การแบ่ง Layer ชัดเจนช่วยให้การ Troubleshoot ง่ายขึ้นและสามารถ Scale ระบบได้ตามความต้องการ

เรื่อง Network Security ก็สำคัญไม่แพ้กัน ควรติดตั้ง Next-Generation Firewall ที่สามารถ Deep Packet Inspection ได้ ใช้ Network Segmentation แยก VLAN สำหรับแต่ละแผนก ติดตั้ง IDS/IPS เพื่อตรวจจับการโจมตี และทำ Regular Security Audit อย่างน้อยปีละ 2 ครั้ง

สรุป

Uptime Kuma Self-hosted Monitoring MLOps Workflow Push Heartbeat HTTP TCP Alert Telegram Slack Discord Line Status Page Docker Caddy SSL Production Pipeline
