TensorRT Optimization Remote Work Setup

TensorRT Remote Work

TensorRT Optimization Remote Work GPU Inference Model Conversion INT8 Calibration SSH Tunnel JupyterLab VS Code Remote Tailscale Production

Precision	Model Size	Speedup	Accuracy Loss	Use Case
FP32	100% (baseline)	1x	0%	Development, baseline
FP16	50%	2-3x	< 0.1%	Production default
INT8	25%	3-5x	< 1%	High throughput, edge
INT4 (TRT-LLM)	12.5%	4-8x	1-3%	LLM inference

Remote Development Environment

=== Remote GPU Server Setup ===

Install NVIDIA Driver + CUDA + TensorRT

sudo apt update && sudo apt install -y nvidia-driver-535

sudo apt install -y nvidia-cuda-toolkit

pip install tensorrt nvidia-tensorrt

Install JupyterLab

pip install jupyterlab ipywidgets

jupyter lab --ip 0.0.0.0 --port 8888 --no-browser

SSH config (~/.ssh/config on local machine)

Host gpu-server

HostName 192.168.1.100 # or public IP / Tailscale IP

User dev

Port 22

IdentityFile ~/.ssh/id_rsa

LocalForward 8888 localhost:8888 # JupyterLab

LocalForward 6006 localhost:6006 # TensorBoard

LocalForward 3000 localhost:3000 # Grafana

ServerAliveInterval 60

ServerAliveCountMax 3

VS Code Remote SSH

1. Install "Remote - SSH" extension

2. Ctrl+Shift+P > "Remote-SSH: Connect to Host"

3. Select "gpu-server"

4. Install Python extension on remote

Tailscale VPN (zero-config)

curl -fsSL https://tailscale.com/install.sh | sh

sudo tailscale up

ssh dev@gpu-server # Use Tailscale hostname

tmux for long-running jobs

tmux new -s training

python train.py # Start training

Ctrl+B, D # Detach

tmux attach -t training # Re-attach later

from dataclasses import dataclass

@dataclass

class RemoteTool:

tool: str

purpose: str

port: str

setup: str

tools = [

RemoteTool("SSH", "Remote terminal access", "22", "ssh-keygen + authorized_keys"),

RemoteTool("JupyterLab", "Interactive notebooks", "8888", "pip install jupyterlab"),

RemoteTool("VS Code Remote", "Full IDE remote", "SSH", "Remote-SSH extension"),

RemoteTool("TensorBoard", "Training visualization", "6006", "tensorboard --logdir runs/"),

RemoteTool("Grafana", "GPU monitoring dashboard", "3000", "Docker + nvidia-smi exporter"),

RemoteTool("Tailscale", "Secure VPN access", "N/A", "curl install + tailscale up"),

RemoteTool("tmux", "Persistent sessions", "N/A", "apt install tmux"),

]

print("=== Remote Tools ===")

for t in tools:

print(f" [{t.tool}] Purpose: {t.purpose}")

print(f" Port: {t.port} | Setup: {t.setup}")

TensorRT Conversion

=== Model Conversion Pipeline ===

Step 1: PyTorch to ONNX

import torch

model = MyModel().eval().cuda()

dummy = torch.randn(1, 3, 224, 224).cuda()

torch.onnx.export(model, dummy, "model.onnx",

input_names=["input"], output_names=["output"],

dynamic_axes={"input": {0: "batch"}, "output": {0: "batch"}},

opset_version=17)

Step 2: ONNX to TensorRT (CLI)

trtexec --onnx=model.onnx \

--saveEngine=model_fp16.trt \

--fp16 \

--minShapes=input:1x3x224x224 \

--optShapes=input:8x3x224x224 \

--maxShapes=input:32x3x224x224 \

--workspace=4096

Step 3: INT8 with Calibration

trtexec --onnx=model.onnx \

--saveEngine=model_int8.trt \

--int8 \

--calib=calibration_cache.bin \

--minShapes=input:1x3x224x224 \

--optShapes=input:8x3x224x224 \

--maxShapes=input:32x3x224x224

Python API — Custom INT8 Calibrator

import tensorrt as trt

import numpy as np

class MyCalibrator(trt.IInt8EntropyCalibrator2):

def init(self, data_loader, cache_file="calib.cache"):

super().__init__()

self.data_loader = iter(data_loader)

self.cache_file = cache_file

self.batch_size = 8

self.device_input = cuda.mem_alloc(

self.batch_size * 3 * 224 * 224 * 4)

def get_batch_size(self):

return self.batch_size

def get_batch(self, names):

try:

batch = next(self.data_loader)

cuda.memcpy_htod(self.device_input, batch.numpy())

return [int(self.device_input)]

except StopIteration:

return None

@dataclass

class ConversionResult:

model: str

original: str

fp16: str

int8: str

speedup_fp16: str

speedup_int8: str

results = [

ConversionResult("ResNet-50", "4.2ms", "1.8ms", "1.1ms", "2.3x", "3.8x"),

ConversionResult("BERT-base", "6.5ms", "3.1ms", "1.9ms", "2.1x", "3.4x"),

ConversionResult("YOLOv8-L", "12.3ms", "5.2ms", "3.1ms", "2.4x", "4.0x"),

ConversionResult("Whisper-small", "450ms", "180ms", "95ms", "2.5x", "4.7x"),

ConversionResult("Stable Diffusion", "8.5s", "3.2s", "N/A", "2.7x", "N/A"),

]

print("\n=== Benchmark Results (T4 GPU) ===")

for r in results:

print(f" [{r.model}] FP32: {r.original} | FP16: {r.fp16} | INT8: {r.int8}")

print(f" Speedup: FP16 {r.speedup_fp16} | INT8 {r.speedup_int8}")

Production Deployment

=== Production Inference Server ===

Triton Inference Server with TensorRT

docker run --gpus all -p 8000:8000 -p 8001:8001 -p 8002:8002 \

-v $(pwd)/model_repository:/models \

nvcr.io/nvidia/tritonserver:24.01-py3 \

tritonserver --model-repository=/models

model_repository/

└── my_model/

├── config.pbtxt

└── 1/

└── model.plan # TensorRT engine

config.pbtxt

platform: "tensorrt_plan"

max_batch_size: 32

input [{

data_type: TYPE_FP32

dims: [3, 224, 224]

}]

output [{

data_type: TYPE_FP32

dims: [1000]

}]

instance_group [{

kind: KIND_GPU

}]

dynamic_batching {

max_queue_delay_microseconds: 100

}

@dataclass

class MonitorMetric:

metric: str

target: str

alert: str

tool: str

metrics = [

MonitorMetric("GPU Utilization", "60-80%", "> 90% or < 30%", "nvidia-smi + Prometheus"),

MonitorMetric("GPU Temperature", "< 80°C", "> 85°C", "nvidia-smi exporter"),

MonitorMetric("GPU Memory", "< 90%", "> 95%", "nvidia-smi exporter"),

MonitorMetric("Inference Latency p99", "< 10ms (ResNet)", "> 20ms", "Triton metrics"),

MonitorMetric("Throughput", "> 500 req/s", "< 300 req/s", "Triton metrics"),

MonitorMetric("Error Rate", "< 0.1%", "> 0.5%", "Application metrics"),

MonitorMetric("Power Usage", "< 250W (T4)", "> 280W", "nvidia-smi"),

]

print("Monitoring:")

for m in metrics:

print(f" [{m.metric}] Target: {m.target}")

print(f" Alert: {m.alert} | Tool: {m.tool}")

เคล็ดลับ

FP16: เริ่มด้วย FP16 ก่อน ได้ 2-3x speedup แทบไม่เสีย Accuracy
Tailscale: ใช้ Tailscale VPN เข้าถึง GPU Server จากทุกที่ ไม่ต้อง Port Forward
tmux: รัน Training ใน tmux ปิด SSH ได้โดย Training ไม่หยุด
Profile: ใช้ trtexec --verbose วิเคราะห์ Layer Performance
Cache: เก็บ TensorRT Engine File ไว้ ไม่ต้อง Build ใหม่ทุกครั้ง

TensorRT คืออะไร

NVIDIA SDK Inference Graph Optimization Precision FP32 FP16 INT8 Kernel Auto-tuning ONNX PyTorch TensorFlow 2-5x Production Edge Autonomous
