TensorRT Pub/Sub Architecture

TensorRT NVIDIA Inference Optimization Pub/Sub Kafka Triton GPU FP16 INT8 Dynamic Batching Kubernetes Scale Production

เนื้อหาเกี่ยวข้อง — ดูเพิ่มเติมเรื่อง Monte Carlo Observability Data Pipeline ETL —

TensorRT Engine Build

# === TensorRT Optimization Pipeline ===

# Convert PyTorch → ONNX → TensorRT
# import torch
# import tensorrt as trt
#
# # Step 1: Export PyTorch to ONNX
# model = MyModel()
# model.load_state_dict(torch.load("model.pth"))
# model.eval()
# dummy_input = torch.randn(1, 3, 224, 224).cuda()
# torch.onnx.export(model, dummy_input, "model.onnx",
#     input_names=["input"], output_names=["output"],
#     dynamic_axes={"input": {0: "batch"}, "output": {0: "batch"}})
#
# # Step 2: Build TensorRT Engine
# # trtexec --onnx=model.onnx --saveEngine=model.engine \
# #   --fp16 --minShapes=input:1x3x224x224 \
# #   --optShapes=input:8x3x224x224 \
# #   --maxShapes=input:32x3x224x224

from dataclasses import dataclass

@dataclass
class OptimizationStep:
    step: str
    command: str
    speedup: str
    note: str

steps = [
    OptimizationStep("Export to ONNX",
        "torch.onnx.export(model, dummy, 'model.onnx')",
        "N/A (preparation)",
        "ใช้ dynamic_axes สำหรับ Dynamic Batch"),
    OptimizationStep("Build FP16 Engine",
        "trtexec --onnx=model.onnx --fp16 --saveEngine=model_fp16.engine",
        "2x faster than FP32",
        "แนะนำเปิดเสมอ Accuracy แทบไม่ลด"),
    OptimizationStep("Build INT8 Engine",
        "trtexec --onnx=model.onnx --int8 --calib=calibration_data",
        "4x faster than FP32",
        "ต้อง Calibrate ด้วย Representative Data 1000+ samples"),
    OptimizationStep("Dynamic Shape",
        "trtexec --minShapes=input:1x3x224x224 --maxShapes=input:32x3x224x224",
        "Flexible Batch Size",
        "Engine รองรับ Batch 1-32 อัตโนมัติ"),
    OptimizationStep("Benchmark",
        "trtexec --loadEngine=model.engine --batch=8 --iterations=1000",
        "วัด Latency Throughput",
        "ทดสอบก่อน Deploy ดู P99 Latency"),
]

print("=== TensorRT Optimization Steps ===")
for s in steps:
    print(f"  [{s.step}]")
    print(f"    Command: {s.command}")
    print(f"    Speedup: {s.speedup}")
    print(f"    Note: {s.note}")

Pub/Sub Integration

# === Pub/Sub Inference Architecture ===

# Kafka Producer (Client)
# from kafka import KafkaProducer
# producer = KafkaProducer(bootstrap_servers='kafka:9092')
# producer.send('inference-requests', value=json.dumps({
#     "request_id": "uuid-123",
#     "model": "resnet50",
#     "input": base64_image,
#     "callback_topic": "inference-results"
# }).encode())

# Kafka Consumer (TensorRT Worker)
# from kafka import KafkaConsumer
# consumer = KafkaConsumer('inference-requests',
#     group_id='tensorrt-workers', bootstrap_servers='kafka:9092')
# for message in consumer:
#     request = json.loads(message.value)
#     result = tensorrt_infer(request["input"])
#     producer.send(request["callback_topic"], value=json.dumps({
#         "request_id": request["request_id"],
#         "prediction": result
#     }).encode())

@dataclass
class PubSubComponent:
    component: str
    role: str
    technology: str
    scaling: str

architecture = [
    PubSubComponent("API Gateway",
        "รับ Request จาก Client ส่งไป Pub/Sub",
        "FastAPI / Kong / AWS API Gateway",
        "HPA ตาม Request Rate"),
    PubSubComponent("Request Topic",
        "Queue สำหรับ Inference Requests",
        "Kafka Topic (partitions=8)",
        "เพิ่ม Partitions ตาม Throughput"),
    PubSubComponent("TensorRT Workers",
        "Consumer ดึง Request → Infer → Publish Result",
        "Python + TensorRT + Kafka Consumer",
        "Scale ตาม Queue Lag (KEDA)"),
    PubSubComponent("Result Topic",
        "Queue สำหรับ Inference Results",
        "Kafka Topic (partitions=8)",
        "Match กับ Request Topic"),
    PubSubComponent("Result Consumer",
        "ดึง Result ส่งกลับ Client (WebSocket/Callback)",
        "FastAPI WebSocket / Webhook",
        "HPA ตาม Connection Count"),
]

print("=== Pub/Sub Architecture ===")
for c in architecture:
    print(f"  [{c.component}] Role: {c.role}")
    print(f"    Tech: {c.technology}")
    print(f"    Scale: {c.scaling}")

Production Deployment

# === Kubernetes + Triton + Kafka ===

# Triton Inference Server Deployment
# apiVersion: apps/v1
# kind: Deployment
# metadata:
#   name: triton-tensorrt
# spec:
#   replicas: 2
#   template:
#     spec:
#       containers:
#         - name: triton
#           image: nvcr.io/nvidia/tritonserver:24.01-py3
#           args: ["tritonserver", "--model-repository=/models"]
#           resources:
#             limits:
#               nvidia.com/gpu: 1
#               memory: "16Gi"
#           ports:
#             - containerPort: 8000  # HTTP
#             - containerPort: 8001  # gRPC
#             - containerPort: 8002  # Metrics

@dataclass
class DeployMetric:
    metric: str
    target: str
    scale_action: str
    monitor: str

metrics = [
    DeployMetric("GPU Utilization",
        "60-80% (Optimal)",
        "Scale Up Workers ถ้า > 80% Scale Down ถ้า < 40%",
        "nvidia-smi / DCGM Exporter → Prometheus"),
    DeployMetric("Inference Latency P99",
        "< 100ms (Real-time) < 500ms (Batch)",
        "Optimize Model (INT8) หรือ Scale Up GPU",
        "Triton Metrics → Prometheus → Grafana"),
    DeployMetric("Queue Depth (Kafka Lag)",
        "< 100 messages",
        "KEDA Scale Workers ตาม Lag",
        "Kafka Consumer Lag → KEDA"),
    DeployMetric("Throughput (RPS)",
        "ตาม SLA (e.g. 1000 RPS)",
        "เพิ่ม Workers + Kafka Partitions",
        "Triton Metrics + Kafka Metrics"),
    DeployMetric("Error Rate",
        "< 0.1%",
        "ตรวจ Model Version OOM GPU Error",
        "Triton Error Count → Alert"),
]

print("=== Production Metrics ===")
for m in metrics:
    print(f"  [{m.metric}] Target: {m.target}")
    print(f"    Scale: {m.scale_action}")
    print(f"    Monitor: {m.monitor}")

เคล็ดลับ

• FP16: เปิด FP16 เสมอ เร็วขึ้น 2x แทบไม่เสีย Accuracy
• Triton: ใช้ Triton Inference Server สำหรับ Production
• KEDA: ใช้ KEDA Scale Workers ตาม Kafka Queue Lag
• Warmup: Warmup Engine ก่อนรับ Traffic จริง
• Cache: Cache Result สำหรับ Repeated Input ลด GPU Load

TensorRT คืออะไร

NVIDIA Inference Optimizer GPU FP16 INT8 Layer Fusion Dynamic Batching ONNX Triton 2-6x Faster T4 A10 A100 H100 Real-time
