TensorFlow Serving Progressive Delivery

TF Serving Progressive Delivery

TensorFlow Serving Progressive Delivery Canary A/B Testing Blue-Green Shadow Istio Argo Rollouts Flagger Kubernetes Production

TF Serving Setup

# === TensorFlow Serving Deployment ===

# Docker Run
# docker run -p 8501:8501 -p 8500:8500 \
#   --mount type=bind, source=/models/my_model, target=/models/my_model \
#   -e MODEL_NAME=my_model \
#   tensorflow/serving

# model_config.list
# model_config_list {
#   config {
#     name: "my_model"
#     base_path: "/models/my_model"
#     model_platform: "tensorflow"
#     model_version_policy {
#       specific { versions: 1 versions: 2 }
#     }
#     version_labels {
#       key: "stable" value: 1
#       key: "canary" value: 2
#     }
#   }
# }

# Kubernetes Deployment
# apiVersion: apps/v1
# kind: Deployment
# metadata:
#   name: tf-serving-v1
# spec:
#   replicas: 3
#   template:
#     spec:
#       containers:
#         - name: tf-serving
#           image: tensorflow/serving:latest
#           args: ["--model_config_file=/config/model.config"]
#           ports:
#             - containerPort: 8501  # REST
#             - containerPort: 8500  # gRPC
#           resources:
#             requests: { cpu: "2", memory: "4Gi" }
#             limits: { cpu: "4", memory: "8Gi", nvidia.com/gpu: "1" }
#           readinessProbe:
#             httpGet:
#               path: /v1/models/my_model
#               port: 8501

from dataclasses import dataclass

@dataclass
class ServingConfig:
    config: str
    value: str
    purpose: str
    tip: str

configs = [
    ServingConfig("model_config_file",
        "/config/model.config",
        "กำหนด Model Name Path Version Policy",
        "ใช้ specific versions สำหรับ Canary"),
    ServingConfig("enable_batching",
        "true + batching_parameters_file",
        "รวม Request เพิ่ม Throughput",
        "max_batch_size=32 batch_timeout=10ms"),
    ServingConfig("rest_api_port",
        "8501",
        "REST API Endpoint",
        "POST /v1/models/{name}:predict"),
    ServingConfig("grpc_port",
        "8500",
        "gRPC Endpoint (เร็วกว่า REST)",
        "ใช้ gRPC สำหรับ Internal Service"),
    ServingConfig("monitoring_config_file",
        "prometheus_config",
        "Export Metrics สำหรับ Prometheus",
        "ดู Latency Throughput Error Rate"),
]

print("=== TF Serving Config ===")
for c in configs:
    print(f"  [{c.config}] = {c.value}")
    print(f"    Purpose: {c.purpose}")
    print(f"    Tip: {c.tip}")

Canary with Istio

# === Canary Deployment with Istio ===

# VirtualService (Traffic Split)
# apiVersion: networking.istio.io/v1beta1
# kind: VirtualService
# metadata:
#   name: tf-serving
# spec:
#   hosts: ["tf-serving"]
#   http:
#     - route:
#         - destination:
#             host: tf-serving-v1
#             port: { number: 8501 }
#           weight: 95
#         - destination:
#             host: tf-serving-v2
#             port: { number: 8501 }
#           weight: 5

# Argo Rollouts
# apiVersion: argoproj.io/v1alpha1
# kind: Rollout
# metadata:
#   name: tf-serving
# spec:
#   strategy:
#     canary:
#       steps:
#         - setWeight: 5
#         - pause: { duration: 10m }
#         - analysis:
#             templates: [{ templateName: tf-serving-analysis }]
#         - setWeight: 25
#         - pause: { duration: 10m }
#         - setWeight: 50
#         - pause: { duration: 10m }
#         - setWeight: 100

@dataclass
class CanaryStep:
    step: int
    weight: str
    duration: str
    action: str
    rollback_trigger: str

steps = [
    CanaryStep(1, "5% Canary", "10 นาที",
        "Deploy V2 ส่ง 5% Traffic Monitor Baseline",
        "Error Rate > 1% Latency P99 > 2x"),
    CanaryStep(2, "25% Canary", "10 นาที",
        "เพิ่ม Traffic ถ้า Step 1 OK",
        "Error Rate > 0.5% Latency P99 > 1.5x"),
    CanaryStep(3, "50% Canary", "10 นาที",
        "เพิ่ม Traffic ตรวจ A/B Significance",
        "Accuracy Drop > 2% Business Metric Drop"),
    CanaryStep(4, "100% Production", "ถาวร",
        "Full Promotion ลบ V1 ออก",
        "Monitor 24 ชม. หลัง Promotion"),
]

print("=== Canary Steps ===")
for s in steps:
    print(f"  Step {s.step}: {s.weight} ({s.duration})")
    print(f"    Action: {s.action}")
    print(f"    Rollback if: {s.rollback_trigger}")

Monitoring & Rollback

# === Model Monitoring ===

@dataclass
class ModelMetric:
    metric: str
    source: str
    baseline: str
    alert: str
    rollback: str

metrics = [
    ModelMetric("Inference Latency P99",
        "Prometheus (TF Serving Metrics)",
        "< 50ms",
        "> 75ms (1.5x)",
        "> 100ms (2x) → Auto Rollback"),
    ModelMetric("Error Rate (5xx)",
        "Prometheus / Istio Metrics",
        "< 0.1%",
        "> 0.5%",
        "> 1% → Auto Rollback"),
    ModelMetric("Model Accuracy",
        "Custom Metrics / Evidently AI",
        "> 95%",
        "< 93% (2% drop)",
        "< 90% (5% drop) → Auto Rollback"),
    ModelMetric("Data Drift",
        "Evidently AI / Alibi Detect",
        "KS-test p > 0.05",
        "p < 0.05 (Drift Detected)",
        "Multiple Features Drift → Retrain"),
    ModelMetric("GPU Utilization",
        "NVIDIA DCGM / Prometheus",
        "< 80%",
        "> 85%",
        "> 95% → Scale Up / Rollback"),
    ModelMetric("Business Metric (CTR)",
        "Analytics Platform",
        "CTR 3.5%",
        "CTR < 3.0% (15% drop)",
        "CTR < 2.5% (30% drop) → Rollback"),
]

print("=== Model Metrics ===")
for m in metrics:
    print(f"  [{m.metric}] Baseline: {m.baseline}")
    print(f"    Source: {m.source}")
    print(f"    Alert: {m.alert}")
    print(f"    Rollback: {m.rollback}")

เคล็ดลับ

• Canary: เริ่ม 5% Monitor 10 นาทีก่อนเพิ่ม
• gRPC: ใช้ gRPC สำหรับ Internal เร็วกว่า REST 2-5x
• Batching: เปิด Batching เพิ่ม Throughput 2-4x
• Argo: ใช้ Argo Rollouts ทำ Canary อัตโนมัติ
• Drift: ตรวจ Data Drift ทุกสัปดาห์ Retrain ถ้า Drift

TensorFlow Serving คืออะไร

Production ML Serving gRPC REST API C++ Low Latency Model Versioning Hot-reload Batching GPU Docker Kubernetes SavedModel

สรุป

TensorFlow Serving Progressive Delivery Canary Istio Argo Rollouts Monitoring Latency Accuracy Drift Rollback Production
