SQLite Litestream Post-mortem Analysis

SQLite Litestream Post-mortem

SQLite Litestream WAL Streaming Real-time Replication S3 Backup Recovery Post-mortem Analysis Root Cause Incident RPO RTO Durability Embedded Database

Litestream Setup

# === Litestream Installation & Configuration ===

# Install
# wget https://github.com/benbjohnson/litestream/releases/latest/download/litestream-linux-amd64.deb
# sudo dpkg -i litestream-linux-amd64.deb

# Configuration — /etc/litestream.yml
# dbs:
#   - path: /data/app.db
#     replicas:
#       - type: s3
#         bucket: my-backup-bucket
#         path: app-db
#         region: ap-southeast-1
#         access-key-id:
#         secret-access-key:
#         retention: 72h
#         sync-interval: 1s
#
#       - type: sftp
#         host: backup-server:22
#         user: backup
#         key-path: /etc/litestream/backup-key
#         path: /backups/app.db

# Run as Service
# sudo systemctl enable litestream
# sudo systemctl start litestream

# Docker Compose
# services:
#   app:
#     build: .
#     volumes: [data:/data]
#   litestream:
#     image: litestream/litestream:latest
#     volumes:
#       - data:/data
#       - ./litestream.yml:/etc/litestream.yml
#     command: replicate
#     environment:
#       - AWS_ACCESS_KEY_ID=
#       - AWS_SECRET_ACCESS_KEY=

# Verify Replication
# litestream replicas list /data/app.db
# litestream wal list /data/app.db

from dataclasses import dataclass

@dataclass
class ReplicaStatus:
    db_path: str
    replica_type: str
    destination: str
    last_sync: str
    lag_ms: int
    status: str

replicas = [
    ReplicaStatus("/data/app.db", "S3", "s3://backup/app-db", "10:30:01", 150, "Syncing"),
    ReplicaStatus("/data/app.db", "SFTP", "backup-server:/backups", "10:30:00", 1200, "Syncing"),
    ReplicaStatus("/data/blog.db", "S3", "s3://backup/blog-db", "10:30:01", 80, "Syncing"),
]

print("=== Litestream Replica Status ===")
for r in replicas:
    print(f"  [{r.status}] {r.db_path} -> {r.replica_type}")
    print(f"    Destination: {r.destination} | Lag: {r.lag_ms}ms | Last: {r.last_sync}")

Recovery และ Testing

# === Disaster Recovery ===

# Restore Latest
# litestream restore -o /data/restored.db s3://backup/app-db

# Point-in-time Recovery
# litestream restore -o /data/restored.db \
#   -timestamp "2024-03-15T10:30:00Z" \
#   s3://backup/app-db

# Verify Integrity
# sqlite3 /data/restored.db "PRAGMA integrity_check;"
# sqlite3 /data/restored.db "SELECT count(*) FROM users;"

# Automated Recovery Test (cron weekly)
# #!/bin/bash
# RESTORE_PATH="/tmp/recovery-test-$(date +%Y%m%d).db"
# litestream restore -o "$RESTORE_PATH" s3://backup/app-db
#
# INTEGRITY=$(sqlite3 "$RESTORE_PATH" "PRAGMA integrity_check;")
# ROW_COUNT=$(sqlite3 "$RESTORE_PATH" "SELECT count(*) FROM users;")
#
# if [ "$INTEGRITY" = "ok" ] && [ "$ROW_COUNT" -gt 0 ]; then
#   echo "RECOVERY TEST PASSED: $ROW_COUNT rows, integrity OK"
#   curl -X POST "$SLACK_WEBHOOK" \
#     -d "{\"text\":\"Recovery test PASSED: $ROW_COUNT rows\"}"
# else
#   echo "RECOVERY TEST FAILED"
#   curl -X POST "$PAGERDUTY_WEBHOOK" \
#     -d "{\"text\":\"CRITICAL: Recovery test FAILED\"}"
# fi
# rm -f "$RESTORE_PATH"

@dataclass
class RecoveryTest:
    date: str
    db: str
    rows_restored: int
    integrity: str
    duration_sec: float
    status: str

tests = [
    RecoveryTest("2024-03-15", "app.db", 150000, "OK", 8.5, "PASSED"),
    RecoveryTest("2024-03-08", "app.db", 148500, "OK", 7.2, "PASSED"),
    RecoveryTest("2024-03-01", "app.db", 145000, "OK", 6.8, "PASSED"),
    RecoveryTest("2024-03-15", "blog.db", 5200, "OK", 1.2, "PASSED"),
]

print("\n=== Recovery Test History ===")
for t in tests:
    print(f"  [{t.status}] {t.date} — {t.db}")
    print(f"    Rows: {t.rows_restored:,} | Integrity: {t.integrity} | Duration: {t.duration_sec}s")

Post-mortem Template

# === Post-mortem: Database Corruption Incident ===

# ## Incident: SQLite Database Corruption
# **Date:** 2024-03-10
# **Duration:** 25 minutes
# **Severity:** P1 - Critical
# **Author:** Platform Team
#
# ### Timeline
# - 14:00 — Alert: App returning 500 errors
# - 14:03 — On-call acknowledges, starts investigation
# - 14:05 — Found: SQLite database file corrupted
# - 14:08 — Root cause: Disk full caused WAL corruption
# - 14:10 — Decision: Restore from Litestream backup
# - 14:12 — litestream restore started
# - 14:13 — Database restored (8.5 seconds)
# - 14:15 — App restarted with restored database
# - 14:20 — Verified: All data intact, 0 rows lost
# - 14:25 — All services healthy, incident resolved
#
# ### Root Cause
# Disk reached 100% capacity due to unrotated log files
# SQLite WAL could not be checkpointed, causing corruption
#
# ### Impact
# - 25 minutes downtime
# - ~500 failed requests
# - 0 data loss (Litestream RPO < 1 second)
#
# ### Action Items
# 1. [DONE] Add disk usage monitoring alert at 80%
# 2. [DONE] Configure log rotation (logrotate)
# 3. [TODO] Add automatic disk cleanup script
# 4. [TODO] Schedule weekly recovery tests
# 5. [DONE] Document recovery runbook

@dataclass
class ActionItem:
    id: int
    action: str
    owner: str
    status: str
    due_date: str

actions = [
    ActionItem(1, "Disk usage alert at 80%", "SRE Team", "Done", "2024-03-11"),
    ActionItem(2, "Configure logrotate", "SRE Team", "Done", "2024-03-11"),
    ActionItem(3, "Auto disk cleanup script", "Platform", "In Progress", "2024-03-20"),
    ActionItem(4, "Weekly recovery test cron", "SRE Team", "Done", "2024-03-12"),
    ActionItem(5, "Recovery runbook doc", "SRE Team", "Done", "2024-03-12"),
]

print("Post-mortem Action Items:")
for a in actions:
    print(f"  [{a.status}] #{a.id}: {a.action}")
    print(f"    Owner: {a.owner} | Due: {a.due_date}")

# Metrics After Incident
improvements = {
    "RPO": "< 1 second (unchanged)",
    "RTO": "25 min -> 2 min (with runbook)",
    "MTTR": "25 min -> 5 min (automated recovery)",
    "Recovery Tests": "0 -> Weekly automated",
    "Disk Alerts": "None -> 80% threshold",
    "Data Loss": "0 rows (Litestream saved us)",
}

print(f"\n\nImprovements After Incident:")
for metric, value in improvements.items():
    print(f"  {metric}: {value}")

เคล็ดลับ

• sync-interval: ตั้ง 1s สำหรับ RPO ต่ำสุด
• retention: เก็บ 72h+ สำหรับ Point-in-time Recovery
• Test: ทดสอบ Recovery ทุกสัปดาห์อัตโนมัติ
• Monitor: Monitor Replication Lag และ Disk Usage
• Blameless: Post-mortem ต้อง Blameless โฟกัสที่ระบบ
