Spark Structured Streaming Troubleshooting

Spark Streaming Troubleshooting

Spark Structured Streaming Troubleshooting แก้ปัญหา OOM Checkpoint Watermark Performance Kafka State Store AQE Partition Skew

เนื้อหาเกี่ยวข้อง — อ่านต่อ: TypeScript Zod Architecture Design Pattern — คู่มือฉบับสมบูรณ์ 2026

ปัญหา	สาเหตุ	วิธีแก้	Priority
OOM (Out of Memory)	State Store ใหญ่ / Shuffle / Large Batch	Watermark + RocksDB + AQE	Critical
Slow Batch	Partition Skew / No AQE / Low Parallelism	เพิ่ม Partitions + AQE + Broadcast	High
Checkpoint Corrupt	Disk Full / Schema Change / Bug	ลบ Checkpoint + Idempotent Sink	High
Late Data Loss	Watermark ตัดข้อมูลเร็วเกินไป	เพิ่ม Watermark Duration	Medium
Data Duplication	Checkpoint Recovery / At-least-once	Idempotent Sink (Upsert)	Medium
Kafka Lag	Processing ช้ากว่า Ingestion	Scale Executors + maxOffsetsPerTrigger	High

Memory & State Issues

# === Spark Structured Streaming Memory Fix ===

# spark-submit configuration
# spark-submit \
#   --master yarn \
#   --deploy-mode cluster \
#   --num-executors 10 \
#   --executor-memory 8g \
#   --executor-cores 4 \
#   --driver-memory 4g \
#   --conf spark.sql.shuffle.partitions=500 \
#   --conf spark.sql.adaptive.enabled=true \
#   --conf spark.sql.adaptive.coalescePartitions.enabled=true \
#   --conf spark.sql.streaming.stateStore.providerClass=org.apache.spark.sql.execution.streaming.state.RocksDBStateStoreProvider \
#   --conf spark.memory.offHeap.enabled=true \
#   --conf spark.memory.offHeap.size=4g \
#   --conf spark.serializer=org.apache.spark.serializer.KryoSerializer \
#   streaming_app.py

# Watermark + State Cleanup
# df = spark.readStream \
#     .format("kafka") \
#     .option("kafka.bootstrap.servers", "kafka:9092") \
#     .option("subscribe", "events") \
#     .option("maxOffsetsPerTrigger", 100000) \
#     .load()
#
# result = df \
#     .withWatermark("event_time", "1 hour") \
#     .groupBy(
#         window("event_time", "5 minutes"),
#         "user_id"
#     ) \
#     .agg(count("*").alias("event_count"))

from dataclasses import dataclass

@dataclass
class MemoryFix:
    problem: str
    symptom: str
    config: str
    value: str
    effect: str

fixes = [
    MemoryFix("State Store OOM",
        "java.lang.OutOfMemoryError: Java heap space",
        "withWatermark('event_time', '1 hour')",
        "ตั้ง Watermark ลบ State เก่ากว่า 1 ชั่วโมง",
        "State Size ลดลง 80-90%"),
    MemoryFix("State Store OOM (Large)",
        "State size > Executor Memory",
        "stateStore.providerClass=RocksDBStateStoreProvider",
        "ใช้ RocksDB เก็บ State บน Disk แทน Memory",
        "รองรับ State ขนาด TB"),
    MemoryFix("Shuffle OOM",
        "OOM ตอน groupBy / join",
        "spark.sql.shuffle.partitions=500",
        "เพิ่ม Partition ลด Data ต่อ Partition",
        "ลด Memory ต่อ Task"),
    MemoryFix("Large Batch OOM",
        "OOM เมื่อข้อมูลสะสมมาก",
        "maxOffsetsPerTrigger=100000",
        "จำกัดข้อมูลต่อ Batch ไม่ให้มากเกินไป",
        "Batch Size สม่ำเสมอ"),
    MemoryFix("AQE Not Enabled",
        "Partition Skew ทำให้ Task ช้า/OOM",
        "spark.sql.adaptive.enabled=true",
        "AQE ปรับ Partition อัตโนมัติ",
        "ลด Skew + ลด Partition ที่เล็กเกินไป"),
]

print("=== Memory Fixes ===")
for f in fixes:
    print(f"\n  [{f.problem}]")
    print(f"    Symptom: {f.symptom}")
    print(f"    Config: {f.config}")
    print(f"    Value: {f.value}")
    print(f"    Effect: {f.effect}")

Checkpoint & Recovery

# === Checkpoint Management ===

# Checkpoint Configuration
# query = result.writeStream \
#     .format("parquet") \
#     .option("checkpointLocation", "s3://bucket/checkpoints/app-v1") \
#     .option("path", "s3://bucket/output/") \
#     .trigger(processingTime="30 seconds") \
#     .outputMode("append") \
#     .start()

# Idempotent Sink (Upsert to Database)
# def upsert_to_db(batch_df, batch_id):
#     batch_df.write \
#         .format("jdbc") \
#         .option("url", "jdbc:postgresql://db:5432/analytics") \
#         .option("dbtable", "events") \
#         .option("user", "app") \
#         .option("password", "secret") \
#         .mode("append") \
#         .save()
#     # Use ON CONFLICT DO UPDATE for true idempotency
#
# query = result.writeStream \
#     .foreachBatch(upsert_to_db) \
#     .option("checkpointLocation", "s3://bucket/checkpoints/db-sink") \
#     .start()

@dataclass
class CheckpointIssue:
    issue: str
    cause: str
    fix: str
    prevention: str

checkpoint_issues = [
    CheckpointIssue("Checkpoint Corruption",
        "Disk Full, Network Error ขณะเขียน Checkpoint",
        "ลบ Checkpoint Directory เริ่มใหม่ + Idempotent Sink",
        "ใช้ S3/HDFS ไม่ใช้ Local Disk + Monitor Disk Usage"),
    CheckpointIssue("Schema Change Break",
        "เปลี่ยน Schema แล้ว Checkpoint เก่า Incompatible",
        "ลบ Checkpoint + ตั้ง Kafka Offset เป็น earliest/latest",
        "ใช้ Schema Registry + Compatible Schema Evolution"),
    CheckpointIssue("Checkpoint Size Too Large",
        "State Store มี Key ล้านๆ ตัว ไม่มี Watermark",
        "เพิ่ม Watermark ลด State + ใช้ RocksDB",
        "ตั้ง Watermark ทุก Stateful Query"),
    CheckpointIssue("Slow Recovery",
        "Checkpoint ใหญ่ เริ่ม Stream ใหม่ช้ามาก",
        "เพิ่ม minBatchesToRetain=10 ลด History",
        "ตั้ง State TTL + Compact Checkpoint เป็นระยะ"),
]

print("=== Checkpoint Issues ===")
for c in checkpoint_issues:
    print(f"  [{c.issue}]")
    print(f"    Cause: {c.cause}")
    print(f"    Fix: {c.fix}")
    print(f"    Prevent: {c.prevention}")

Performance Tuning

# === Performance Tuning Checklist ===

@dataclass
class TuningParam:
    category: str
    param: str
    default_val: str
    recommended: str
    impact: str

tuning = [
    TuningParam("Parallelism",
        "spark.sql.shuffle.partitions",
        "200",
        "2-3x Kafka Partitions (e.g. 500)",
        "ลด Skew ใช้ Core เต็มที่"),
    TuningParam("AQE",
        "spark.sql.adaptive.enabled",
        "false (Spark 3.0) / true (3.2+)",
        "true",
        "Auto-coalesce + Skew join + Optimize"),
    TuningParam("Batch Size",
        "maxOffsetsPerTrigger",
        "Unlimited",
        "100000-500000",
        "Batch Size สม่ำเสมอ ไม่ OOM"),
    TuningParam("Trigger",
        "trigger(processingTime=...)",
        "ASAP (0ms)",
        "10-60 seconds",
        "Balance Latency vs Throughput"),
    TuningParam("Serializer",
        "spark.serializer",
        "JavaSerializer",
        "KryoSerializer",
        "ลด Serialization Time 30-50%"),
    TuningParam("Join",
        "spark.sql.autoBroadcastJoinThreshold",
        "10MB",
        "50-100MB",
        "Broadcast Join ลด Shuffle"),
    TuningParam("State Store",
        "stateStore.providerClass",
        "HDFSBackedStateStoreProvider",
        "RocksDBStateStoreProvider",
        "รองรับ State ขนาดใหญ่มาก"),
    TuningParam("Compression",
        "spark.sql.streaming.stateStore.compression.codec",
        "none",
        "lz4",
        "ลด Checkpoint Size 40-60%"),
]

print("=== Performance Tuning ===")
for t in tuning:
    print(f"  [{t.category}] {t.param}")
    print(f"    Default: {t.default_val} → Recommended: {t.recommended}")
    print(f"    Impact: {t.impact}")

เคล็ดลับ

Watermark: ตั้ง Watermark ทุก Stateful Query ป้องกัน State OOM
RocksDB: ใช้ RocksDB State Store สำหรับ State ขนาดใหญ่
AQE: เปิด Adaptive Query Execution ลด Skew อัตโนมัติ
Idempotent: ใช้ Idempotent Sink (Upsert) ป้องกันข้อมูลซ้ำ
Monitor: ดู Spark UI Batch Duration Processing Rate State Size

ปัญหาที่พบบ่อยมีอะไร

OOM State Store Partition Skew Slow Batch Checkpoint Corruption Late Data Kafka Offset Serialization Schema Evolution Backlog
