SonarQube Troubleshooting

SonarQube Analysis Troubleshooting แก้ปัญหา Scanner Config Memory OOM Coverage Quality Gate CI/CD GitHub GitLab Jenkins Production

Scanner Configuration

# === SonarQube Scanner Configuration ===

# sonar-project.properties
# sonar.projectKey=my-project
# sonar.projectName=My Project
# sonar.projectVersion=1.0
#
# # Source
# sonar.sources=src
# sonar.tests=test
# sonar.sourceEncoding=UTF-8
#
# # Server
# sonar.host.url=https://sonarqube.example.com
# sonar.token=sqp_xxxxxxxxxxxx
#
# # Exclusions
# sonar.exclusions=**/vendor/**,**/node_modules/**,**/*.min.js,**/dist/**
# sonar.coverage.exclusions=**/test/**,**/*_test.go,**/*.spec.ts
# sonar.cpd.exclusions=**/generated/**
#
# # Coverage Report
# sonar.javascript.lcov.reportPaths=coverage/lcov.info
# sonar.go.coverage.reportPaths=coverage.out
# sonar.python.coverage.reportPaths=coverage.xml
# sonar.java.coveragePlugin=jacoco
# sonar.coverage.jacoco.xmlReportPaths=build/reports/jacoco/test/jacocoTestReport.xml
#
# # SCM
# sonar.scm.provider=git
# sonar.scm.forceReloadAll=true

from dataclasses import dataclass

@dataclass
class ScannerIssue:
    problem: str
    symptom: str
    cause: str
    fix: str
    config: str

issues = [
    ScannerIssue("Connection Failed",
        "ERROR: SonarQube server [url] can not be reached",
        "URL ผิด Server ไม่ทำงาน Firewall Block Port",
        "ตรวจ URL Port 9000 Token Network curl ทดสอบ",
        "sonar.host.url=http://sonarqube:9000"),
    ScannerIssue("Authentication Failed",
        "ERROR: Not authorized. Analyzing this project requires authentication",
        "Token หมดอายุ Token ไม่มีสิทธิ์ Analysis",
        "สร้าง Token ใหม่ ตั้ง Permission Execute Analysis",
        "sonar.token=sqp_newtoken"),
    ScannerIssue("Coverage 0%",
        "Coverage widget shows 0.0% despite having tests",
        "Report Path ผิด Format ไม่รองรับ Report ไม่ถูกสร้าง",
        "ตรวจ Path ถูก Run Test ก่อน Scan ตรวจ Format",
        "sonar.javascript.lcov.reportPaths=coverage/lcov.info"),
    ScannerIssue("Source Not Found",
        "WARN: Invalid value of sonar.sources",
        "sonar.sources ชี้ไป Directory ที่ไม่มี",
        "ตรวจ Path ถูกต้อง Relative to Project Root",
        "sonar.sources=src/main/java"),
    ScannerIssue("SCM Not Working",
        "SCM provider autodetection failed",
        "ไม่มี .git Directory หรือ Git ไม่ได้ติดตั้ง",
        "ตั้ง scm.provider=git Checkout Full History",
        "sonar.scm.provider=git"),
]

print("=== Scanner Issues ===")
for i in issues:
    print(f"\n  [{i.problem}]")
    print(f"    Symptom: {i.symptom}")
    print(f"    Cause: {i.cause}")
    print(f"    Fix: {i.fix}")
    print(f"    Config: {i.config}")

Memory & Performance

# === Memory & Performance Tuning ===

# Scanner Memory
# export SONAR_SCANNER_OPTS="-Xmx4g -Xms1g"
# sonar-scanner

# Maven
# mvn sonar:sonar -Dsonar.host.url=http://sonarqube:9000 \
#   -Dsonar.token=sqp_xxx \
#   MAVEN_OPTS="-Xmx4g"

# Gradle
# ./gradlew sonar -Dsonar.host.url=http://sonarqube:9000 \
#   -Dorg.gradle.jvmargs="-Xmx4g"

# Server Memory (sonar.properties)
# sonar.web.javaOpts=-Xmx2g -Xms1g -XX:+UseG1GC
# sonar.ce.javaOpts=-Xmx4g -Xms2g -XX:+UseG1GC
# sonar.search.javaOpts=-Xmx2g -Xms2g

@dataclass
class MemoryConfig:
    component: str
    default: str
    recommended: str
    when_to_increase: str
    max: str

memory_configs = [
    MemoryConfig("Scanner (SONAR_SCANNER_OPTS)",
        "-Xmx512m",
        "-Xmx2g-4g",
        "Project > 500K LOC หรือ OOM Error",
        "-Xmx8g (ขึ้นกับ Project Size)"),
    MemoryConfig("Web Server (sonar.web.javaOpts)",
        "-Xmx512m",
        "-Xmx1g-2g",
        "Server ช้า UI ไม่ตอบสนอง",
        "-Xmx4g"),
    MemoryConfig("Compute Engine (sonar.ce.javaOpts)",
        "-Xmx512m",
        "-Xmx2g-4g",
        "Analysis Queue สะสม Background Task ช้า",
        "-Xmx8g (สำคัญที่สุด)"),
    MemoryConfig("Elasticsearch (sonar.search.javaOpts)",
        "-Xmx512m",
        "-Xmx1g-2g",
        "Search ช้า Project เยอะ Index ใหญ่",
        "-Xmx4g (ไม่เกิน 50% RAM)"),
    MemoryConfig("Database Connection Pool",
        "10",
        "20-50",
        "Connection Timeout หลาย Concurrent Analysis",
        "100 (PostgreSQL max_connections)"),
]

print("=== Memory Config ===")
for m in memory_configs:
    print(f"  [{m.component}]")
    print(f"    Default: {m.default} → Recommended: {m.recommended}")
    print(f"    Increase when: {m.when_to_increase}")
    print(f"    Max: {m.max}")

CI/CD Integration

# === CI/CD Integration Examples ===

# GitHub Actions
# - name: SonarQube Scan
#   uses: SonarSource/sonarqube-scan-action@master
#   env:
#     SONAR_TOKEN: }
#     SONAR_HOST_URL: }
#
# - name: Quality Gate
#   uses: SonarSource/sonarqube-quality-gate-action@master
#   timeout-minutes: 5
#   env:
#     SONAR_TOKEN: }

# GitLab CI
# sonarqube:
#   image: sonarsource/sonar-scanner-cli:latest
#   variables:
#     SONAR_HOST_URL: $SONAR_HOST_URL
#     SONAR_TOKEN: $SONAR_TOKEN
#   script:
#     - sonar-scanner -Dsonar.projectKey=$CI_PROJECT_NAME
#                     -Dsonar.branch.name=$CI_COMMIT_BRANCH

# Jenkins Pipeline
# pipeline {
#   stages {
#     stage('SonarQube') {
#       steps {
#         withSonarQubeEnv('SonarQube') {
#           sh 'sonar-scanner'
#         }
#       }
#     }
#     stage('Quality Gate') {
#       steps {
#         timeout(time: 5, unit: 'MINUTES') {
#           waitForQualityGate abortPipeline: true
#         }
#       }
#     }
#   }
# }

@dataclass
class CICDIssue:
    ci_tool: str
    issue: str
    cause: str
    fix: str

cicd_issues = [
    CICDIssue("GitHub Actions",
        "Quality Gate timeout",
        "Webhook ไม่ส่งกลับ หรือ Analysis ยังไม่เสร็จ",
        "ตั้ง Webhook ใน SonarQube ชี้ไป GitHub เพิ่ม timeout"),
    CICDIssue("GitLab CI",
        "sonar-scanner not found",
        "ใช้ Image ที่ไม่มี sonar-scanner",
        "ใช้ sonarsource/sonar-scanner-cli Docker Image"),
    CICDIssue("Jenkins",
        "waitForQualityGate hangs",
        "Webhook ไม่ Configure หรือ Firewall Block",
        "ตั้ง Webhook ใน SonarQube → Jenkins URL/sonarqube-webhook/"),
    CICDIssue("All",
        "Branch Analysis ไม่ทำงาน",
        "ไม่ตั้ง sonar.branch.name หรือ ใช้ Community Edition",
        "ตั้ง sonar.branch.name=$BRANCH (Developer Edition+)"),
    CICDIssue("All",
        "PR Decoration ไม่แสดง",
        "ALM Integration ไม่ Configure",
        "ตั้ง DevOps Platform Integration ใน SonarQube Admin"),
]

print("=== CI/CD Issues ===")
for c in cicd_issues:
    print(f"  [{c.ci_tool}] {c.issue}")
    print(f"    Cause: {c.cause}")
    print(f"    Fix: {c.fix}")

เคล็ดลับ

• Exclusions: ตั้ง Exclusions ลด Scan Time ไม่ Scan vendor node_modules
• CE Memory: Compute Engine สำคัญที่สุด เพิ่ม Memory ก่อน
• PostgreSQL: ใช้ PostgreSQL สำหรับ Production ไม่ใช้ H2
• Webhook: ตั้ง Webhook สำหรับ Quality Gate ใน CI/CD
• Token: ใช้ Project Token แทน Global Token Least Privilege

ปัญหาที่พบบ่อยมีอะไร

Connection Refused OOM Coverage 0% Timeout Quality Gate Fail SCM Language Plugin Elasticsearch Database Duplicate False Positive

สรุป

SonarQube Troubleshooting Scanner Config Memory OOM Coverage Quality Gate CI/CD GitHub GitLab Jenkins Webhook PostgreSQL Production
