Snyk Code Security Hexagonal Architecture —

เผยแพร่ 28 พฤษภาคม 2569

Snyk Hexagonal Security

Snyk Code Security Hexagonal Architecture Ports Adapters SAST SCA Container IaC Domain Application Infrastructure CI/CD Production

Snyk ProductHex LayerWhat It ChecksExample Finding
Snyk Code (SAST)All LayersSource Code VulnerabilitiesSQL Injection in DB Adapter
Snyk Open Source (SCA)InfrastructureDependency CVEsCVE in express lodash
Snyk ContainerInfrastructureDocker Image VulnerabilitiesCVE in base image OS package
Snyk IaCInfrastructureTerraform K8s MisconfigOpen Security Group S3 Public

Hexagonal Architecture

# === Hexagonal Architecture Structure ===

# Project Structure:
# src/
# ├── domain/           # Core Business Logic (NO dependencies)
# │   ├── entities/     # User Order Product
# │   ├── value-objects/ # Email Password Money
# │   ├── services/     # DomainService
# │   └── ports/        # Interfaces (Repository, Gateway)
# ├── application/      # Use Cases (Orchestration)
# │   ├── use-cases/    # CreateOrder, AuthenticateUser
# │   ├── dto/          # Request/Response DTOs
# │   └── services/     # ApplicationService
# └── infrastructure/   # External Adapters
#     ├── adapters/
#     │   ├── http/      # Express/Fastify Controllers
#     │   ├── database/  # PostgreSQL/MongoDB Repositories
#     │   ├── queue/     # RabbitMQ/Kafka Producers
#     │   └── external/  # Payment/Email API Clients
#     └── config/        # Database Config, Env Variables

from dataclasses import dataclass

@dataclass
class HexLayer:
    layer: str
    responsibility: str
    dependencies: str
    security_concern: str
    snyk_product: str

layers = [
    HexLayer("Domain (Core)",
        "Business Logic Entities Rules Validation",
        "ไม่มี Dependencies ภายนอก (Pure Code)",
        "Input Validation Business Rule Enforcement",
        "Snyk Code: ตรวจ Logic Flaw Injection ใน Validation"),
    HexLayer("Application (Use Cases)",
        "Orchestrate Domain Logic Auth Authorization",
        "Domain Layer Only",
        "Authentication Authorization Audit Logging",
        "Snyk Code: ตรวจ Auth Bypass Missing Authorization"),
    HexLayer("Infrastructure (Adapters)",
        "Database HTTP Queue External API Implementation",
        "Application + Domain + External Libraries",
        "SQL Injection XSS SSRF Dependency CVE",
        "Snyk Code + Open Source + Container + IaC"),
    HexLayer("Ports (Interfaces)",
        "Define Contract ระหว่าง Layer",
        "ไม่มี (Interface Only)",
        "Input/Output Validation Contract Enforcement",
        "Snyk Code: ตรวจ Type Safety Contract Violation"),
]

print("=== Hexagonal Layers ===")
for l in layers:
    print(f"\n  [{l.layer}] {l.responsibility}")
    print(f"    Deps: {l.dependencies}")
    print(f"    Security: {l.security_concern}")
    print(f"    Snyk: {l.snyk_product}")

Security per Layer

# === Security Implementation per Layer ===

# Domain Layer Security (Pure - No Framework)
# class Email:
#     def __init__(self, value: str):
#         if not re.match(r'^[a-zA-Z0-9_.+-]+@[a-zA-Z0-9-]+\.[a-zA-Z0-9-.]+$', value):
#             raise ValueError("Invalid email format")
#         self.value = value
#
# class Password:
#     MIN_LENGTH = 12
#     def __init__(self, raw: str):
#         if len(raw) < self.MIN_LENGTH:
#             raise ValueError(f"Password must be >= {self.MIN_LENGTH} chars")
#         if not re.search(r'[A-Z]', raw):
#             raise ValueError("Password must contain uppercase")
#         self.hashed = bcrypt.hashpw(raw.encode(), bcrypt.gensalt())

# Application Layer Security
# class AuthenticateUser:
#     def __init__(self, user_repo: UserRepository, token_service: TokenService):
#         self.user_repo = user_repo
#         self.token_service = token_service
#
#     async def execute(self, email: str, password: str) -> AuthResult:
#         user = await self.user_repo.find_by_email(Email(email))
#         if not user or not user.verify_password(password):
#             audit_log("AUTH_FAILED", email)  # Audit
#             raise AuthenticationError("Invalid credentials")
#         audit_log("AUTH_SUCCESS", email)
#         return AuthResult(token=self.token_service.generate(user))

@dataclass
class SecurityCheck:
    layer: str
    check: str
    implementation: str
    snyk_rule: str

checks = [
    SecurityCheck("Domain",
        "Input Validation (Email Password Amount)",
        "Value Object Constructor Validation",
        "Snyk Code: Improper Input Validation (CWE-20)"),
    SecurityCheck("Domain",
        "Business Rule Enforcement",
        "Domain Service Invariant Check",
        "Snyk Code: Business Logic Bypass"),
    SecurityCheck("Application",
        "Authentication (Login MFA Token)",
        "Use Case + Token Service + User Repository",
        "Snyk Code: Broken Authentication (CWE-287)"),
    SecurityCheck("Application",
        "Authorization (RBAC ABAC)",
        "Use Case Decorator/Middleware",
        "Snyk Code: Missing Authorization (CWE-862)"),
    SecurityCheck("Infrastructure",
        "SQL Injection Prevention",
        "Parameterized Query ใน Database Adapter",
        "Snyk Code: SQL Injection (CWE-89)"),
    SecurityCheck("Infrastructure",
        "XSS Prevention",
        "Output Encoding ใน HTTP Adapter",
        "Snyk Code: Cross-site Scripting (CWE-79)"),
    SecurityCheck("Infrastructure",
        "Dependency Vulnerabilities",
        "Lock File + Version Pinning",
        "Snyk Open Source: Known CVE Detection"),
]

print("=== Security Checks per Layer ===")
for c in checks:
    print(f"  [{c.layer}] {c.check}")
    print(f"    Impl: {c.implementation}")
    print(f"    Snyk: {c.snyk_rule}")

CI/CD Pipeline

# === Snyk Security Pipeline ===

# GitHub Actions
# name: Security Pipeline
# on: [push, pull_request]
# jobs:
#   snyk-code:
#     runs-on: ubuntu-latest
#     steps:
#     - uses: actions/checkout@v4
#     - name: Snyk Code (SAST)
#       uses: snyk/actions/node@master
#       env:
#         SNYK_TOKEN: }
#       with:
#         command: code test
#         args: --severity-threshold=high
#   snyk-oss:
#     runs-on: ubuntu-latest
#     steps:
#     - uses: actions/checkout@v4
#     - name: Snyk Open Source (SCA)
#       uses: snyk/actions/node@master
#       env:
#         SNYK_TOKEN: }
#       with:
#         command: test
#         args: --severity-threshold=high
#   snyk-container:
#     runs-on: ubuntu-latest
#     steps:
#     - name: Snyk Container
#       uses: snyk/actions/docker@master
#       env:
#         SNYK_TOKEN: }
#       with:
#         image: my-app:latest
#         args: --severity-threshold=high

@dataclass
class PipelineStage:
    stage: str
    snyk_command: str
    hex_layer: str
    fail_criteria: str

stages = [
    PipelineStage("Snyk Code (SAST)",
        "snyk code test --severity-threshold=high",
        "Domain + Application + Infrastructure",
        "Any High/Critical → Block PR"),
    PipelineStage("Snyk Open Source (SCA)",
        "snyk test --severity-threshold=high",
        "Infrastructure (Dependencies)",
        "High/Critical CVE → Block + Auto-fix PR"),
    PipelineStage("Unit Tests",
        "npm test -- --coverage",
        "Domain + Application (90%+ Coverage)",
        "Test Fail or Coverage < 90% → Block"),
    PipelineStage("Snyk Container",
        "snyk container test image:tag",
        "Infrastructure (Docker)",
        "Critical CVE in Base Image → Block"),
    PipelineStage("Snyk IaC",
        "snyk iac test terraform/",
        "Infrastructure (Cloud Config)",
        "High Severity Misconfig → Block"),
    PipelineStage("DAST (Staging)",
        "OWASP ZAP / Burp Suite scan staging URL",
        "All Layers (Runtime)",
        "Critical Finding → Block Release"),
]

print("=== Security Pipeline ===")
for s in stages:
    print(f"  [{s.stage}]")
    print(f"    Command: {s.snyk_command}")
    print(f"    Layer: {s.hex_layer}")
    print(f"    Fail: {s.fail_criteria}")

เคล็ดลับ

  • Domain Pure: Domain Layer ต้องไม่มี External Dependency ลด Attack Surface
  • Validation: Validate ใน Domain (Value Object) ไม่ใช่แค่ Controller
  • Snyk Monitor: ใช้ snyk monitor ตรวจ Production Dependencies ต่อเนื่อง
  • Auto-fix: เปิด Snyk Auto-fix PR สำหรับ Dependency Upgrade
  • Port Security: กำหนด Security Contract ใน Port Interface

Snyk คืออะไร

Developer Security Platform SAST SCA Container IaC Code Dependencies Docker Terraform CVE Fix Recommendation CI/CD GitHub Free Team
