Skaffold Dev Monitoring และ Alerting

Skaffold Dev Monitoring

Skaffold Dev Monitoring Alerting Prometheus Grafana Loki Log Aggregation Health Check Observability Metrics Dashboard Alert Pod Status Resource Usage

Prometheus Setup

# === Prometheus + Grafana for Skaffold Dev ===

# Install with Helm
# helm repo add prometheus-community https://prometheus-community.github.io/helm-charts
# helm install monitoring prometheus-community/kube-prometheus-stack \
# --namespace monitoring --create-namespace \
# --set grafana.adminPassword=admin123

# Skaffold config — include monitoring
# apiVersion: skaffold/v4beta7
# kind: Config
# metadata:
# name: my-app
# build:
# artifacts:
# - image: my-app
# docker:
# dockerfile: Dockerfile
# deploy:
# kubectl:
# manifests:
# - k8s/*.yaml
# portForward:
# - resourceType: service
# resourceName: my-app
# port: 8080
# localPort: 8080
# - resourceType: service
# resourceName: monitoring-grafana
# namespace: monitoring
# port: 80
# localPort: 3000
# - resourceType: service
# resourceName: monitoring-kube-prometheus-prometheus
# namespace: monitoring
# port: 9090
# localPort: 9090

# Application Metrics — Python Flask
# from prometheus_client import Counter, Histogram, generate_latest
# from flask import Flask, Response
#
# app = Flask(__name__)
#
# REQUEST_COUNT = Counter('http_requests_total',
# 'Total HTTP requests', ['method', 'endpoint', 'status'])
# REQUEST_LATENCY = Histogram('http_request_duration_seconds',
# 'HTTP request latency', ['method', 'endpoint'])
#
# @app.before_request
# def before_request():
# request.start_time = time.time()
#
# @app.after_request
# def after_request(response):
# latency = time.time() - request.start_time
# REQUEST_COUNT.labels(request.method, request.path, response.status_code).inc()
# REQUEST_LATENCY.labels(request.method, request.path).observe(latency)
# return response
#
# @app.route('/metrics')
# def metrics():
# return Response(generate_latest(), mimetype='text/plain')

# ServiceMonitor — Prometheus scrape config
# apiVersion: monitoring.coreos.com/v1
# kind: ServiceMonitor
# metadata:
# name: my-app
# labels:
# release: monitoring
# spec:
# selector:
# matchLabels:
# app: my-app
# endpoints:
# - port: http
# path: /metrics
# interval: 15s

from dataclasses import dataclass

@dataclass
class MetricConfig:
 metric: str
 type_val: str
 labels: str
 alert_threshold: str
 dashboard: str

metrics = [
 MetricConfig("http_requests_total", "Counter", "method endpoint status", "> 100 errors/min", "Request Rate"),
 MetricConfig("http_request_duration_seconds", "Histogram", "method endpoint", "p99 > 500ms", "Latency"),
 MetricConfig("container_cpu_usage_seconds_total", "Counter", "pod namespace", "> 80% limit", "CPU Usage"),
 MetricConfig("container_memory_working_set_bytes", "Gauge", "pod namespace", "> 80% limit", "Memory"),
 MetricConfig("kube_pod_status_phase", "Gauge", "pod phase", "phase != Running", "Pod Status"),
]

print("=== Monitoring Metrics ===")
for m in metrics:
 print(f" [{m.metric}] Type: {m.type_val}")
 print(f" Labels: {m.labels}")
 print(f" Alert: {m.alert_threshold} | Dashboard: {m.dashboard}")

Log Aggregation

# === Loki Log Aggregation ===

# Install Loki Stack
# helm install loki grafana/loki-stack \
# --namespace monitoring \
# --set promtail.enabled=true \
# --set grafana.enabled=false # use existing Grafana

# Structured Logging — Python
# import logging
# import json
# from datetime import datetime
#
# class JSONFormatter(logging.Formatter):
# def format(self, record):
# log_entry = {
# "timestamp": datetime.utcnow().isoformat(),
# "level": record.levelname,
# "message": record.getMessage(),
# "logger": record.name,
# "module": record.module,
# "function": record.funcName,
# "line": record.lineno,
# }
# if hasattr(record, 'correlation_id'):
# log_entry['correlation_id'] = record.correlation_id
# if record.exc_info:
# log_entry['exception'] = self.formatException(record.exc_info)
# return json.dumps(log_entry)
#
# handler = logging.StreamHandler()
# handler.setFormatter(JSONFormatter())
# logger = logging.getLogger('my-app')
# logger.addHandler(handler)

# LogQL Queries in Grafana
# {app="my-app"} | json | level="error"
# {app="my-app"} | json | latency_ms > 500
# {namespace="production"} |= "Exception"
# rate({app="my-app"} | json | level="error" [5m])

@dataclass
class LogQuery:
 name: str
 logql: str
 purpose: str
 alert: bool

queries = [
 LogQuery("Error Logs", '{app="my-app"} | json | level="error"', "ดู Error ทั้งหมด", True),
 LogQuery("Slow Requests", '{app="my-app"} | json | latency_ms > 500', "Request ที่ช้า", True),
 LogQuery("Exception Trace", '{app="my-app"} |= "Exception"', "ดู Stack Trace", False),
 LogQuery("Error Rate", 'rate({app="my-app"} | json | level="error" [5m])', "อัตรา Error", True),
 LogQuery("Request Volume", 'rate({app="my-app"} [1m])', "ปริมาณ Request", False),
]

print("\n=== LogQL Queries ===")
for q in queries:
 alert_tag = "[ALERT]" if q.alert else ""
 print(f" [{q.name}] {alert_tag}")
 print(f" Query: {q.logql}")
 print(f" Purpose: {q.purpose}")

Alerting

# === Alerting Configuration ===

# PrometheusRule — Alert Definitions
# apiVersion: monitoring.coreos.com/v1
# kind: PrometheusRule
# metadata:
# name: my-app-alerts
# labels:
# release: monitoring
# spec:
# groups:
# - name: my-app
# rules:
# - alert: HighErrorRate
# expr: rate(http_requests_total{status=~"5.."}[5m]) > 0.05
# for: 5m
# labels:
# severity: critical
# annotations:
# summary: "High error rate on {{ $labels.instance }}"
# description: "Error rate is {{ $value | humanizePercentage }}"
#
# - alert: HighLatency
# expr: histogram_quantile(0.99, rate(http_request_duration_seconds_bucket[5m])) > 0.5
# for: 5m
# labels:
# severity: warning
#
# - alert: PodCrashLooping
# expr: rate(kube_pod_container_status_restarts_total[15m]) > 0
# for: 5m
# labels:
# severity: critical

# Alertmanager — Slack Notification
# apiVersion: monitoring.coreos.com/v1alpha1
# kind: AlertmanagerConfig
# spec:
# route:
# receiver: slack
# groupBy: [alertname, namespace]
# groupWait: 30s
# groupInterval: 5m
# repeatInterval: 4h
# receivers:
# - name: slack
# slackConfigs:
# - channel: '#alerts'
# apiURL: 'https://hooks.slack.com/services/...'
# title: '[{{ .Status }}] {{ .CommonLabels.alertname }}'
# text: '{{ .CommonAnnotations.description }}'

@dataclass
class AlertRule:
 name: str
 condition: str
 severity: str
 action: str
 notification: str

alerts = [
 AlertRule("HighErrorRate", "5xx > 5% for 5min", "Critical", "Investigate immediately", "Slack + PagerDuty"),
 AlertRule("HighLatency", "p99 > 500ms for 5min", "Warning", "Check slow endpoints", "Slack"),
 AlertRule("PodCrashLooping", "Restart > 0 in 15min", "Critical", "Check pod logs", "Slack + PagerDuty"),
 AlertRule("HighCPU", "CPU > 80% for 10min", "Warning", "Scale up or optimize", "Slack"),
 AlertRule("HighMemory", "Memory > 85% for 5min", "Warning", "Check memory leaks", "Slack"),
 AlertRule("DiskFull", "Disk > 90%", "Critical", "Clean up or expand", "Slack + PagerDuty"),
]

print("Alert Rules:")
for a in alerts:
 print(f" [{a.severity}] {a.name}")
 print(f" Condition: {a.condition}")
 print(f" Action: {a.action} | Notify: {a.notification}")

เคล็ดลับ

• Metrics: เก็บ RED Metrics (Rate Errors Duration) ทุก Service
• Structured Log: ใช้ JSON Log Format ค้นหาง่าย
• Alert: ตั้ง Alert เฉพาะที่ต้อง Action ไม่ Alert มากจนชิน
• Dashboard: สร้าง Dashboard สำหรับทุก Service ดูภาพรวม
• Dev Parity: ใช้ Monitoring เหมือนกันทั้ง Dev และ Production

Skaffold Dev Monitoring คืออะไร

ตรวจสอบสถานะ Application Dev Skaffold Pod Status Log Port Forwarding Prometheus Grafana Loki Alertmanager Metrics Dashboard Bug Performance

สรุป

Skaffold Dev Monitoring Alerting Prometheus Grafana Loki Log Aggregation Health Check Observability Metrics Dashboard Alert PromQL LogQL Production
