Segment Routing Micro-segmentation

Segment Routing Micro-segmentation

Segment Routing SR-MPLS SRv6 Source Routing Segments Labels SIDs Micro-segmentation Zero Trust East-West Traffic Lateral Movement Policy Enforcement Network Security

Segment Routing Configuration

# === Segment Routing Configuration ===

# Cisco IOS-XR — SR-MPLS Configuration
# router isis CORE
#  address-family ipv4 unicast
#   segment-routing mpls
#  !
#  interface Loopback0
#   address-family ipv4 unicast
#    prefix-sid index 100
#   !
#  !
#  interface GigabitEthernet0/0/0/0
#   address-family ipv4 unicast
#    prefix-sid index 101
#   !
#  !
# !
#
# segment-routing
#  traffic-eng
#   segment-list SL-TO-PE2
#    index 10 mpls label 16002
#    index 20 mpls label 16003
#   !
#   policy SR-POLICY-1
#    color 100 end-point ipv4 10.0.0.2
#    candidate-paths
#     preference 100
#      explicit segment-list SL-TO-PE2
#      !
#     !
#    !
#   !
#  !
# !

# Linux SRv6 Configuration
# ip -6 route add fc00:2::/48 encap seg6 mode encap \
#   segs fc00:1::100, fc00:3::200 dev eth0
#
# # SRv6 End function
# ip -6 route add fc00:1::100/128 encap seg6local \
#   action End dev eth0
#
# # SRv6 End.DX4 (Decapsulate to IPv4)
# ip -6 route add fc00:1::200/128 encap seg6local \
#   action End.DX4 nh4 10.0.0.1 dev eth0

from dataclasses import dataclass, field
from typing import List, Dict

@dataclass
class SRSegment:
    sid: str
    type: str
    node: str
    action: str

@dataclass
class SRPolicy:
    name: str
    color: int
    endpoint: str
    segments: List[SRSegment]
    bandwidth_mbps: int
    priority: int

policies = [
    SRPolicy("Voice-Traffic", 10, "10.0.0.5", [
        SRSegment("16001", "Prefix-SID", "PE1", "Forward"),
        SRSegment("16003", "Prefix-SID", "P1", "Forward"),
        SRSegment("16005", "Prefix-SID", "PE2", "Forward"),
    ], 100, 1),
    SRPolicy("Data-Traffic", 20, "10.0.0.5", [
        SRSegment("16001", "Prefix-SID", "PE1", "Forward"),
        SRSegment("16002", "Prefix-SID", "P2", "Forward"),
        SRSegment("16004", "Prefix-SID", "P3", "Forward"),
        SRSegment("16005", "Prefix-SID", "PE2", "Forward"),
    ], 1000, 2),
]

print("=== SR Policies ===")
for p in policies:
    path = " -> ".join([s.node for s in p.segments])
    print(f"\n  [{p.name}] Color: {p.color} | Priority: {p.priority}")
    print(f"    Endpoint: {p.endpoint} | BW: {p.bandwidth_mbps} Mbps")
    print(f"    Path: {path}")

Micro-segmentation Policy

# === Micro-segmentation Implementation ===

# VMware NSX Micro-segmentation Rules (DFW)
# - name: "Web to App"
#   source: "web-tier"
#   destination: "app-tier"
#   service: "TCP/8080, TCP/8443"
#   action: "Allow"
#   logged: true
#
# - name: "App to DB"
#   source: "app-tier"
#   destination: "db-tier"
#   service: "TCP/5432, TCP/3306"
#   action: "Allow"
#   logged: true
#
# - name: "Web to DB"
#   source: "web-tier"
#   destination: "db-tier"
#   service: "Any"
#   action: "Deny"
#   logged: true
#
# - name: "Default Deny"
#   source: "Any"
#   destination: "Any"
#   service: "Any"
#   action: "Deny"
#   logged: true

# Kubernetes Network Policy
# apiVersion: networking.k8s.io/v1
# kind: NetworkPolicy
# metadata:
#   name: allow-app-to-db
#   namespace: production
# spec:
#   podSelector:
#     matchLabels:
#       tier: database
#   policyTypes:
#   - Ingress
#   ingress:
#   - from:
#     - podSelector:
#         matchLabels:
#           tier: application
#     ports:
#     - protocol: TCP
#       port: 5432

from dataclasses import dataclass
from typing import List
from enum import Enum

class Action(Enum):
    ALLOW = "Allow"
    DENY = "Deny"
    LOG = "Log & Allow"

@dataclass
class MicroSegRule:
    name: str
    source: str
    destination: str
    ports: str
    action: Action
    logged: bool

rules = [
    MicroSegRule("Web -> App", "web-tier", "app-tier", "8080,8443", Action.ALLOW, True),
    MicroSegRule("App -> DB", "app-tier", "db-tier", "5432,3306", Action.ALLOW, True),
    MicroSegRule("App -> Cache", "app-tier", "cache-tier", "6379", Action.ALLOW, True),
    MicroSegRule("Web -> DB", "web-tier", "db-tier", "Any", Action.DENY, True),
    MicroSegRule("External -> DB", "external", "db-tier", "Any", Action.DENY, True),
    MicroSegRule("Default Deny", "Any", "Any", "Any", Action.DENY, True),
]

print("\n=== Micro-segmentation Rules ===")
for r in rules:
    print(f"  [{r.action.value}] {r.name}")
    print(f"    {r.source} -> {r.destination} : {r.ports} "
          f"{'(Logged)' if r.logged else ''}")

Zero Trust Architecture

# === Zero Trust Network Architecture ===

zt_pillars = {
    "Identity": {
        "desc": "ยืนยันตัวตนทุก User และ Device",
        "tools": "Azure AD, Okta, Auth0",
        "controls": "MFA, SSO, Conditional Access",
    },
    "Device": {
        "desc": "ตรวจสอบสถานะอุปกรณ์",
        "tools": "Intune, CrowdStrike, Carbon Black",
        "controls": "Device Health, Compliance, EDR",
    },
    "Network": {
        "desc": "แบ่งส่วนและควบคุม Traffic",
        "tools": "NSX, Illumio, Calico, Cilium",
        "controls": "Micro-segmentation, Encryption, SR",
    },
    "Application": {
        "desc": "ควบคุมการเข้าถึง Application",
        "tools": "ZTNA, Service Mesh, API Gateway",
        "controls": "mTLS, RBAC, Rate Limiting",
    },
    "Data": {
        "desc": "ปกป้องข้อมูลทุกที่",
        "tools": "DLP, Encryption, Tokenization",
        "controls": "Classification, Access Control, Audit",
    },
}

print("Zero Trust Pillars:")
for pillar, info in zt_pillars.items():
    print(f"\n  [{pillar}]")
    for k, v in info.items():
        print(f"    {k}: {v}")

# Implementation Steps
steps = [
    "1. Map — ระบุ Assets, Data Flows, Dependencies ทั้งหมด",
    "2. Identify — กำหนด Protect Surface (ข้อมูล/ระบบสำคัญ)",
    "3. Architect — ออกแบบ Micro-perimeters รอบ Protect Surface",
    "4. Policy — สร้าง Granular Access Policies (Who, What, When, How)",
    "5. Monitor — ติดตาม Traffic, Anomaly, Compliance ตลอดเวลา",
    "6. Automate — Automate Policy Enforcement, Response",
    "7. Iterate — ปรับปรุง Policies ต่อเนื่องจาก Analytics",
]

print(f"\n\nZero Trust Implementation:")
for step in steps:
    print(f"  {step}")

เคล็ดลับ

• Default Deny: เริ่มจาก Deny All แล้วค่อยเปิด Allow ตามที่จำเป็น
• East-West: ควบคุม East-West Traffic ไม่ใช่แค่ North-South
• Logging: Log ทุก Rule สำหรับ Troubleshooting และ Audit
• Automate: ใช้ Automation สร้าง Policies จาก Application Dependencies
• SRv6: พิจารณา SRv6 สำหรับ Network ใหม่ ยืดหยุ่นกว่า SR-MPLS

Segment Routing คืออะไร

Network Architecture Segments Labels SIDs Source Routing SR-MPLS SRv6 ลดความซับซ้อน ลด Protocol State
