Postman Newman MLOps Workflow

Newman MLOps Testing

Postman Newman MLOps Workflow API Testing CI/CD Collection Environment Contract Testing Health Check Model Deployment Rollback Production

Collection Design

# === Postman Collection for ML API ===

# Collection structure:
# ML-API-Tests/
# ├── Health/
# │   └── GET /health
# ├── Predict/
# │   ├── POST /predict (valid input)
# │   ├── POST /predict (invalid input)
# │   └── POST /predict (edge cases)
# ├── Batch/
# │   └── POST /batch-predict
# ├── Model Info/
# │   └── GET /model/info
# └── Auth/
#     ├── GET /predict (no token)
#     └── GET /predict (invalid token)

# Test Script Examples:
# // Health Check
# pm.test("Status 200", () => {
#     pm.response.to.have.status(200);
# });
# pm.test("Response time < 500ms", () => {
#     pm.expect(pm.response.responseTime).to.be.below(500);
# });
# pm.test("Status is healthy", () => {
#     var json = pm.response.json();
#     pm.expect(json.status).to.eql("healthy");
#     pm.expect(json.model_loaded).to.be.true;
# });

# // Predict Endpoint
# pm.test("Prediction response valid", () => {
#     var json = pm.response.json();
#     pm.expect(json).to.have.property("prediction");
#     pm.expect(json).to.have.property("confidence");
#     pm.expect(json.confidence).to.be.within(0, 1);
#     pm.expect(json).to.have.property("model_version");
# });
# pm.test("Latency within SLA", () => {
#     pm.expect(pm.response.responseTime).to.be.below(1000);
# });

# // Schema Validation
# var schema = {
#     type: "object",
#     required: ["prediction", "confidence", "model_version"],
#     properties: {
#         prediction: { type: "number" },
#         confidence: { type: "number", minimum: 0, maximum: 1 },
#         model_version: { type: "string" },
#         latency_ms: { type: "number" }
#     }
# };
# pm.test("Response matches schema", () => {
#     pm.response.to.have.jsonSchema(schema);
# });

from dataclasses import dataclass

@dataclass
class TestCase:
    name: str
    method: str
    endpoint: str
    body: str
    expected_status: int
    assertions: str

tests = [
    TestCase("Health Check", "GET", "/health", "None",
        200, "status=healthy, model_loaded=true"),
    TestCase("Valid Prediction", "POST", "/predict",
        '{"features": [1.2, 3.4, 5.6]}',
        200, "prediction exists, confidence 0-1"),
    TestCase("Invalid Input", "POST", "/predict",
        '{"features": "not_array"}',
        422, "error message, validation details"),
    TestCase("Missing Field", "POST", "/predict",
        '{}',
        422, "error: features required"),
    TestCase("Model Info", "GET", "/model/info", "None",
        200, "version, name, metrics"),
    TestCase("No Auth Token", "POST", "/predict",
        '{"features": [1.2]}',
        401, "error: unauthorized"),
    TestCase("Batch Predict", "POST", "/batch-predict",
        '{"instances": [[1.2,3.4],[5.6,7.8]]}',
        200, "predictions array, same length as input"),
]

print("=== Test Cases ===")
for t in tests:
    print(f"  [{t.name}] {t.method} {t.endpoint}")
    print(f"    Body: {t.body}")
    print(f"    Expected: {t.expected_status} | Assert: {t.assertions}")

CI/CD Integration

# === GitHub Actions + Newman ===

# .github/workflows/ml-api-test.yml
# name: ML API Tests
# on:
#   push:
#     branches: [main]
#   schedule:
#     - cron: '*/5 * * * *'  # Health check every 5 min
#
# jobs:
#   smoke-test:
#     runs-on: ubuntu-latest
#     steps:
#       - uses: actions/checkout@v4
#       - uses: actions/setup-node@v4
#         with: { node-version: '20' }
#       - run: npm install -g newman newman-reporter-htmlextra
#       - name: Run Smoke Tests
#         run: |
#           newman run tests/smoke.json \
#             -e tests/env/prod.json \
#             --reporters cli, junit, htmlextra \
#             --reporter-junit-export results/junit.xml \
#             --reporter-htmlextra-export results/report.html
#       - uses: actions/upload-artifact@v4
#         if: always()
#         with:
#           name: test-results
#           path: results/
#       - name: Alert on Failure
#         if: failure()
#         run: |
#           curl -X POST $SLACK_WEBHOOK \
#             -d '{"text":"ML API Smoke Test FAILED!"}'

# Environment file (prod.json)
# {
#   "values": [
#     {"key": "base_url", "value": "https://ml-api.example.com"},
#     {"key": "api_key", "value": "{{secrets.ML_API_KEY}}"},
#     {"key": "model_version", "value": "v2.1.0"},
#     {"key": "sla_latency_ms", "value": "1000"}
#   ]
# }

# Newman CLI Examples
# newman run collection.json                    # Basic run
# newman run collection.json -e prod.json       # With environment
# newman run collection.json -n 10              # Run 10 iterations
# newman run collection.json --delay-request 100 # 100ms delay between
# newman run collection.json --bail             # Stop on first failure
# newman run collection.json --timeout-request 5000  # 5s timeout

@dataclass
class CIStep:
    stage: str
    trigger: str
    newman_cmd: str
    on_fail: str

pipeline = [
    CIStep("Pre-deploy Health", "Before deploy",
        "newman run smoke.json -e staging.json --bail",
        "Abort deployment"),
    CIStep("Post-deploy Smoke", "After deploy",
        "newman run smoke.json -e prod.json",
        "Rollback to previous version"),
    CIStep("Contract Test", "After API change",
        "newman run contract.json -e prod.json",
        "Block merge, fix schema"),
    CIStep("Integration", "Nightly at 02:00",
        "newman run integration.json -e prod.json -n 5",
        "Create P2 ticket, alert team"),
    CIStep("Health Monitor", "Every 5 minutes",
        "newman run health.json -e prod.json --bail",
        "Page on-call, check infrastructure"),
]

print("\nCI/CD Pipeline:")
for c in pipeline:
    print(f"  [{c.stage}] Trigger: {c.trigger}")
    print(f"    Command: {c.newman_cmd}")
    print(f"    On fail: {c.on_fail}")

Monitoring and Reporting

# === Newman Monitoring Dashboard ===

@dataclass
class MonitorResult:
    endpoint: str
    status: str
    latency_ms: int
    tests_passed: int
    tests_failed: int
    timestamp: str

results = [
    MonitorResult("/health", "PASS", 45, 3, 0, "2024-01-15 10:00"),
    MonitorResult("/predict", "PASS", 230, 5, 0, "2024-01-15 10:00"),
    MonitorResult("/batch-predict", "PASS", 890, 4, 0, "2024-01-15 10:00"),
    MonitorResult("/model/info", "PASS", 35, 2, 0, "2024-01-15 10:00"),
    MonitorResult("/predict (invalid)", "PASS", 15, 3, 0, "2024-01-15 10:00"),
]

print("=== Latest Monitor Results ===")
total_passed = sum(r.tests_passed for r in results)
total_failed = sum(r.tests_failed for r in results)
for r in results:
    icon = "PASS" if r.status == "PASS" else "FAIL"
    print(f"  [{icon}] {r.endpoint} — {r.latency_ms}ms — {r.tests_passed}/{r.tests_passed + r.tests_failed} tests")

print(f"\n  Total: {total_passed} passed, {total_failed} failed")
print(f"  Pass rate: {total_passed/(total_passed+total_failed)*100:.0f}%")

# Newman reporters
reporters = {
    "cli": "Terminal output, default",
    "junit": "JUnit XML for CI integration",
    "htmlextra": "Beautiful HTML report with charts",
    "json": "JSON output for custom processing",
    "csv": "CSV export for spreadsheet analysis",
    "teamcity": "TeamCity service messages",
}

print(f"\n  Available Reporters:")
for k, v in reporters.items():
    print(f"    [{k}]: {v}")

เคล็ดลับ

• Bail: ใช้ --bail หยุดทันทีเมื่อ Test แรก Fail ประหยัดเวลา
• Environment: แยก Environment File ตาม dev staging prod
• Schema: ใช้ JSON Schema Validation ตรวจ Response Structure
• Version: ตรวจ Model Version ทุกครั้งหลัง Deploy
• Monitor: รัน Health Check ทุก 5 นาที แจ้งเตือนเมื่อ API Down

Newman คืออะไร

CLI Runner Postman Collection Command Line CI/CD Environment Reporter CLI HTML JSON JUnit npm Pre-request Test Script

สรุป

Postman Newman MLOps API Testing CI/CD Collection Environment Schema Validation Health Check Model Version Rollback Monitor Production
