Payload CMS Capacity Planning

Payload CMS Capacity Planning

Payload CMS Capacity Planning TypeScript Node.js MongoDB PostgreSQL CDN Redis Caching Sizing API Performance Production

Sizing Calculator

# === Payload CMS Capacity Calculator ===

from dataclasses import dataclass

@dataclass
class SizingInput:
    content_count: int
    avg_doc_size_kb: float
    media_count: int
    avg_media_size_mb: float
    api_rps: int
    admin_users: int

@dataclass
class SizingResult:
    db_storage_gb: float
    media_storage_gb: float
    node_instances: int
    cpu_per_instance: int
    ram_per_instance_gb: int
    db_connections: int
    redis_memory_gb: float

def calculate_sizing(inp: SizingInput) -> SizingResult:
    db_gb = (inp.content_count * inp.avg_doc_size_kb * 3) / (1024 * 1024)
    media_gb = (inp.media_count * inp.avg_media_size_mb * 1.5) / 1024
    if inp.api_rps <= 100:
        instances, cpu, ram = 1, 1, 1
    elif inp.api_rps <= 1000:
        instances, cpu, ram = 2, 2, 4
    elif inp.api_rps <= 10000:
        instances, cpu, ram = 4, 4, 8
    else:
        instances, cpu, ram = 8, 8, 16
    db_conn = instances * 10
    redis_gb = max(0.5, inp.api_rps * 0.001)
    return SizingResult(round(db_gb, 2), round(media_gb, 2),
        instances, cpu, ram, db_conn, round(redis_gb, 2))

scenarios = [
    ("Blog (Personal)", SizingInput(500, 5, 200, 2, 50, 2)),
    ("Corporate Site", SizingInput(5000, 10, 2000, 3, 500, 10)),
    ("E-commerce", SizingInput(50000, 15, 20000, 5, 5000, 50)),
    ("Enterprise Platform", SizingInput(500000, 20, 100000, 4, 20000, 200)),
]

print("=== Capacity Planning ===")
for name, inp in scenarios:
    r = calculate_sizing(inp)
    print(f"\n  [{name}]")
    print(f"    Content: {inp.content_count:,} docs | Media: {inp.media_count:,} files")
    print(f"    DB: {r.db_storage_gb} GB | Media: {r.media_storage_gb} GB")
    print(f"    Instances: {r.node_instances}x ({r.cpu_per_instance} vCPU {r.ram_per_instance_gb}GB)")
    print(f"    DB Connections: {r.db_connections} | Redis: {r.redis_memory_gb} GB")

Caching Architecture

# === Caching Strategy ===

# Payload Hook for Cache Invalidation
# // collections/Posts.ts
# const Posts: CollectionConfig = {
#   slug: 'posts',
#   hooks: {
#     afterChange: [
#       async ({ doc }) => {
#         // Purge CDN cache
#         await fetch(`https://api.cloudflare.com/client/v4/zones//purge_cache`, {
#           method: 'POST',
#           headers: { Authorization: `Bearer ` },
#           body: JSON.stringify({ files: [`https://example.com/api/posts/`] })
#         });
#         // Invalidate Redis cache
#         await redis.del(`posts:`);
#         await redis.del('posts:list');
#         // Trigger Next.js revalidation
#         await fetch(`https://frontend.com/api/revalidate?secret=&path=/blog/`);
#       }
#     ]
#   }
# };

@dataclass
class CacheLayer:
    layer: str
    tool: str
    ttl: str
    invalidation: str
    hit_rate: str

layers = [
    CacheLayer("CDN Edge",
        "Cloudflare / CloudFront",
        "60s (API) 1y (Media)",
        "Webhook Purge on afterChange",
        "70-90% (Static content)"),
    CacheLayer("Application (Redis)",
        "Redis 6+",
        "60-300s per content type",
        "redis.del on afterChange Hook",
        "50-80% (Dynamic queries)"),
    CacheLayer("Full Page (ISR)",
        "Next.js ISR / Vercel",
        "revalidate: 60-3600",
        "On-demand revalidation API",
        "90%+ (Static pages)"),
    CacheLayer("Browser",
        "HTTP Cache-Control ETag",
        "60s (API) 1y (Assets)",
        "ETag mismatch → 200 else 304",
        "High (repeat visitors)"),
    CacheLayer("Database",
        "MongoDB WiredTiger / PG shared_buffers",
        "Automatic (LRU)",
        "Automatic on write",
        "Depends on working set vs RAM"),
]

print("=== Caching Layers ===")
for c in layers:
    print(f"  [{c.layer}] Tool: {c.tool}")
    print(f"    TTL: {c.ttl}")
    print(f"    Invalidation: {c.invalidation}")
    print(f"    Hit Rate: {c.hit_rate}")

Monitoring

# === Production Monitoring ===

@dataclass
class MonitorMetric:
    metric: str
    source: str
    target: str
    alert: str

monitoring = [
    MonitorMetric("API Response Time P99",
        "Prometheus / APM (Datadog NewRelic)",
        "< 200ms (cached) < 500ms (uncached)",
        "> 1s → P2 Check DB Cache Instances"),
    MonitorMetric("API Throughput (RPS)",
        "Prometheus http_requests_total",
        "ตาม Sizing Target",
        "< 50% target → Check if underprovisioned"),
    MonitorMetric("Error Rate",
        "Prometheus http_errors_total / total",
        "< 0.1%",
        "> 1% → P1 Check Logs DB Connection"),
    MonitorMetric("Database Connection Pool",
        "MongoDB/PG metrics",
        "< 80% pool usage",
        "> 90% → P2 Increase Pool or Scale"),
    MonitorMetric("Cache Hit Rate",
        "Redis INFO stats / CDN Analytics",
        "> 60% Redis > 80% CDN",
        "< 30% → Review Cache Keys TTL"),
    MonitorMetric("Media Storage Usage",
        "S3/Disk metrics",
        "< 80% allocated",
        "> 90% → P3 Expand Storage Archive Old"),
]

print("=== Monitoring ===")
for m in monitoring:
    print(f"  [{m.metric}] Target: {m.target}")
    print(f"    Source: {m.source}")
    print(f"    Alert: {m.alert}")

เคล็ดลับ

• CDN: ใช้ CDN Cache API Response ลด Load 70-90%
• Redis: Cache Popular Queries ใน Redis TTL 60-300s
• Hook: ใช้ afterChange Hook Invalidate Cache อัตโนมัติ
• ISR: ใช้ Next.js ISR + On-demand Revalidation ลด API Load 90%+
• Index: สร้าง Database Index ตาม Query Pattern ทุกตัว

Payload CMS คืออะไร

Open Source Headless CMS TypeScript Node.js MongoDB PostgreSQL REST GraphQL Admin Panel Auth Upload Versioning Localization Hooks

สรุป

Payload CMS Capacity Planning TypeScript MongoDB PostgreSQL CDN Redis ISR Caching Hook Invalidation Sizing Monitoring Production
