mTLS Service Mesh SaaS Architecture

mTLS ใน Service Mesh

mTLS เข้ารหัสการสื่อสารสองทาง Client Server ยืนยันตัวตนด้วย Certificate Service Mesh จัดการอัตโนมัติ Istio Linkerd Consul Connect

SaaS Architecture ใช้ mTLS ป้องกัน Service-to-Service Communication Zero Trust ไม่เชื่อใจอะไรเลย ทุก Request ยืนยันตัวตน

Istio mTLS Configuration

# === Istio mTLS Configuration ===

# 1. Install Istio
# curl -L https://istio.io/downloadIstio | sh -
# cd istio-1.21.0
# export PATH=$PWD/bin:$PATH
# istioctl install --set profile=demo -y

# 2. Enable Sidecar Injection
# kubectl label namespace default istio-injection=enabled

# 3. PeerAuthentication — บังคับ mTLS ทั้ง Namespace
# apiVersion: security.istio.io/v1beta1
# kind: PeerAuthentication
# metadata:
#   name: default
#   namespace: default
# spec:
#   mtls:
#     mode: STRICT  # STRICT = บังคับ mTLS, PERMISSIVE = ยอมรับทั้ง mTLS และ plaintext

# 4. PeerAuthentication — Mesh-wide (ทั้ง Cluster)
# apiVersion: security.istio.io/v1beta1
# kind: PeerAuthentication
# metadata:
#   name: default
#   namespace: istio-system
# spec:
#   mtls:
#     mode: STRICT

# 5. DestinationRule — บังคับ mTLS เมื่อเรียก Service
# apiVersion: networking.istio.io/v1beta1
# kind: DestinationRule
# metadata:
#   name: api-service
# spec:
#   host: api-service.default.svc.cluster.local
#   trafficPolicy:
#     tls:
#       mode: ISTIO_MUTUAL  # ใช้ Istio certificates

# 6. AuthorizationPolicy — Zero Trust
# apiVersion: security.istio.io/v1beta1
# kind: AuthorizationPolicy
# metadata:
#   name: api-policy
#   namespace: default
# spec:
#   selector:
#     matchLabels:
#       app: api-service
#   action: ALLOW
#   rules:
#   - from:
#     - source:
#         principals: ["cluster.local/ns/default/sa/frontend-sa"]
#     to:
#     - operation:
#         methods: ["GET", "POST"]
#         paths: ["/api/*"]

# 7. ตรวจสอบ mTLS Status
# istioctl x describe pod
# istioctl proxy-config secret
# istioctl analyze

# 8. Kiali Dashboard (Visualization)
# istioctl dashboard kiali

from dataclasses import dataclass
from typing import List

@dataclass
class IstioConfig:
    name: str
    kind: str
    namespace: str
    description: str

configs = [
    IstioConfig("default-mtls", "PeerAuthentication", "default",
                "บังคับ mTLS ทั้ง Namespace"),
    IstioConfig("mesh-mtls", "PeerAuthentication", "istio-system",
                "บังคับ mTLS ทั้ง Mesh"),
    IstioConfig("api-dr", "DestinationRule", "default",
                "บังคับ mTLS เมื่อเรียก API Service"),
    IstioConfig("api-policy", "AuthorizationPolicy", "default",
                "อนุญาตเฉพาะ Frontend เรียก API"),
]

print("Istio mTLS Configuration:")
for c in configs:
    print(f"  [{c.kind}] {c.name}")
    print(f"    Namespace: {c.namespace}")
    print(f"    {c.description}")

SaaS Architecture with Service Mesh

# saas_architecture.py — SaaS Architecture with mTLS
from dataclasses import dataclass, field
from typing import List, Dict

@dataclass
class MicroService:
    name: str
    namespace: str
    replicas: int
    port: int
    service_account: str
    allowed_callers: List[str]
    mtls: str = "STRICT"

class SaaSArchitecture:
    """SaaS Architecture with Service Mesh"""

    def __init__(self):
        self.services: List[MicroService] = []
        self.tenants: List[str] = []

    def add_service(self, svc: MicroService):
        self.services.append(svc)

    def add_tenant(self, tenant: str):
        self.tenants.append(tenant)

    def generate_auth_policies(self):
        """Generate AuthorizationPolicy for each service"""
        print(f"\n{'='*55}")
        print(f"AuthorizationPolicies (Zero Trust)")
        print(f"{'='*55}")

        for svc in self.services:
            print(f"\n  [{svc.name}]")
            print(f"    ServiceAccount: {svc.service_account}")
            print(f"    mTLS: {svc.mtls}")
            print(f"    Allowed Callers:")
            for caller in svc.allowed_callers:
                print(f"      - {caller}")

    def architecture_diagram(self):
        """Show Architecture"""
        print(f"\n{'='*55}")
        print(f"SaaS Architecture — Service Mesh")
        print(f"{'='*55}")

        layers = {
            "Edge": ["API Gateway (Kong/Nginx)", "WAF", "Rate Limiting"],
            "Frontend": ["Web App (React)", "Mobile BFF"],
            "API": ["Auth Service", "User Service", "Billing Service"],
            "Core": ["Order Service", "Product Service", "Notification Service"],
            "Data": ["PostgreSQL", "Redis", "Kafka", "S3"],
            "Observability": ["Prometheus", "Grafana", "Jaeger", "Kiali"],
        }

        for layer, components in layers.items():
            print(f"\n  [{layer} Layer]")
            for comp in components:
                print(f"    - {comp}")

    def tenant_isolation(self):
        """Tenant Isolation Strategy"""
        strategies = {
            "Namespace per Tenant": "แต่ละ Tenant มี Namespace แยก mTLS แยก",
            "Shared Services + Headers": "Services ร่วมกัน แยกด้วย Tenant Header",
            "Database per Tenant": "แต่ละ Tenant มี Database แยก",
            "Schema per Tenant": "Database เดียว แยก Schema ต่อ Tenant",
            "Row-level Security": "Table เดียว แยกด้วย tenant_id column",
        }

        print(f"\n  Tenant Isolation Strategies:")
        for strategy, desc in strategies.items():
            print(f"    {strategy}: {desc}")

# ตัวอย่าง
arch = SaaSArchitecture()

services = [
    MicroService("api-gateway", "edge", 3, 8080, "gateway-sa",
                ["istio-ingressgateway"]),
    MicroService("auth-service", "auth", 3, 8081, "auth-sa",
                ["api-gateway"]),
    MicroService("user-service", "core", 2, 8082, "user-sa",
                ["api-gateway", "auth-service"]),
    MicroService("billing-service", "billing", 2, 8083, "billing-sa",
                ["api-gateway", "order-service"]),
    MicroService("order-service", "core", 3, 8084, "order-sa",
                ["api-gateway", "billing-service"]),
    MicroService("notification-service", "core", 2, 8085, "notification-sa",
                ["order-service", "billing-service"]),
]

for svc in services:
    arch.add_service(svc)

arch.architecture_diagram()
arch.generate_auth_policies()
arch.tenant_isolation()

Certificate Management และ Monitoring

# === Certificate Management ===

# 1. Istio CA (Built-in)
# Istio จัดการ Certificates อัตโนมัติ
# - Root CA: istiod สร้างและจัดการ
# - Workload Certificates: ออกให้ทุก Pod อัตโนมัติ
# - Auto-rotation: หมุนเวียน Certificate อัตโนมัติ (24 ชม.)
# - SPIFFE Identity: spiffe://cluster.local/ns//sa/

# 2. External CA (cert-manager)
# apiVersion: cert-manager.io/v1
# kind: Certificate
# metadata:
#   name: istio-ca
#   namespace: istio-system
# spec:
#   isCA: true
#   duration: 8760h  # 1 year
#   secretName: istio-ca-secret
#   issuerRef:
#     name: vault-issuer
#     kind: ClusterIssuer
#   commonName: istio-ca

# 3. Vault Integration
# apiVersion: cert-manager.io/v1
# kind: ClusterIssuer
# metadata:
#   name: vault-issuer
# spec:
#   vault:
#     path: pki/sign/istio
#     server: https://vault.company.com
#     auth:
#       kubernetes:
#         role: cert-manager
#         mountPath: /v1/auth/kubernetes

# 4. Monitoring mTLS
# Prometheus Queries:
# istio_requests_total{connection_security_policy="mutual_tls"}
# istio_tcp_connections_opened_total
# envoy_cluster_ssl_handshake

# 5. Grafana Dashboard
# Import Istio dashboards:
# - Istio Mesh Dashboard (ID: 7639)
# - Istio Service Dashboard (ID: 7636)
# - Istio Workload Dashboard (ID: 7630)

# 6. Jaeger Tracing
# istioctl dashboard jaeger

# 7. Security Audit
# istioctl analyze --all-namespaces
# istioctl proxy-config secret  -o json
# kubectl get peerauthentication --all-namespaces
# kubectl get authorizationpolicy --all-namespaces

cert_management = {
    "Istio CA": "Built-in CA, Auto-rotation ทุก 24 ชม.",
    "cert-manager": "External CA, Vault, Let's Encrypt",
    "SPIFFE": "Identity: spiffe://cluster.local/ns/xxx/sa/yyy",
    "Rotation": "อัตโนมัติ ไม่ต้อง Restart Pods",
}

monitoring = {
    "Kiali": "Service Mesh Visualization, mTLS Status",
    "Prometheus": "Metrics: requests, connections, SSL handshakes",
    "Grafana": "Dashboards: Mesh, Service, Workload",
    "Jaeger": "Distributed Tracing ระหว่าง Services",
}

print("Certificate Management:")
for tool, desc in cert_management.items():
    print(f"  {tool}: {desc}")

print(f"\nMonitoring:")
for tool, desc in monitoring.items():
    print(f"  {tool}: {desc}")

Best Practices

• STRICT mTLS: บังคับ mTLS ทั้ง Mesh ไม่ใช้ PERMISSIVE ใน Production
• AuthorizationPolicy: กำหนด Zero Trust ทุก Service ระบุ Callers ชัดเจน
• Certificate Rotation: ตั้ง Auto-rotation สั้น (24 ชม.) ลด Risk
• Namespace Isolation: แยก Namespace ตาม Tenant หรือ Team
• Monitoring: ใช้ Kiali ดู mTLS Status, Prometheus Metrics, Jaeger Tracing
• Audit: รัน istioctl analyze ตรวจสอบ Configuration เป็นประจำ

mTLS คืออะไร

Mutual TLS เข้ารหัสสองทาง Client Server ยืนยันตัวตน Certificate Service-to-Service Communication ป้องกัน Man-in-the-Middle Attack

สรุป

mTLS เข้ารหัสสองทาง Service Mesh จัดการอัตโนมัติ Istio Envoy Sidecar PeerAuthentication STRICT AuthorizationPolicy Zero Trust Certificate Auto-rotation SaaS Tenant Isolation Monitoring Kiali Prometheus Grafana Jaeger
