LLM Inference vLLM Micro-segmentation

vLLM Micro-segmentation

vLLM LLM Inference PagedAttention Continuous Batching Micro-segmentation Zero Trust Network Policy Calico Cilium Kubernetes GPU Model Serving OpenAI API

vLLM Deployment

# === vLLM Setup ===

# Install
# pip install vllm

# Run vLLM Server
# python -m vllm.entrypoints.openai.api_server \
# --model meta-llama/Llama-3.1-8B-Instruct \
# --tensor-parallel-size 1 \
# --gpu-memory-utilization 0.9 \
# --max-model-len 8192 \
# --port 8000

# Docker
# docker run --gpus all \
# -v ~/.cache/huggingface:/root/.cache/huggingface \
# -p 8000:8000 \
# vllm/vllm-openai:latest \
# --model meta-llama/Llama-3.1-8B-Instruct

# Kubernetes Deployment
# apiVersion: apps/v1
# kind: Deployment
# metadata:
# name: vllm-llama
# namespace: ai-inference
# spec:
# replicas: 2
# selector:
# matchLabels: { app: vllm-llama }
# template:
# spec:
# containers:
# - name: vllm
# image: vllm/vllm-openai:latest
# args:
# - "--model"
# - "meta-llama/Llama-3.1-8B-Instruct"
# - "--tensor-parallel-size"
# - "1"
# resources:
# limits:
# nvidia.com/gpu: 1
# ports:
# - containerPort: 8000

# OpenAI Compatible API Call
# import openai
# client = openai.OpenAI(base_url="http://vllm:8000/v1", api_key="dummy")
# response = client.chat.completions.create(
# model="meta-llama/Llama-3.1-8B-Instruct",
# messages=[{"role": "user", "content": "Hello"}],
# max_tokens=512,
# )
# print(response.choices[0].message.content)

from dataclasses import dataclass

@dataclass
class ModelConfig:
 model: str
 gpu: str
 vram_gb: int
 throughput_tps: int
 latency_ms: int
 cost_hr: float

models = [
 ModelConfig("Llama-3.1-8B", "A100 80GB", 16, 150, 45, 3.40),
 ModelConfig("Llama-3.1-70B", "A100 80GB x2", 140, 40, 120, 6.80),
 ModelConfig("Mistral-7B", "A10G 24GB", 14, 180, 35, 1.02),
 ModelConfig("Qwen2-72B", "A100 80GB x2", 145, 35, 130, 6.80),
 ModelConfig("Phi-3-mini-4k", "T4 16GB", 8, 200, 25, 0.53),
]

print("=== vLLM Model Configs ===")
for m in models:
 print(f" [{m.model}] {m.gpu}")
 print(f" VRAM: {m.vram_gb}GB | TPS: {m.throughput_tps} | Latency: {m.latency_ms}ms | /hr")

Micro-segmentation Policy

# === Kubernetes Network Policy ===

# Calico Network Policy — Restrict LLM Pod
# apiVersion: projectcalico.org/v3
# kind: NetworkPolicy
# metadata:
# name: vllm-inference-policy
# namespace: ai-inference
# spec:
# selector: app == 'vllm-llama'
# types: [Ingress, Egress]
# ingress:
# - action: Allow
# source:
# selector: app == 'api-gateway'
# destination:
# ports: [8000]
# egress:
# - action: Allow
# destination:
# selector: app == 'model-cache'
# ports: [6379]
# - action: Deny

# Cilium Network Policy
# apiVersion: cilium.io/v2
# kind: CiliumNetworkPolicy
# metadata:
# name: vllm-l7-policy
# namespace: ai-inference
# spec:
# endpointSelector:
# matchLabels: { app: vllm-llama }
# ingress:
# - fromEndpoints:
# - matchLabels: { app: api-gateway }
# toPorts:
# - ports: [{ port: "8000", protocol: TCP }]
# rules:
# http:
# - method: POST
# path: "/v1/chat/completions"
# - method: GET
# path: "/health"

@dataclass
class NetworkRule:
 name: str
 direction: str
 source: str
 destination: str
 port: int
 action: str

rules = [
 NetworkRule("API -> vLLM", "Ingress", "api-gateway", "vllm-llama", 8000, "Allow"),
 NetworkRule("vLLM -> Cache", "Egress", "vllm-llama", "model-cache", 6379, "Allow"),
 NetworkRule("vLLM -> Metrics", "Egress", "vllm-llama", "prometheus", 9090, "Allow"),
 NetworkRule("vLLM -> Internet", "Egress", "vllm-llama", "0.0.0.0/0", 443, "Deny"),
 NetworkRule("vLLM -> Other Pods", "Egress", "vllm-llama", "*", 0, "Deny"),
 NetworkRule("Other -> vLLM", "Ingress", "*", "vllm-llama", 8000, "Deny"),
]

print("\n=== Network Policies ===")
for r in rules:
 print(f" [{r.action}] {r.name}")
 print(f" {r.direction}: {r.source} -> {r.destination}:{r.port}")

Production Architecture

# === Production LLM + Zero Trust ===

# Architecture:
# Client -> WAF -> API Gateway (auth+rate limit)
# -> vLLM Pod (GPU, Network Policy isolated)
# -> Response -> Client
#
# Monitoring: Prometheus -> Grafana
# Logging: vLLM -> Fluentbit -> Elasticsearch
# Audit: API Gateway logs all requests

# Rate Limiting & Token Budget
# apiVersion: gateway.networking.k8s.io/v1
# kind: HTTPRoute
# metadata:
# name: llm-route
# spec:
# rules:
# - matches:
# - path: { value: "/v1/chat/completions" }
# filters:
# - type: ExtensionRef
# extensionRef:
# name: rate-limit-100rpm
# backendRefs:
# - name: vllm-service
# port: 8000

security_layers = {
 "WAF": "Block SQL Injection, XSS, Bot Detection",
 "API Gateway": "Authentication, Rate Limiting, Token Budget",
 "Network Policy": "Micro-segmentation, Ingress/Egress Control",
 "Pod Security": "Non-root, Read-only FS, No Privilege Escalation",
 "Encryption": "mTLS between services, TLS 1.3 external",
 "Audit Log": "All API calls logged with user, tokens, cost",
 "Model Protection": "Weights encrypted at rest, no egress allowed",
}

print("Zero Trust Security Layers:")
for layer, desc in security_layers.items():
 print(f" [{layer}]: {desc}")

# Cost Monitoring
costs = {
 "GPU (A100 x2)": "$6.80/hr = $4,896/mo",
 "API Gateway": "$50/mo",
 "Monitoring": "$30/mo",
 "Network (egress)": "$100/mo",
 "Total": "~$5,076/mo",
 "Cost per 1M tokens": "~$0.15 (vs OpenAI $3.00)",
 "Savings": "95% vs OpenAI API",
}

print(f"\n\nCost Analysis:")
for item, cost in costs.items():
 print(f" {item}: {cost}")

เคล็ดลับ

• PagedAttention: vLLM ใช้ Memory ดีกว่า ใส่ Model ใหญ่ขึ้นได้
• Deny All: เริ่มจาก Deny All แล้ว Allow เฉพาะที่ต้องการ
• Rate Limit: จำกัด Request ต่อ User ป้องกัน Abuse
• Egress Block: ห้าม LLM Pod เข้าถึง Internet ป้องกัน Data Leak
• Audit: Log ทุก Request สำหรับ Compliance และ Cost Tracking

vLLM คืออะไร

LLM Inference Engine PagedAttention Continuous Batching Throughput 10-24x OpenAI Compatible Llama Mistral Qwen GPU Serving

สรุป

vLLM LLM Inference PagedAttention Continuous Batching Micro-segmentation Zero Trust Calico Cilium Network Policy Kubernetes GPU OpenAI API Rate Limit Token Budget Security
