LLM Fine-tuning LoRA High Availability HA Setup

LLM LoRA HA

LLM Fine-tuning LoRA High Availability Low-Rank Adaptation Training Pipeline Model Serving vLLM TGI Kubernetes GPU Auto-scale Production Deployment

LoRA Training

# === LoRA Fine-tuning Pipeline ===

# pip install transformers peft datasets accelerate bitsandbytes trl

# from peft import LoraConfig, get_peft_model, TaskType
# from transformers import (
#     AutoModelForCausalLM, AutoTokenizer,
#     TrainingArguments, BitsAndBytesConfig
# )
# from trl import SFTTrainer
# from datasets import load_dataset
# import torch
#
# # QLoRA — 4-bit Quantization
# bnb_config = BitsAndBytesConfig(
#     load_in_4bit=True,
#     bnb_4bit_quant_type="nf4",
#     bnb_4bit_compute_dtype=torch.bfloat16,
#     bnb_4bit_use_double_quant=True,
# )
#
# # Load Base Model
# model_name = "meta-llama/Llama-3.1-8B"
# model = AutoModelForCausalLM.from_pretrained(
#     model_name,
#     quantization_config=bnb_config,
#     device_map="auto",
#     trust_remote_code=True,
# )
# tokenizer = AutoTokenizer.from_pretrained(model_name)
# tokenizer.pad_token = tokenizer.eos_token
#
# # LoRA Configuration
# lora_config = LoraConfig(
#     r=16,                          # Rank
#     lora_alpha=32,                 # Alpha = 2x Rank
#     target_modules=["q_proj", "k_proj", "v_proj", "o_proj"],
#     lora_dropout=0.05,
#     bias="none",
#     task_type=TaskType.CAUSAL_LM,
# )
#
# model = get_peft_model(model, lora_config)
# model.print_trainable_parameters()
# # trainable params: 13,107,200 || all params: 8,030,261,248 || trainable%: 0.163
#
# # Training Arguments
# training_args = TrainingArguments(
#     output_dir="./lora-llama-8b",
#     num_train_epochs=3,
#     per_device_train_batch_size=4,
#     gradient_accumulation_steps=4,
#     learning_rate=2e-4,
#     warmup_steps=100,
#     logging_steps=10,
#     save_steps=500,
#     evaluation_strategy="steps",
#     eval_steps=500,
#     bf16=True,
#     optim="paged_adamw_8bit",
# )

from dataclasses import dataclass

@dataclass
class LoRAExperiment:
    rank: int
    alpha: int
    targets: str
    params: str
    gpu_mem: str
    train_time: str
    eval_loss: float

experiments = [
    LoRAExperiment(8, 16, "q_proj v_proj", "6.5M", "12GB", "2h", 1.45),
    LoRAExperiment(16, 32, "q_proj k_proj v_proj o_proj", "13.1M", "14GB", "3h", 1.32),
    LoRAExperiment(32, 64, "q_proj k_proj v_proj o_proj", "26.2M", "16GB", "5h", 1.28),
    LoRAExperiment(64, 128, "all linear", "52.4M", "20GB", "8h", 1.25),
]

print("=== LoRA Experiments (LLaMA 8B) ===")
for e in experiments:
    print(f"  [r={e.rank} α={e.alpha}] Targets: {e.targets}")
    print(f"    Params: {e.params} | GPU: {e.gpu_mem} | Time: {e.train_time}")
    print(f"    Eval Loss: {e.eval_loss}")

HA Architecture

# === High Availability LLM Serving ===

# vLLM — High Performance Serving
# pip install vllm
# python -m vllm.entrypoints.openai.api_server \
#   --model meta-llama/Llama-3.1-8B \
#   --lora-modules my-lora=./lora-adapter \
#   --max-loras 4 \
#   --port 8000 \
#   --tensor-parallel-size 1

# Kubernetes Deployment — Multi-replica
# apiVersion: apps/v1
# kind: Deployment
# metadata:
#   name: llm-serving
# spec:
#   replicas: 3
#   selector:
#     matchLabels:
#       app: llm-serving
#   template:
#     spec:
#       containers:
#         - name: vllm
#           image: vllm/vllm-openai:latest
#           args:
#             - --model=meta-llama/Llama-3.1-8B
#             - --lora-modules=my-lora=/models/lora-adapter
#             - --max-model-len=4096
#           ports: [{containerPort: 8000}]
#           resources:
#             limits:
#               nvidia.com/gpu: 1
#           readinessProbe:
#             httpGet: {path: /health, port: 8000}
#             initialDelaySeconds: 120
#             periodSeconds: 10
#           livenessProbe:
#             httpGet: {path: /health, port: 8000}
#             initialDelaySeconds: 180
#             periodSeconds: 30

# HPA — Auto-scale on GPU
# apiVersion: autoscaling/v2
# kind: HorizontalPodAutoscaler
# metadata:
#   name: llm-hpa
# spec:
#   scaleTargetRef:
#     apiVersion: apps/v1
#     kind: Deployment
#     name: llm-serving
#   minReplicas: 2
#   maxReplicas: 8
#   metrics:
#     - type: Pods
#       pods:
#         metric: {name: gpu_utilization}
#         target: {type: AverageValue, averageValue: "70"}

@dataclass
class HAComponent:
    component: str
    technology: str
    purpose: str
    replicas: str
    failover: str

components = [
    HAComponent("Load Balancer", "Nginx / Traefik", "Route requests", "2 (active-passive)", "Auto failover"),
    HAComponent("Model Server", "vLLM / TGI", "Inference serving", "3-8 (GPU nodes)", "Health check + replace"),
    HAComponent("Model Registry", "MLflow / S3", "Store adapters", "Replicated storage", "Multi-region"),
    HAComponent("Cache", "Redis Cluster", "Cache responses", "3 nodes", "Sentinel failover"),
    HAComponent("Queue", "RabbitMQ / Redis", "Buffer requests", "3 nodes", "Mirror queues"),
    HAComponent("Monitoring", "Prometheus + Grafana", "GPU metrics latency", "2 replicas", "Alert on failure"),
]

print("\n=== HA Architecture ===")
for c in components:
    print(f"  [{c.component}] {c.technology}")
    print(f"    Purpose: {c.purpose} | Replicas: {c.replicas}")
    print(f"    Failover: {c.failover}")

Production Monitoring

# === Production LLM Metrics ===

@dataclass
class LLMMetric:
    metric: str
    value: str
    target: str
    alert: str

metrics = [
    LLMMetric("Inference Latency (p50)", "180ms", "<200ms", "> 500ms"),
    LLMMetric("Inference Latency (p99)", "850ms", "<1000ms", "> 2000ms"),
    LLMMetric("Throughput", "45 req/s", ">30 req/s", "< 15 req/s"),
    LLMMetric("GPU Utilization", "72%", "60-80%", "> 90%"),
    LLMMetric("GPU Memory", "85%", "<90%", "> 95%"),
    LLMMetric("Error Rate", "0.1%", "<0.5%", "> 1%"),
    LLMMetric("Cache Hit Rate", "35%", ">25%", "< 10%"),
    LLMMetric("Model Load Time", "45s", "<60s", "> 120s"),
    LLMMetric("Active Replicas", "3/3", "All healthy", "Any unhealthy"),
    LLMMetric("Token Cost/day", "$120", "<$200", "> $300"),
]

print("Production Metrics:")
for m in metrics:
    print(f"  {m.metric}: {m.value} (Target: {m.target} | Alert: {m.alert})")

deployment_checklist = {
    "Model Tested": "Eval loss < threshold, A/B test passed",
    "LoRA Adapter": "Uploaded to Model Registry with version tag",
    "Health Check": "Readiness + Liveness probes configured",
    "Auto-scale": "HPA on GPU utilization 70%",
    "Rollback": "Previous adapter version tagged for rollback",
    "Monitoring": "Prometheus metrics + Grafana dashboard",
    "Alerting": "PagerDuty for latency and error rate",
    "Blue-green": "New adapter deployed to canary first",
}

print(f"\n\nDeployment Checklist:")
for k, v in deployment_checklist.items():
    print(f"  [{k}]: {v}")

เคล็ดลับ

• QLoRA: ใช้ QLoRA 4-bit ถ้า GPU จำกัด ประหยัด Memory 4x
• Rank 16: เริ่มที่ Rank 16 Alpha 32 ปรับตามผลลัพธ์
• vLLM: ใช้ vLLM สำหรับ Production Serving เร็วกว่า HF 3-5x
• Replicas: Deploy อย่างน้อย 2 Replicas สำหรับ HA
• Canary: Deploy Adapter ใหม่แบบ Canary ก่อน Full Rollout

LoRA Fine-tuning คืออะไร

Low-Rank Adaptation ไม่อัปเดต Weight ทั้งหมด Low-rank Matrices Attention Layers ลด Parameters GPU น้อย Adapter เล็ก LLaMA Mistral

สรุป

LLM Fine-tuning LoRA QLoRA High Availability vLLM Kubernetes GPU Auto-scale Model Registry Canary Deployment Production Monitoring Inference Serving
