Linkerd Pub/Sub

Linkerd Service Mesh Pub Sub Architecture mTLS Observability Traffic Split NATS Kafka Microservices Event-driven Async Communication Canary Deployment

Linkerd Setup

# === Linkerd Installation ===

# Install CLI
# curl --proto '=https' --tlsv1.2 -sSfL https://run.linkerd.io/install | sh
# export PATH=$HOME/.linkerd2/bin:$PATH

# Pre-check
# linkerd check --pre

# Install to Kubernetes
# linkerd install --crds | kubectl apply -f -
# linkerd install | kubectl apply -f -
# linkerd check

# Install Viz (Dashboard)
# linkerd viz install | kubectl apply -f -
# linkerd viz dashboard &

# Inject sidecar to namespace
# kubectl annotate namespace default linkerd.io/inject=enabled
# kubectl rollout restart deployment -n default

# Verify mTLS
# linkerd viz edges deployment -n default
# linkerd viz tap deployment/my-app -n default

# Service Profile — Retry & Timeout
# apiVersion: linkerd.io/v1alpha2
# kind: ServiceProfile
# metadata:
#   name: my-api.default.svc.cluster.local
#   namespace: default
# spec:
#   routes:
#     - name: GET /api/orders
#       condition:
#         method: GET
#         pathRegex: /api/orders
#       isRetryable: true
#       timeout: 5s
#     - name: POST /api/orders
#       condition:
#         method: POST
#         pathRegex: /api/orders
#       timeout: 10s

from dataclasses import dataclass

@dataclass
class LinkerdFeature:
    feature: str
    description: str
    config: str
    impact: str

features = [
    LinkerdFeature("mTLS", "Auto encryption pod-to-pod", "Auto (inject sidecar)", "Security ไม่ต้องแก้ Code"),
    LinkerdFeature("Observability", "Golden metrics per route", "linkerd viz install", "Debug ง่ายขึ้นมาก"),
    LinkerdFeature("Traffic Split", "Canary % based routing", "TrafficSplit CRD", "Safe deployments"),
    LinkerdFeature("Retry", "Auto retry failed requests", "ServiceProfile isRetryable", "Higher success rate"),
    LinkerdFeature("Timeout", "Per-route timeout", "ServiceProfile timeout", "Prevent cascading failure"),
    LinkerdFeature("Circuit Breaker", "Fail fast on unhealthy", "ServiceProfile + budgets", "System resilience"),
]

print("=== Linkerd Features ===")
for f in features:
    print(f"  [{f.feature}] {f.description}")
    print(f"    Config: {f.config} | Impact: {f.impact}")

Pub/Sub with NATS

# === NATS Pub/Sub on Kubernetes ===

# Install NATS via Helm
# helm repo add nats https://nats-io.github.io/k8s/helm/charts/
# helm install nats nats/nats \
#   --set nats.jetstream.enabled=true \
#   --set nats.jetstream.memStorage.size=1Gi \
#   --set nats.jetstream.fileStorage.size=10Gi

# Python Publisher
# import nats
# import json
# import asyncio
#
# async def publish_order(order):
#     nc = await nats.connect("nats://nats:4222")
#     js = nc.jetstream()
#
#     # Create stream
#     await js.add_stream(name="ORDERS", subjects=["orders.*"])
#
#     # Publish
#     await js.publish(
#         f"orders.{order['type']}",
#         json.dumps(order).encode(),
#         headers={"Nats-Msg-Id": order["id"]},  # Dedup
#     )
#     await nc.close()

# Python Subscriber
# async def subscribe_orders():
#     nc = await nats.connect("nats://nats:4222")
#     js = nc.jetstream()
#
#     # Durable consumer
#     sub = await js.subscribe(
#         "orders.*",
#         durable="order-processor",
#         deliver_policy=nats.api.DeliverPolicy.ALL,
#     )
#
#     async for msg in sub.messages:
#         order = json.loads(msg.data.decode())
#         try:
#             process_order(order)
#             await msg.ack()
#         except Exception as e:
#             await msg.nak(delay=5)  # Retry after 5s

@dataclass
class PubSubBroker:
    broker: str
    delivery: str
    persistence: str
    throughput: str
    latency: str
    use_case: str

brokers = [
    PubSubBroker("NATS Core", "At-most-once", "No", "High", "< 1ms", "Real-time lightweight"),
    PubSubBroker("NATS JetStream", "At-least-once", "Yes", "High", "1-5ms", "Durable messaging"),
    PubSubBroker("Kafka", "At-least-once", "Yes (log)", "Very High", "5-50ms", "Event sourcing pipeline"),
    PubSubBroker("RabbitMQ", "At-least-once", "Yes", "Medium", "1-10ms", "Task queues routing"),
    PubSubBroker("Redis Pub/Sub", "At-most-once", "No", "Very High", "< 1ms", "Cache invalidation"),
]

print("\n=== Message Brokers ===")
for b in brokers:
    print(f"  [{b.broker}] Delivery: {b.delivery}")
    print(f"    Persist: {b.persistence} | Throughput: {b.throughput} | Latency: {b.latency}")
    print(f"    Use Case: {b.use_case}")

Production Architecture

# === Production Pub/Sub + Linkerd ===

# Traffic Split — Canary Consumer
# apiVersion: split.smi-spec.io/v1alpha2
# kind: TrafficSplit
# metadata:
#   name: order-consumer-split
# spec:
#   service: order-consumer
#   backends:
#     - service: order-consumer-stable
#       weight: 900   # 90%
#     - service: order-consumer-canary
#       weight: 100   # 10%

@dataclass
class ServiceMetric:
    service: str
    success_rate: str
    p50_latency: str
    p99_latency: str
    rps: str
    mtls: str

metrics = [
    ServiceMetric("order-api", "99.8%", "12ms", "85ms", "450", "Enabled"),
    ServiceMetric("order-consumer", "99.5%", "25ms", "180ms", "320", "Enabled"),
    ServiceMetric("nats-client", "99.9%", "1ms", "5ms", "1200", "Enabled"),
    ServiceMetric("payment-service", "99.7%", "45ms", "250ms", "180", "Enabled"),
    ServiceMetric("notification-svc", "99.2%", "8ms", "50ms", "500", "Enabled"),
]

print("Production Service Metrics (Linkerd Viz):")
for m in metrics:
    print(f"  [{m.service}] SR: {m.success_rate} | mTLS: {m.mtls}")
    print(f"    p50: {m.p50_latency} | p99: {m.p99_latency} | RPS: {m.rps}")

architecture = {
    "API Gateway": "Ingress → order-api (Linkerd injected)",
    "Pub/Sub": "order-api → NATS JetStream → order-consumer",
    "Async Processing": "order-consumer → payment-service → notification-svc",
    "Observability": "Linkerd Viz → Prometheus → Grafana",
    "Security": "mTLS auto all pod-to-pod + NATS TLS",
    "Resilience": "Retry + Timeout + Circuit Breaker per route",
}

print(f"\n\nArchitecture:")
for k, v in architecture.items():
    print(f"  [{k}]: {v}")

เคล็ดลับ

• Linkerd: เลือก Linkerd ถ้าต้องการ Lightweight ง่าย
• NATS: ใช้ JetStream สำหรับ Durable Messaging
• mTLS: Linkerd ให้ mTLS อัตโนมัติไม่ต้องแก้ Code
• Canary: ใช้ TrafficSplit ทดสอบ Consumer Version ใหม่
• Monitor: ดู Golden Metrics ทุก Service ใน Linkerd Viz

การนำความรู้ไปประยุกต์ใช้งานจริง

แหล่งเรียนรู้ที่แนะนำ ได้แก่ Official Documentation ที่อัพเดทล่าสุดเสมอ Online Course จาก Coursera Udemy edX ช่อง YouTube คุณภาพทั้งไทยและอังกฤษ และ Community อย่าง Discord Reddit Stack Overflow ที่ช่วยแลกเปลี่ยนประสบการณ์กับนักพัฒนาทั่วโลก
