LangChain Agent Micro-segmentation

LangChain Micro-segmentation

LangChain Agent Micro-segmentation AI Network Security Zero Trust Policy Automation ReAct GPT-4 Cilium Calico VMware NSX Lateral Movement Prevention

LangChain Agent Setup

# === LangChain Security Agent ===

# pip install langchain langchain-openai

# from langchain.agents import AgentExecutor, create_react_agent
# from langchain_openai import ChatOpenAI
# from langchain.tools import Tool
# from langchain.prompts import PromptTemplate
#
# # Tools for Network Security
# def analyze_traffic(query: str) -> str:
#     """Analyze network traffic patterns"""
#     # Query traffic database
#     return f"Traffic analysis: {query}"
#
# def create_policy(spec: str) -> str:
#     """Create Kubernetes NetworkPolicy"""
#     # Generate and apply policy
#     return f"Policy created: {spec}"
#
# def check_compliance(namespace: str) -> str:
#     """Check security compliance"""
#     # Verify policies
#     return f"Compliance check: {namespace}"
#
# def block_ip(ip: str) -> str:
#     """Block suspicious IP address"""
#     # Add to blocklist
#     return f"Blocked: {ip}"
#
# tools = [
#     Tool(name="TrafficAnalyzer", func=analyze_traffic,
#          description="Analyze network traffic patterns and anomalies"),
#     Tool(name="PolicyCreator", func=create_policy,
#          description="Create Kubernetes NetworkPolicy YAML"),
#     Tool(name="ComplianceChecker", func=check_compliance,
#          description="Check namespace security compliance"),
#     Tool(name="IPBlocker", func=block_ip,
#          description="Block suspicious IP address"),
# ]
#
# llm = ChatOpenAI(model="gpt-4o", temperature=0)
# agent = create_react_agent(llm, tools, prompt)
# executor = AgentExecutor(agent=agent, tools=tools, verbose=True)
#
# # Example: Auto-analyze and create policy
# result = executor.invoke({
#     "input": "Analyze traffic for namespace 'payment' and create "
#              "micro-segmentation policy allowing only required connections"
# })

from dataclasses import dataclass

@dataclass
class AgentTool:
    name: str
    function: str
    input_type: str
    output: str
    risk_level: str

agent_tools = [
    AgentTool("TrafficAnalyzer", "วิเคราะห์ Traffic Pattern", "Namespace/Pod", "Traffic Report", "Low"),
    AgentTool("PolicyCreator", "สร้าง NetworkPolicy", "Policy Spec", "YAML Applied", "Medium"),
    AgentTool("ComplianceChecker", "ตรวจ Compliance", "Namespace", "Compliance Score", "Low"),
    AgentTool("IPBlocker", "Block IP ที่น่าสงสัย", "IP Address", "Block Confirmed", "High"),
    AgentTool("LogAnalyzer", "วิเคราะห์ Security Log", "Time Range", "Threat Report", "Low"),
    AgentTool("VulnScanner", "Scan Vulnerabilities", "Target", "CVE List", "Medium"),
]

print("=== Agent Tools ===")
for t in agent_tools:
    print(f"  [{t.risk_level}] {t.name}")
    print(f"    Function: {t.function}")
    print(f"    Input: {t.input_type} | Output: {t.output}")

Kubernetes Network Policy

# === Micro-segmentation with Cilium ===

# Kubernetes NetworkPolicy — Deny All Default
# apiVersion: networking.k8s.io/v1
# kind: NetworkPolicy
# metadata:
#   name: default-deny-all
#   namespace: payment
# spec:
#   podSelector: {}
#   policyTypes:
#     - Ingress
#     - Egress

# Allow specific traffic — Payment Service
# apiVersion: networking.k8s.io/v1
# kind: NetworkPolicy
# metadata:
#   name: allow-payment-api
#   namespace: payment
# spec:
#   podSelector:
#     matchLabels:
#       app: payment-api
#   policyTypes:
#     - Ingress
#     - Egress
#   ingress:
#     - from:
#         - namespaceSelector:
#             matchLabels:
#               name: frontend
#         - podSelector:
#             matchLabels:
#               app: checkout
#       ports:
#         - protocol: TCP
#           port: 8080
#   egress:
#     - to:
#         - podSelector:
#             matchLabels:
#               app: payment-db
#       ports:
#         - protocol: TCP
#           port: 5432
#     - to:
#         - ipBlock:
#             cidr: 0.0.0.0/0
#       ports:
#         - protocol: TCP
#           port: 443  # Stripe API

# Cilium L7 Policy — HTTP Method Filtering
# apiVersion: cilium.io/v2
# kind: CiliumNetworkPolicy
# metadata:
#   name: payment-l7
# spec:
#   endpointSelector:
#     matchLabels:
#       app: payment-api
#   ingress:
#     - fromEndpoints:
#         - matchLabels:
#             app: checkout
#       toPorts:
#         - ports:
#             - port: "8080"
#           rules:
#             http:
#               - method: POST
#                 path: "/api/v1/charge"
#               - method: GET
#                 path: "/api/v1/status/.*"

@dataclass
class SegmentPolicy:
    namespace: str
    service: str
    allowed_ingress: str
    allowed_egress: str
    l7_filter: bool
    status: str

policies = [
    SegmentPolicy("payment", "payment-api", "checkout only", "payment-db + Stripe", True, "Enforced"),
    SegmentPolicy("payment", "payment-db", "payment-api only", "None (isolated)", False, "Enforced"),
    SegmentPolicy("frontend", "web-app", "ALB ingress", "api-gateway", False, "Enforced"),
    SegmentPolicy("backend", "api-gateway", "web-app + mobile", "All backend services", True, "Enforced"),
    SegmentPolicy("monitoring", "prometheus", "All namespaces (scrape)", "alertmanager", False, "Enforced"),
]

print("\n=== Segmentation Policies ===")
for p in policies:
    l7 = "L7" if p.l7_filter else "L3/L4"
    print(f"  [{p.status}] {p.namespace}/{p.service}")
    print(f"    Ingress: {p.allowed_ingress}")
    print(f"    Egress: {p.allowed_egress} | Filter: {l7}")

AI-powered Security

# === AI Security Automation ===

# Agent Workflow:
# 1. Collect traffic data from Cilium Hubble
# 2. LLM analyzes patterns and anomalies
# 3. Generate recommended policies
# 4. Human approval (or auto-apply low-risk)
# 5. Monitor and adjust

# Traffic Analysis Prompt
# """
# Analyze the following network traffic for namespace 'payment':
# - Source: checkout-pod -> payment-api:8080 (500 req/min)
# - Source: unknown-pod -> payment-api:8080 (50 req/min)
# - Source: payment-api -> payment-db:5432 (480 req/min)
# - Source: payment-api -> external:443 (100 req/min)
#
# Identify:
# 1. Normal traffic patterns
# 2. Suspicious connections
# 3. Recommended NetworkPolicy
# """

@dataclass
class SecurityEvent:
    time: str
    source: str
    destination: str
    action: str
    risk: str
    ai_decision: str

events = [
    SecurityEvent("14:23:15", "checkout", "payment-api:8080", "ALLOW", "Low", "Normal traffic"),
    SecurityEvent("14:23:45", "unknown-pod", "payment-api:8080", "ALERT", "High", "Block + investigate"),
    SecurityEvent("14:24:00", "payment-api", "payment-db:5432", "ALLOW", "Low", "Normal DB query"),
    SecurityEvent("14:24:30", "payment-api", "external:443", "ALLOW", "Medium", "Stripe API call"),
    SecurityEvent("14:25:00", "debug-pod", "payment-db:5432", "DENY", "Critical", "Unauthorized DB access"),
    SecurityEvent("14:25:30", "scanner-pod", "payment-api:22", "DENY", "Critical", "Port scan detected"),
]

print("AI Security Events:")
for e in events:
    print(f"  [{e.risk}] {e.time} | {e.source} -> {e.destination}")
    print(f"    Action: {e.action} | AI: {e.ai_decision}")

security_metrics = {
    "Policies Enforced": "28",
    "Namespaces Protected": "8",
    "Blocked Connections (24h)": "1,250",
    "AI-generated Policies": "12",
    "False Positive Rate": "2.1%",
    "Mean Time to Detect": "15 seconds",
    "Mean Time to Respond": "45 seconds",
    "Compliance Score": "96%",
}

print(f"\n\nSecurity Dashboard:")
for k, v in security_metrics.items():
    print(f"  {k}: {v}")

เคล็ดลับ

• Default Deny: เริ่มจาก Deny All แล้วค่อย Allow
• L7: ใช้ Cilium L7 Policy กรอง HTTP Method Path
• AI: ใช้ LangChain Agent วิเคราะห์ Traffic แนะนำ Policy
• Human-in-loop: AI แนะนำ แต่คนอนุมัติ High-risk Policy
• Monitor: ใช้ Hubble ดู Traffic Real-time ทุก Namespace

LangChain Agent คืออะไร

AI Agent LLM ตัดสินใจ Tool ReAct คิด-ทำ-สังเกต API Database Search GPT-4 Claude Autonomous วิเคราะห์ Network สร้าง Policy อัตโนมัติ

สรุป

LangChain Agent Micro-segmentation AI Network Security Zero Trust Cilium Calico Kubernetes NetworkPolicy GPT-4 ReAct Traffic Analysis Policy Automation Hubble
