HTTP/3 QUIC Log Management ELK

HTTP/3 QUIC ELK Stack

HTTP/3 QUIC UDP TLS 1.3 0-RTT Multiplexing ELK Stack Elasticsearch Logstash Kibana Filebeat Log Management Centralized Logging Security Monitoring

ELK Stack Setup

# === ELK Stack Docker Compose ===

# docker-compose.yml
# version: '3.8'
# services:
#   elasticsearch:
#     image: elasticsearch:8.12.0
#     environment:
#       - discovery.type=single-node
#       - xpack.security.enabled=true
#       - ELASTIC_PASSWORD=changeme
#       - "ES_JAVA_OPTS=-Xms2g -Xmx2g"
#     ports:
#       - "9200:9200"
#     volumes:
#       - es-data:/usr/share/elasticsearch/data
#     ulimits:
#       memlock: { soft: -1, hard: -1 }
#
#   logstash:
#     image: logstash:8.12.0
#     ports:
#       - "5044:5044"
#     volumes:
#       - ./logstash.conf:/usr/share/logstash/pipeline/logstash.conf
#     depends_on:
#       - elasticsearch
#
#   kibana:
#     image: kibana:8.12.0
#     environment:
#       - ELASTICSEARCH_HOSTS=http://elasticsearch:9200
#       - ELASTICSEARCH_USERNAME=kibana_system
#       - ELASTICSEARCH_PASSWORD=changeme
#     ports:
#       - "5601:5601"
#     depends_on:
#       - elasticsearch
#
# volumes:
#   es-data:

# Logstash Pipeline (logstash.conf)
# input {
#   beats { port => 5044 }
#   udp {
#     port => 5045
#     codec => json
#     tags => ["quic"]
#   }
# }
#
# filter {
#   if "nginx" in [tags] {
#     grok {
#       match => { "message" => "%{COMBINEDAPACHELOG}" }
#     }
#     geoip { source => "clientip" }
#   }
#   if "quic" in [tags] {
#     mutate {
#       add_field => { "protocol" => "HTTP/3" }
#     }
#   }
#   date {
#     match => ["timestamp", "dd/MMM/yyyy:HH:mm:ss Z"]
#   }
# }
#
# output {
#   elasticsearch {
#     hosts => ["elasticsearch:9200"]
#     index => "logs-%{+YYYY.MM.dd}"
#     user => "elastic"
#     password => "changeme"
#   }
# }

from dataclasses import dataclass
from typing import List

@dataclass
class ELKComponent:
    name: str
    role: str
    port: int
    resources: str
    use_case: str

components = [
    ELKComponent("Elasticsearch", "Store & Search", 9200, "2-4GB RAM", "Index + Query Logs"),
    ELKComponent("Logstash", "Transform", 5044, "1-2GB RAM", "Parse + Enrich Logs"),
    ELKComponent("Kibana", "Visualize", 5601, "512MB RAM", "Dashboard + Analytics"),
    ELKComponent("Filebeat", "Collect", 0, "50MB RAM", "Ship Logs from Servers"),
    ELKComponent("Metricbeat", "Metrics", 0, "50MB RAM", "System + App Metrics"),
]

print("=== ELK Stack Components ===")
for c in components:
    port = f":{c.port}" if c.port else "Agent"
    print(f"  [{c.name}] {c.role} ({port})")
    print(f"    Resources: {c.resources} | Use: {c.use_case}")

QUIC Traffic Analysis

# === QUIC Traffic Monitoring ===

# Nginx QUIC/HTTP3 Config
# server {
#     listen 443 quic reuseport;
#     listen 443 ssl;
#     http2 on;
#
#     ssl_certificate /etc/nginx/certs/cert.pem;
#     ssl_certificate_key /etc/nginx/certs/key.pem;
#     ssl_protocols TLSv1.3;
#
#     add_header Alt-Svc 'h3=":443"; ma=86400';
#
#     # QUIC Log Format
#     log_format quic '$remote_addr - $remote_user [$time_local] '
#                     '"$request" $status $body_bytes_sent '
#                     '"$http_referer" "$http_user_agent" '
#                     '$request_time $http3';
#
#     access_log /var/log/nginx/quic.log quic;
# }

# Filebeat Config (filebeat.yml)
# filebeat.inputs:
# - type: log
#   paths:
#     - /var/log/nginx/quic.log
#   tags: ["nginx", "quic"]
#   fields:
#     service: web-frontend
#
# output.logstash:
#   hosts: ["logstash:5044"]

@dataclass
class QUICMetric:
    metric: str
    value: str
    threshold: str
    status: str

metrics = [
    QUICMetric("0-RTT Success Rate", "85%", "> 80%", "OK"),
    QUICMetric("Handshake Latency", "15ms", "< 50ms", "OK"),
    QUICMetric("Packet Loss Rate", "0.3%", "< 1%", "OK"),
    QUICMetric("Connection Migration", "12/hr", "< 50/hr", "OK"),
    QUICMetric("QUIC vs TCP Ratio", "65% QUIC", "> 50%", "OK"),
    QUICMetric("Avg Response Time", "120ms", "< 200ms", "OK"),
    QUICMetric("Error Rate (4xx+5xx)", "2.1%", "< 5%", "OK"),
]

print("\n=== QUIC Monitoring Dashboard ===")
for m in metrics:
    print(f"  [{m.status}] {m.metric}: {m.value} (threshold: {m.threshold})")

Security และ Alerting

# === Security Monitoring & Alerts ===

# Elasticsearch Query — Detect Anomalies
# GET logs-*/_search
# {
#   "query": {
#     "bool": {
#       "must": [
#         {"range": {"@timestamp": {"gte": "now-1h"}}},
#         {"term": {"response": "403"}}
#       ],
#       "filter": [
#         {"term": {"protocol": "HTTP/3"}}
#       ]
#     }
#   },
#   "aggs": {
#     "by_ip": {
#       "terms": {"field": "clientip", "size": 10}
#     }
#   }
# }

# Kibana Alert Rules
# ElastWatch / Kibana Alerting
# - High Error Rate: > 5% 5xx errors in 5 min
# - DDoS Suspect: > 1000 req/min from single IP
# - Unusual QUIC: Sudden drop in QUIC traffic
# - Slow Response: P99 latency > 500ms
# - Certificate: TLS handshake failures > 10/min

alert_rules = {
    "High Error Rate": {
        "condition": "5xx > 5% in 5 min",
        "action": "Slack + PagerDuty",
        "severity": "Critical",
    },
    "DDoS Detection": {
        "condition": "> 1000 req/min single IP",
        "action": "Block IP + Alert",
        "severity": "Critical",
    },
    "QUIC Drop": {
        "condition": "QUIC traffic drops > 50%",
        "action": "Slack Alert",
        "severity": "Warning",
    },
    "Slow Response": {
        "condition": "P99 > 500ms for 10 min",
        "action": "Slack + Investigate",
        "severity": "Warning",
    },
    "TLS Failures": {
        "condition": "Handshake fail > 10/min",
        "action": "Check Certificates",
        "severity": "High",
    },
}

print("Security Alert Rules:")
for name, rule in alert_rules.items():
    print(f"\n  [{rule['severity']}] {name}")
    print(f"    Condition: {rule['condition']}")
    print(f"    Action: {rule['action']}")

เคล็ดลับ

• Index Lifecycle: ตั้ง ILM ลบ Log เก่าอัตโนมัติ ประหยัด Disk
• Filebeat: ใช้ Filebeat แทน Logstash ถ้าไม่ต้อง Transform
• Alt-Svc: ตั้ง Alt-Svc Header ให้ Browser รู้ว่ารองรับ HTTP/3
• Firewall: เปิด UDP 443 ถ้าจะใช้ QUIC/HTTP3
• Dashboard: สร้าง Kibana Dashboard สำหรับ QUIC vs TCP เปรียบเทียบ

HTTP/3 QUIC คืออะไร

HTTP เวอร์ชันล่าสุด QUIC Protocol UDP TLS 1.3 Built-in 0-RTT Multiplexing ไม่มี HOL Blocking Connection Migration เร็วกว่า HTTP/2

สรุป

HTTP/3 QUIC UDP TLS 1.3 0-RTT ELK Stack Elasticsearch Logstash Kibana Filebeat Centralized Logging QUIC Monitoring Security Alert ILM Dashboard Nginx Alt-Svc
