Flux Setup & Hexagonal Structure

# === Flux CD Bootstrap ===

# Install Flux CLI
# curl -s https://fluxcd.io/install.sh | sudo bash

# Bootstrap Flux with GitHub
# flux bootstrap github \
#   --owner=myorg \
#   --repository=fleet-infra \
#   --branch=main \
#   --path=clusters/production \
#   --personal

# Repository Structure (Hexagonal)
# fleet-infra/
# ├── clusters/           # Inbound Adapters (per cluster)
# │   ├── production/
# │   │   ├── flux-system/ (Flux components)
# │   │   └── apps.yaml   (Kustomization pointing to apps/)
# │   └── staging/
# ├── apps/               # Core Domain (Application configs)
# │   ├── base/           (shared base configs)
# │   ├── production/     (production overlays)
# │   └── staging/        (staging overlays)
# └── infrastructure/     # Outbound Adapters (infra components)
#     ├── base/           (shared: ingress, cert-manager, monitoring)
#     ├── production/
#     └── staging/

from dataclasses import dataclass

@dataclass
class HexLayer:
    layer: str
    directory: str
    contents: str
    hex_role: str

structure = [
    HexLayer("Cluster Entry",
        "clusters/{env}/",
        "Flux System + Kustomization pointers",
        "Inbound Adapter (รับ Git Changes)"),
    HexLayer("Application Core",
        "apps/base/ + apps/{env}/",
        "Deployments Services ConfigMaps Kustomize Overlays",
        "Core Domain (Business Logic)"),
    HexLayer("Infrastructure",
        "infrastructure/base/ + infrastructure/{env}/",
        "Ingress Cert-manager Monitoring Logging",
        "Outbound Adapter (Platform Services)"),
    HexLayer("Helm Releases",
        "apps/{env}/helm-releases/",
        "HelmRelease CRDs pointing to Helm Charts",
        "Port (Interface to Helm Ecosystem)"),
    HexLayer("Image Automation",
        "clusters/{env}/image-automation/",
        "ImageRepository ImagePolicy ImageUpdateAutomation",
        "Inbound Adapter (Container Registry)"),
]

print("=== Hexagonal Repository Structure ===")
for h in structure:
    print(f"  [{h.layer}] Dir: {h.directory}")
    print(f"    Contents: {h.contents}")
    print(f"    Hex Role: {h.hex_role}")

Multi-cluster Management

# === Multi-cluster with Flux ===

# Management Cluster controls Workload Clusters
# flux create secret git workload-cluster-01 \
#   --url=ssh://git@github.com/myorg/fleet-infra \
#   --namespace=flux-system

# Remote Cluster Kustomization
# apiVersion: kustomize.toolkit.fluxcd.io/v1
# kind: Kustomization
# metadata:
#   name: workload-cluster-01
#   namespace: flux-system
# spec:
#   kubeConfig:
#     secretRef:
#       name: workload-cluster-01-kubeconfig
#   sourceRef:
#     kind: GitRepository
#     name: fleet-infra
#   path: ./clusters/workload-01
#   interval: 5m

@dataclass
class ClusterConfig:
    cluster: str
    role: str
    flux_config: str
    apps: str

clusters = [
    ClusterConfig("Management Cluster",
        "Flux Controllers + Multi-cluster Management",
        "Bootstrap Flux + Remote Cluster Secrets",
        "Flux System Only (ไม่รัน App)"),
    ClusterConfig("Production Cluster",
        "Production Workloads",
        "Managed by Management Cluster Flux",
        "All Production Apps + Monitoring"),
    ClusterConfig("Staging Cluster",
        "Staging/QA Workloads",
        "Managed by Management Cluster Flux",
        "All Apps (Staging Config) + Test"),
    ClusterConfig("Dev Cluster",
        "Development Workloads",
        "Self-managed Flux (Developer Bootstrap)",
        "Feature Branch Apps + Experiments"),
]

print("=== Multi-cluster Setup ===")
for c in clusters:
    print(f"  [{c.cluster}] Role: {c.role}")
    print(f"    Flux: {c.flux_config}")
    print(f"    Apps: {c.apps}")

Monitoring & Promotion

# === GitOps Metrics & Promotion ===

@dataclass
class GitOpsMetric:
    metric: str
    source: str
    target: str
    alert: str

metrics = [
    GitOpsMetric("Reconciliation Success Rate",
        "flux_reconcile_condition{type='Ready', status='True'}",
        "> 99%",
        "< 95% → P1 Alert Check Flux Logs"),
    GitOpsMetric("Sync Duration",
        "flux_reconcile_duration_seconds",
        "P99 < 60 seconds",
        "> 120s → P2 Warning Check Git/Cluster"),
    GitOpsMetric("Git Commit to Deploy",
        "Custom metric: commit_time → deploy_time",
        "< 5 minutes (Staging) < 15 min (Prod)",
        "> 30 min → P2 Check Pipeline"),
    GitOpsMetric("Image Update Lag",
        "flux_image_automation_update_duration",
        "< 2 minutes after push",
        "> 5 min → P3 Check Image Automation"),
    GitOpsMetric("Drift Detection",
        "flux_reconcile_condition{type='Ready', status='False'}",
        "0 (No drift)",
        "Any drift → P1 Alert Investigate"),
]

print("=== GitOps Metrics ===")
for m in metrics:
    print(f"  [{m.metric}]")
    print(f"    Source: {m.source}")
    print(f"    Target: {m.target}")
    print(f"    Alert: {m.alert}")

เคล็ดลับ

• Multi-repo: แยก App Repo กับ Infra Repo สำหรับทีมใหญ่
• Kustomize: ใช้ Kustomize Overlays แยก Environment Config
• Image Automation: เปิด Image Automation ลด Manual Update
• SOPS: ใช้ SOPS Encrypt Secrets ใน Git Repository
• Weave UI: ติดตั้ง Weave GitOps UI ดู Flux Status ง่าย
