OpenTelemetry Setup

# === OpenTelemetry Python Setup ===

# pip install opentelemetry-api opentelemetry-sdk
# pip install opentelemetry-exporter-otlp
# pip install opentelemetry-instrumentation-flask
# pip install opentelemetry-instrumentation-requests

# from opentelemetry import trace
# from opentelemetry.sdk.trace import TracerProvider
# from opentelemetry.sdk.trace.export import BatchSpanProcessor
# from opentelemetry.exporter.otlp.proto.grpc.trace_exporter import OTLPSpanExporter
# from opentelemetry.sdk.resources import Resource
# from opentelemetry.instrumentation.flask import FlaskInstrumentor
# from opentelemetry.instrumentation.requests import RequestsInstrumentor
#
# # Configure resource
# resource = Resource.create({
#     "service.name": "order-service",
#     "service.version": "1.2.0",
#     "deployment.environment": "production",
# })
#
# # Configure tracer
# provider = TracerProvider(resource=resource)
# exporter = OTLPSpanExporter(endpoint="http://otel-collector:4317")
# provider.add_span_processor(BatchSpanProcessor(exporter))
# trace.set_tracer_provider(provider)
#
# # Auto-instrument
# app = Flask(__name__)
# FlaskInstrumentor().instrument_app(app)
# RequestsInstrumentor().instrument()
#
# # Custom span
# tracer = trace.get_tracer("order-service")
# with tracer.start_as_current_span("process_order") as span:
#     span.set_attribute("order.id", order_id)
#     span.set_attribute("order.total", total)
#     result = process(order)

from dataclasses import dataclass

@dataclass
class OTelComponent:
    component: str
    package: str
    purpose: str
    config: str

components = [
    OTelComponent("SDK",
        "opentelemetry-sdk",
        "Core SDK สร้าง Tracer Span",
        "TracerProvider + Resource + SpanProcessor"),
    OTelComponent("OTLP Exporter",
        "opentelemetry-exporter-otlp",
        "ส่ง Trace ไป Collector ผ่าน gRPC/HTTP",
        "endpoint: otel-collector:4317"),
    OTelComponent("Auto-instrumentation",
        "opentelemetry-instrumentation-*",
        "Auto-create Span สำหรับ Framework",
        "Flask, Django, FastAPI, requests, SQLAlchemy"),
    OTelComponent("Propagator",
        "opentelemetry-propagator-*",
        "ส่ง Context ข้าม Service ผ่าน Header",
        "W3C TraceContext (default), B3, Jaeger"),
    OTelComponent("Sampler",
        "Built-in SDK",
        "กำหนด % ที่จะเก็บ Trace",
        "TraceIdRatioBased(0.1) = เก็บ 10%"),
]

print("=== OTel Components ===")
for c in components:
    print(f"  [{c.component}] {c.package}")
    print(f"    Purpose: {c.purpose}")
    print(f"    Config: {c.config}")

Collector & Backend

# === OTel Collector Config ===

# otel-collector-config.yaml
# receivers:
#   otlp:
#     protocols:
#       grpc:
#         endpoint: 0.0.0.0:4317
#       http:
#         endpoint: 0.0.0.0:4318
#
# processors:
#   batch:
#     timeout: 5s
#     send_batch_size: 1024
#   tail_sampling:
#     decision_wait: 10s
#     policies:
#       - name: error-policy
#         type: status_code
#         status_code: { status_codes: [ERROR] }
#       - name: latency-policy
#         type: latency
#         latency: { threshold_ms: 1000 }
#       - name: probabilistic
#         type: probabilistic
#         probabilistic: { sampling_percentage: 10 }
#
# exporters:
#   otlp/tempo:
#     endpoint: tempo:4317
#     tls:
#       insecure: true
#   otlp/jaeger:
#     endpoint: jaeger:4317
#
# service:
#   pipelines:
#     traces:
#       receivers: [otlp]
#       processors: [tail_sampling, batch]
#       exporters: [otlp/tempo]

@dataclass
class CollectorPipeline:
    stage: str
    component: str
    config: str
    note: str

pipeline = [
    CollectorPipeline("Receive",
        "OTLP Receiver (gRPC + HTTP)",
        "port 4317 (gRPC), 4318 (HTTP)",
        "รับ Trace จากทุก Service"),
    CollectorPipeline("Process - Sample",
        "Tail-based Sampling",
        "เก็บ 100% Error, 100% > 1s latency, 10% ที่เหลือ",
        "ลด Storage 80-90% เก็บ Trace ที่สำคัญ"),
    CollectorPipeline("Process - Batch",
        "Batch Processor",
        "timeout: 5s, batch_size: 1024",
        "รวม Span ก่อนส่ง ลด Network call"),
    CollectorPipeline("Export",
        "OTLP Exporter → Tempo/Jaeger",
        "endpoint: tempo:4317",
        "ส่ง Trace ไป Backend เก็บและค้นหา"),
    CollectorPipeline("Store",
        "Tempo (S3) / Jaeger (ES)",
        "S3: ถูก Scale ง่าย / ES: ค้นหาดี",
        "Retention 7-30 วัน ลบอัตโนมัติ"),
]

print("=== Collector Pipeline ===")
for p in pipeline:
    print(f"  [{p.stage}] {p.component}")
    print(f"    Config: {p.config}")
    print(f"    Note: {p.note}")

Monitoring & Alerting

# === Trace-based Monitoring ===

@dataclass
class TraceMetric:
    metric: str
    source: str
    threshold: str
    alert: str

metrics = [
    TraceMetric("Request Latency p99",
        "Span duration histogram",
        "< 500ms (API), < 2s (Page Load)",
        "> 1s API → Warning, > 3s → Critical"),
    TraceMetric("Error Rate",
        "Span status = ERROR / Total spans",
        "< 1%",
        "> 1% → Warning, > 5% → Critical"),
    TraceMetric("Throughput (RPM)",
        "Root span count per minute",
        "Monitor trend ไม่ให้ drop > 20%",
        "Drop > 30% → Critical (possible outage)"),
    TraceMetric("Service Dependency",
        "Service Map from trace data",
        "ทุก Service ต้อง Healthy",
        "Dependency down → Critical"),
    TraceMetric("Trace Completeness",
        "Spans per trace vs expected",
        "ทุก Service ต้องมี Span ใน Trace",
        "Missing span → Warning (instrumentation gap)"),
]

print("=== Trace Metrics ===")
for m in metrics:
    print(f"  [{m.metric}] Source: {m.source}")
    print(f"    Threshold: {m.threshold}")
    print(f"    Alert: {m.alert}")

เคล็ดลับ

• OTel: ใช้ OpenTelemetry เป็น Standard ไม่ Lock-in Vendor
• Sampling: ใช้ Tail-based Sampling เก็บ 100% Error + Slow Trace
• Attributes: เพิ่ม Custom Attribute user_id order_id ค้นหาง่าย
• Collector: ใช้ Collector เป็น Gateway ไม่ส่งตรงจาก Service ไป Backend
• Tempo: ใช้ Grafana Tempo + S3 ถูกที่สุดสำหรับ Trace Storage

Distributed Tracing คืออะไร

ติดตาม Request ข้าม Microservices Span Trace Trace ID Context Propagation Bottleneck OpenTelemetry Jaeger Tempo Datadog APM
