Dagster Pipeline Low Code No Code

Dagster Pipeline Low Code

Dagster Data Orchestrator สร้าง Data Pipelines Python Software-defined Assets Jobs Schedules Sensors Dagit Web UI Monitor Debug Testing

Low Code No Code ใช้โค้ดน้อย Visual Interface ลาก Drop Non-developer สร้างแอปได้เร็ว Dagster Config System Launchpad Reusable Assets

Dagster Assets และ Config

# dagster_lowcode.py — Dagster Low Code Pipeline
# pip install dagster dagster-webserver dagster-pandas

import dagster
from dagster import (
    asset, AssetExecutionContext, Config,
    Definitions, MaterializeResult, MetadataValue,
    schedule, sensor, RunRequest, RunConfig,
)
from dataclasses import dataclass
import pandas as pd

# 1. Config Classes — กำหนด Parameters ผ่าน UI
class ExtractConfig(Config):
    """Config สำหรับ Extract Data"""
    source_url: str = "https://api.example.com/data"
    date_from: str = "2024-01-01"
    date_to: str = "2024-12-31"
    limit: int = 1000
    format: str = "json"

class TransformConfig(Config):
    """Config สำหรับ Transform Data"""
    drop_nulls: bool = True
    normalize: bool = True
    columns: str = "id, name, value, date"  # comma-separated
    filter_column: str = ""
    filter_value: str = ""

class LoadConfig(Config):
    """Config สำหรับ Load Data"""
    destination: str = "warehouse"  # warehouse, s3, local
    table_name: str = "processed_data"
    mode: str = "append"  # append, replace, upsert

# 2. Assets — Reusable Data Components
@asset(
    description="Extract data from source API",
    group_name="etl_pipeline",
    compute_kind="python",
)
def raw_data(context: AssetExecutionContext, config: ExtractConfig):
    """Extract Data — Non-developer กำหนด Config ผ่าน Dagit UI"""
    context.log.info(f"Extracting from {config.source_url}")
    context.log.info(f"Date range: {config.date_from} to {config.date_to}")

    # Simulate API call
    data = pd.DataFrame({
        "id": range(1, config.limit + 1),
        "name": [f"item_{i}" for i in range(1, config.limit + 1)],
        "value": [i * 10.5 for i in range(1, config.limit + 1)],
        "date": pd.date_range(config.date_from, periods=config.limit, freq="h"),
    })

    return MaterializeResult(
        metadata={
            "num_rows": MetadataValue.int(len(data)),
            "columns": MetadataValue.text(", ".join(data.columns)),
            "source": MetadataValue.text(config.source_url),
        },
    )

@asset(
    deps=["raw_data"],
    description="Transform and clean data",
    group_name="etl_pipeline",
    compute_kind="pandas",
)
def clean_data(context: AssetExecutionContext, config: TransformConfig):
    """Transform Data — Config กำหนดผ่าน UI"""
    context.log.info(f"Transform: drop_nulls={config.drop_nulls}")
    context.log.info(f"Columns: {config.columns}")

    # Simulate transform
    columns = [c.strip() for c in config.columns.split(",")]
    context.log.info(f"Processing {len(columns)} columns")

    if config.filter_column and config.filter_value:
        context.log.info(f"Filter: {config.filter_column} = {config.filter_value}")

    return MaterializeResult(
        metadata={
            "columns_used": MetadataValue.text(config.columns),
            "drop_nulls": MetadataValue.bool(config.drop_nulls),
            "normalized": MetadataValue.bool(config.normalize),
        },
    )

@asset(
    deps=["clean_data"],
    description="Load data to destination",
    group_name="etl_pipeline",
    compute_kind="database",
)
def warehouse_data(context: AssetExecutionContext, config: LoadConfig):
    """Load Data — เลือก Destination ผ่าน UI"""
    context.log.info(f"Loading to {config.destination}/{config.table_name}")
    context.log.info(f"Mode: {config.mode}")

    return MaterializeResult(
        metadata={
            "destination": MetadataValue.text(config.destination),
            "table": MetadataValue.text(config.table_name),
            "mode": MetadataValue.text(config.mode),
        },
    )

# 3. Definitions
defs = Definitions(
    assets=[raw_data, clean_data, warehouse_data],
)

print("Dagster Low Code Pipeline:")
print("  Assets: raw_data -> clean_data -> warehouse_data")
print("  Config: ExtractConfig, TransformConfig, LoadConfig")
print("  UI: Dagit Launchpad สำหรับกรอก Config")

Sensors และ Automation

# dagster_automation.py — Sensors และ Automation
from dagster import (
    sensor, SensorEvaluationContext, RunRequest,
    schedule, ScheduleEvaluationContext,
    asset_sensor, AssetKey, EventLogEntry,
)

# 1. File Sensor — ตรวจจับไฟล์ใหม่
# @sensor(
#     asset_selection=[AssetKey("raw_data")],
#     minimum_interval_seconds=60,
# )
# def new_file_sensor(context: SensorEvaluationContext):
#     """ตรวจจับไฟล์ใหม่ใน S3/Local — ทำงานอัตโนมัติ"""
#     import os
#     watch_dir = "/data/incoming"
#     last_cursor = context.cursor or ""
#
#     new_files = []
#     for f in sorted(os.listdir(watch_dir)):
#         if f > last_cursor and f.endswith(".csv"):
#             new_files.append(f)
#
#     if new_files:
#         context.update_cursor(new_files[-1])
#         for f in new_files:
#             yield RunRequest(
#                 run_key=f,
#                 run_config={
#                     "ops": {
#                         "raw_data": {
#                             "config": {
#                                 "source_url": f"/data/incoming/{f}",
#                                 "format": "csv",
#                             }
#                         }
#                     }
#                 },
#             )

# 2. Webhook Sensor — รับ Webhook จาก n8n/Zapier
# @sensor(asset_selection=[AssetKey("raw_data")])
# def webhook_sensor(context: SensorEvaluationContext):
#     """รับ Trigger จาก Low Code Tools (n8n, Zapier, Make)"""
#     import requests
#     response = requests.get("http://localhost:8000/webhooks/pending")
#     webhooks = response.json()
#
#     for webhook in webhooks:
#         yield RunRequest(
#             run_key=webhook["id"],
#             run_config=RunConfig(
#                 ops={"raw_data": ExtractConfig(
#                     source_url=webhook["source_url"],
#                     date_from=webhook["date_from"],
#                     date_to=webhook["date_to"],
#                 )}
#             ),
#         )

# 3. Schedule — รันตามเวลา
# @schedule(
#     cron_schedule="0 6 * * *",  # ทุกวัน 6:00
#     target=[AssetKey("raw_data"), AssetKey("clean_data"), AssetKey("warehouse_data")],
# )
# def daily_etl_schedule(context: ScheduleEvaluationContext):
#     """ETL รายวัน — ตั้งเวลาผ่าน UI"""
#     from datetime import datetime, timedelta
#     yesterday = (datetime.now() - timedelta(days=1)).strftime("%Y-%m-%d")
#     today = datetime.now().strftime("%Y-%m-%d")
#
#     return RunRequest(
#         run_config=RunConfig(
#             ops={"raw_data": ExtractConfig(
#                 date_from=yesterday,
#                 date_to=today,
#             )}
#         ),
#     )

# Low Code Integration Points
integrations = {
    "n8n": {
        "type": "Webhook Trigger",
        "how": "n8n Workflow -> HTTP Request -> Dagster GraphQL API",
        "use_case": "Trigger ETL เมื่อมี Event ใน n8n",
    },
    "Zapier": {
        "type": "Webhook Trigger",
        "how": "Zapier Zap -> Webhook -> Dagster Sensor",
        "use_case": "Trigger Pipeline จาก Google Sheets, Email",
    },
    "Retool": {
        "type": "Admin Dashboard",
        "how": "Retool -> Dagster GraphQL API -> View/Trigger Runs",
        "use_case": "Dashboard สำหรับ Non-developer ดู Pipeline Status",
    },
    "Appsmith": {
        "type": "Internal Tool",
        "how": "Appsmith -> REST API -> Dagster Runs",
        "use_case": "Internal Tool สำหรับจัดการ Pipeline Config",
    },
}

print("Low Code Integrations:")
for tool, info in integrations.items():
    print(f"\n  [{tool}] ({info['type']})")
    print(f"    How: {info['how']}")
    print(f"    Use Case: {info['use_case']}")

Dagster vs Airflow

# comparison.py — Dagster vs Airflow
comparison = {
    "Core Concept": {
        "Dagster": "Software-defined Assets (Data-centric)",
        "Airflow": "DAGs and Tasks (Task-centric)",
    },
    "Language": {
        "Dagster": "Python + Type hints",
        "Airflow": "Python",
    },
    "Testing": {
        "Dagster": "Built-in testing utilities ทดสอบง่าย",
        "Airflow": "ต้อง Mock มาก ทดสอบยาก",
    },
    "UI": {
        "Dagster": "Dagit — Asset Lineage, Launchpad Config",
        "Airflow": "Airflow UI — DAG Graph, Task Logs",
    },
    "Configuration": {
        "Dagster": "Config System + Dagit UI Input",
        "Airflow": "Variables + Connections + XCom",
    },
    "IO Management": {
        "Dagster": "IO Managers จัดการ Storage อัตโนมัติ",
        "Airflow": "ต้องจัดการ Storage เอง",
    },
    "Community": {
        "Dagster": "เติบโตเร็ว Modern",
        "Airflow": "ใหญ่มาก Plugin เยอะ",
    },
    "Low Code Support": {
        "Dagster": "Config UI, Launchpad, GraphQL API",
        "Airflow": "Limited — ต้องเขียน DAGs",
    },
}

print("Dagster vs Airflow:")
print(f"{'Feature':<20} {'Dagster':<35} {'Airflow':<35}")
print("-" * 90)
for feature, values in comparison.items():
    print(f"{feature:<20} {values['Dagster'][:34]:<35} {values['Airflow'][:34]:<35}")

Best Practices

• Config System: ใช้ Config Classes กำหนด Parameters ให้ Non-developer กรอกผ่าน UI
• Reusable Assets: สร้าง Assets ที่ใช้ซ้ำได้ เปลี่ยน Config ตาม Use Case
• Sensors: ใช้ Sensors ตรวจจับ Events ทำงานอัตโนมัติ
• GraphQL API: ใช้ Dagster GraphQL API เชื่อมกับ Low Code Tools
• Testing: เขียน Unit Tests สำหรับ Assets ทุกตัว
• Monitoring: ใช้ Dagit UI Monitor Pipeline Status

Dagster คืออะไร

Data Orchestrator สร้าง Data Pipelines Python Software-defined Assets Jobs Schedules Sensors Dagit Web UI Monitor Debug Testing Data Engineering MLOps

สรุป

Dagster Data Orchestrator Software-defined Assets Config System Dagit UI Low Code Non-developer กรอก Config Sensors ตรวจจับ Events อัตโนมัติ Integration n8n Zapier Retool GraphQL API Testing ง่าย Modern Developer Experience
