XRD and Composition

# === Crossplane XRD and Composition ===

# CompositeResourceDefinition (XRD)
# apiVersion: apiextensions.crossplane.io/v1
# kind: CompositeResourceDefinition
# metadata:
#   name: databases.platform.example.com
# spec:
#   group: platform.example.com
#   names:
#     kind: Database
#     plural: databases
#   claimNames:
#     kind: DatabaseClaim
#     plural: databaseclaims
#   versions:
#     - name: v1alpha1
#       served: true
#       referenceable: true
#       schema:
#         openAPIV3Schema:
#           type: object
#           properties:
#             spec:
#               type: object
#               properties:
#                 engine:
#                   type: string
#                   enum: [postgres, mysql]
#                 size:
#                   type: string
#                   enum: [small, medium, large]
#                 region:
#                   type: string
#                   default: ap-southeast-1
#               required: [engine, size]

# Composition
# apiVersion: apiextensions.crossplane.io/v1
# kind: Composition
# metadata:
#   name: database-aws
# spec:
#   compositeTypeRef:
#     apiVersion: platform.example.com/v1alpha1
#     kind: Database
#   resources:
#     - name: rds-instance
#       base:
#         apiVersion: rds.aws.upbound.io/v1beta1
#         kind: Instance
#         spec:
#           forProvider:
#             instanceClass: db.t3.micro
#             allocatedStorage: 20
#             engine: postgres
#       patches:
#         - fromFieldPath: spec.engine
#           toFieldPath: spec.forProvider.engine
#         - fromFieldPath: spec.size
#           toFieldPath: spec.forProvider.instanceClass
#           transforms:
#             - type: map
#               map:
#                 small: db.t3.micro
#                 medium: db.t3.medium
#                 large: db.r5.large

from dataclasses import dataclass

@dataclass
class PlatformAPI:
    resource: str
    inputs: str
    creates: str
    claim_lines: int
    cloud_resources: int

apis = [
    PlatformAPI("Database", "engine, size, region",
        "RDS + Security Group + Subnet Group + Secret",
        8, 4),
    PlatformAPI("Cache", "engine, size, replicas",
        "ElastiCache + Security Group + Parameter Group",
        7, 3),
    PlatformAPI("Bucket", "name, versioning, encryption",
        "S3 Bucket + Policy + Lifecycle Rule",
        6, 3),
    PlatformAPI("Network", "cidr, azs, nat_gateway",
        "VPC + Subnets + IGW + NAT + Route Tables",
        8, 8),
    PlatformAPI("Cluster", "version, node_size, node_count",
        "EKS + Node Group + IAM Roles + Add-ons",
        9, 6),
]

print("=== Platform APIs ===")
for a in apis:
    print(f"  [{a.resource}] Inputs: {a.inputs}")
    print(f"    Creates: {a.creates}")
    print(f"    Claim: {a.claim_lines} lines YAML | Cloud: {a.cloud_resources} resources")

Self-service Portal

# === Developer Self-service ===

# Developer Claim (what devs write — just 8 lines!)
# apiVersion: platform.example.com/v1alpha1
# kind: DatabaseClaim
# metadata:
#   name: my-app-db
#   namespace: team-alpha
# spec:
#   engine: postgres
#   size: medium
#   region: ap-southeast-1

# Backstage Integration
# - Backstage Software Template creates Claim YAML
# - Developer fills form in UI (no YAML needed)
# - Template commits to Git repository
# - ArgoCD detects change, applies to cluster
# - Crossplane creates all cloud resources
# - Connection details stored in Kubernetes Secret

# GitOps Workflow
# 1. Developer opens PR with Claim YAML
# 2. CI validates schema, cost estimation
# 3. Reviewer approves PR
# 4. Merge triggers ArgoCD sync
# 5. Crossplane creates resources (~2-10 minutes)
# 6. Secret with connection details created
# 7. App reads Secret, connects to database

@dataclass
class SelfServiceFlow:
    step: int
    actor: str
    action: str
    tool: str
    duration: str

flow = [
    SelfServiceFlow(1, "Developer", "Select resource type and size in portal",
        "Backstage / Port UI", "30 seconds"),
    SelfServiceFlow(2, "CI/CD", "Validate schema, estimate cost, lint",
        "GitHub Actions + OPA", "1 minute"),
    SelfServiceFlow(3, "Reviewer", "Approve PR (optional for non-prod)",
        "GitHub PR Review", "0-30 minutes"),
    SelfServiceFlow(4, "ArgoCD", "Sync Claim to Kubernetes cluster",
        "ArgoCD", "30 seconds"),
    SelfServiceFlow(5, "Crossplane", "Create cloud resources",
        "Crossplane Controller", "2-10 minutes"),
    SelfServiceFlow(6, "Crossplane", "Store connection in Secret",
        "Crossplane Connection Secret", "Automatic"),
    SelfServiceFlow(7, "Developer", "Use resource via Secret reference",
        "Kubernetes Secret Mount / Env", "Immediate"),
]

print("Self-service Flow:")
for s in flow:
    print(f"  Step {s.step}: [{s.actor}] {s.action}")
    print(f"    Tool: {s.tool} | Duration: {s.duration}")

Production Setup

# === Production Crossplane ===

# Install Crossplane
# helm repo add crossplane-stable https://charts.crossplane.io/stable
# helm install crossplane crossplane-stable/crossplane \
#   --namespace crossplane-system --create-namespace

# Install AWS Provider
# apiVersion: pkg.crossplane.io/v1
# kind: Provider
# metadata:
#   name: provider-aws
# spec:
#   package: xpkg.upbound.io/upbound/provider-family-aws:v1.0.0

# ProviderConfig with IRSA (EKS)
# apiVersion: aws.upbound.io/v1beta1
# kind: ProviderConfig
# metadata:
#   name: default
# spec:
#   credentials:
#     source: IRSA

@dataclass
class ProductionCheck:
    category: str
    item: str
    config: str
    importance: str

checks = [
    ProductionCheck("Security", "IRSA for AWS credentials",
        "No static keys, use IAM Roles for Service Accounts",
        "Critical"),
    ProductionCheck("Security", "RBAC for Claims",
        "Namespace-scoped Claims, restrict who can create what",
        "Critical"),
    ProductionCheck("Reliability", "HA Crossplane deployment",
        "replicas: 2, PDB, resource limits",
        "High"),
    ProductionCheck("Observability", "Crossplane metrics",
        "Prometheus ServiceMonitor for controller metrics",
        "High"),
    ProductionCheck("Cost", "Cost estimation in CI",
        "Infracost or custom OPA policy for cost limits",
        "Medium"),
    ProductionCheck("Governance", "OPA/Kyverno policies",
        "Enforce naming, tagging, size limits",
        "High"),
    ProductionCheck("GitOps", "ArgoCD Application per team",
        "Separate ArgoCD App per namespace/team",
        "High"),
    ProductionCheck("Backup", "XRD and Composition in Git",
        "Version control all platform definitions",
        "Critical"),
]

print("=== Production Checklist ===")
for c in checks:
    print(f"  [{c.importance}] {c.category}: {c.item}")
    print(f"    Config: {c.config}")

เคล็ดลับ

• XRD: ออกแบบ XRD Schema ให้เรียบง่าย Developer ไม่ต้องรู้ Cloud Detail
• Patch: ใช้ Transforms Map แปลงค่าจาก Enum เป็น Cloud-specific Config
• GitOps: ใช้ ArgoCD Sync Claim จาก Git ไม่ให้ kubectl apply ตรง
• RBAC: จำกัด Claim ตาม Namespace ให้แต่ละทีมเห็นเฉพาะของตัวเอง
• Cost: ใส่ Cost Estimation ใน CI ก่อน Merge PR

Crossplane คืออะไร

Open Source Cloud Infrastructure Kubernetes API CRD AWS GCP Azure Platform Team Developer Self-service Terraform GitOps ArgoCD Flux Provider

สรุป

Crossplane Composition Low Code No Code XRD Claim Self-service Platform API Kubernetes GitOps ArgoCD AWS GCP Azure Enterprise Production
