ClickHouse Analytics 12 Factor App

ClickHouse 12-Factor

ClickHouse Analytics 12-Factor App Columnar Database Config Dependencies Stateless Logging Concurrency Disposability Scale Backing Service Production

ClickHouse Setup

# === ClickHouse 12-Factor Configuration ===

# Docker Compose — ClickHouse
# version: '3.8'
# services:
#   clickhouse:
#     image: clickhouse/clickhouse-server:latest
#     ports:
#       - "8123:8123"   # HTTP
#       - "9000:9000"   # Native
#     volumes:
#       - ch_data:/var/lib/clickhouse
#       - ./config/users.xml:/etc/clickhouse-server/users.d/users.xml
#     environment:
#       - CLICKHOUSE_DB=analytics
#       - CLICKHOUSE_USER=app
#       - CLICKHOUSE_PASSWORD=
#     ulimits:
#       nofile:
#         soft: 262144
#         hard: 262144

# Factor III: Config via Environment Variables
# .env
# CH_HOST=clickhouse.example.com
# CH_PORT=9000
# CH_DB=analytics
# CH_USER=app
# CH_PASSWORD=secure-password
# CH_POOL_SIZE=10
# LOG_LEVEL=info
# APP_PORT=8080

import os
from dataclasses import dataclass

@dataclass
class AppConfig:
    ch_host: str
    ch_port: int
    ch_db: str
    ch_user: str
    ch_pool_size: int
    log_level: str
    app_port: int

    @classmethod
    def from_env(cls):
        return cls(
            ch_host=os.getenv("CH_HOST", "localhost"),
            ch_port=int(os.getenv("CH_PORT", "9000")),
            ch_db=os.getenv("CH_DB", "analytics"),
            ch_user=os.getenv("CH_USER", "default"),
            ch_pool_size=int(os.getenv("CH_POOL_SIZE", "10")),
            log_level=os.getenv("LOG_LEVEL", "info"),
            app_port=int(os.getenv("APP_PORT", "8080")),
        )

config = AppConfig.from_env()
print("=== App Config (from ENV) ===")
print(f"  ClickHouse: {config.ch_host}:{config.ch_port}/{config.ch_db}")
print(f"  Pool Size: {config.ch_pool_size}")
print(f"  Log Level: {config.log_level}")
print(f"  App Port: {config.app_port}")

# Table Design — MergeTree
# CREATE TABLE analytics.events (
#     event_id UUID DEFAULT generateUUIDv4(),
#     event_time DateTime64(3) DEFAULT now64(3),
#     event_date Date DEFAULT toDate(event_time),
#     user_id UInt64,
#     event_type LowCardinality(String),
#     page_url String,
#     referrer String DEFAULT '',
#     country LowCardinality(String) DEFAULT '',
#     device LowCardinality(String) DEFAULT '',
#     duration_ms UInt32 DEFAULT 0,
#     properties String DEFAULT '{}'
# ) ENGINE = MergeTree()
# PARTITION BY toYYYYMM(event_date)
# ORDER BY (event_type, user_id, event_time)
# TTL event_date + INTERVAL 90 DAY
# SETTINGS index_granularity = 8192;

# Materialized View — Pre-aggregation
# CREATE MATERIALIZED VIEW analytics.daily_stats
# ENGINE = SummingMergeTree()
# PARTITION BY toYYYYMM(date)
# ORDER BY (date, event_type, country)
# AS SELECT
#     toDate(event_time) AS date,
#     event_type,
#     country,
#     count() AS event_count,
#     uniqExact(user_id) AS unique_users,
#     avg(duration_ms) AS avg_duration
# FROM analytics.events
# GROUP BY date, event_type, country;

print("\n=== ClickHouse Schema ===")
print("  Table: analytics.events (MergeTree)")
print("  Partition: Monthly (toYYYYMM)")
print("  Order: event_type, user_id, event_time")
print("  TTL: 90 days")
print("  MV: daily_stats (SummingMergeTree)")

Application Layer

# === Stateless Analytics API ===

# Factor VI: Stateless Processes
# from fastapi import FastAPI
# from clickhouse_driver import Client
# import os
# import logging
#
# app = FastAPI()
# logger = logging.getLogger("analytics")
#
# def get_ch_client():
#     return Client(
#         host=os.getenv("CH_HOST"),
#         port=int(os.getenv("CH_PORT", "9000")),
#         database=os.getenv("CH_DB"),
#         user=os.getenv("CH_USER"),
#         password=os.getenv("CH_PASSWORD"),
#     )
#
# @app.get("/api/v1/stats/daily")
# async def daily_stats(date_from: str, date_to: str):
#     client = get_ch_client()
#     result = client.execute("""
#         SELECT date, event_type,
#             sum(event_count) as events,
#             sum(unique_users) as users
#         FROM analytics.daily_stats
#         WHERE date BETWEEN %(from)s AND %(to)s
#         GROUP BY date, event_type
#         ORDER BY date
#     """, {"from": date_from, "to": date_to})
#     return {"data": result}
#
# @app.post("/api/v1/events")
# async def ingest_events(events: list):
#     client = get_ch_client()
#     client.execute(
#         "INSERT INTO analytics.events (user_id, event_type, page_url) VALUES",
#         events
#     )
#     logger.info(f"Ingested {len(events)} events")  # Factor XI: Logs
#     return {"inserted": len(events)}

# Factor IX: Disposability — Graceful Shutdown
# import signal
# import sys
#
# def graceful_shutdown(signum, frame):
#     logger.info("Shutting down gracefully...")
#     # Close connections, flush buffers
#     sys.exit(0)
#
# signal.signal(signal.SIGTERM, graceful_shutdown)

# Factor VIII: Concurrency — Scale with Processes
# Dockerfile
# FROM python:3.12-slim
# WORKDIR /app
# COPY requirements.txt .
# RUN pip install --no-cache-dir -r requirements.txt
# COPY . .
# CMD ["uvicorn", "main:app", "--host", "0.0.0.0", "--port", "8080", "--workers", "4"]

# Kubernetes Deployment
# apiVersion: apps/v1
# kind: Deployment
# spec:
#   replicas: 3  # Factor VIII: Concurrency
#   template:
#     spec:
#       containers:
#         - name: analytics
#           image: analytics-api:v1.0
#           env:  # Factor III: Config
#             - name: CH_HOST
#               valueFrom:
#                 configMapKeyRef:
#                   name: analytics-config
#                   key: CH_HOST
#           livenessProbe:  # Factor IX: Disposability
#             httpGet:
#               path: /health
#               port: 8080
#           readinessProbe:
#             httpGet:
#               path: /ready
#               port: 8080

@dataclass
class FactorCheck:
    factor: str
    name: str
    implementation: str
    status: str

factors = [
    FactorCheck("I", "Codebase", "Git mono-repo GitHub", "Done"),
    FactorCheck("II", "Dependencies", "requirements.txt pip freeze", "Done"),
    FactorCheck("III", "Config", "ENV vars ConfigMap Secret", "Done"),
    FactorCheck("IV", "Backing Services", "ClickHouse Redis as ENV URL", "Done"),
    FactorCheck("V", "Build/Release/Run", "Docker CI/CD GitHub Actions", "Done"),
    FactorCheck("VI", "Processes", "Stateless FastAPI no local state", "Done"),
    FactorCheck("VII", "Port Binding", "Uvicorn self-contained port 8080", "Done"),
    FactorCheck("VIII", "Concurrency", "K8s replicas 3 workers 4", "Done"),
    FactorCheck("IX", "Disposability", "Graceful shutdown health check", "Done"),
    FactorCheck("X", "Dev/Prod Parity", "Docker Compose = K8s same images", "Done"),
    FactorCheck("XI", "Logs", "JSON stdout Loki collection", "Done"),
    FactorCheck("XII", "Admin Processes", "Management commands K8s Jobs", "Done"),
]

print("\n=== 12-Factor Checklist ===")
for f in factors:
    print(f"  [{f.status}] Factor {f.factor}: {f.name}")
    print(f"    Implementation: {f.implementation}")

Production Scaling

# === ClickHouse Cluster Scaling ===

# ClickHouse Cluster — 3 Shards 2 Replicas
#
#
#
#
#         ch-s1-r19000
#         ch-s1-r29000
#
#
#         ch-s2-r19000
#         ch-s2-r29000
#
#
#         ch-s3-r19000
#         ch-s3-r29000
#
#
#
#

# Distributed Table
# CREATE TABLE analytics.events_distributed AS analytics.events
# ENGINE = Distributed(analytics_cluster, analytics, events, rand());

@dataclass
class ScaleMetric:
    component: str
    current: str
    max_tested: str
    bottleneck: str
    action: str

scale_metrics = [
    ScaleMetric("API Pods", "3 pods", "20 pods", "CPU", "HPA auto-scale"),
    ScaleMetric("ClickHouse Shards", "3 shards", "10 shards", "Disk I/O", "Add shard"),
    ScaleMetric("ClickHouse Replicas", "2 per shard", "3 per shard", "Read load", "Add replica"),
    ScaleMetric("Ingestion Rate", "100K events/sec", "1M events/sec", "Network", "Batch + Buffer"),
    ScaleMetric("Query Latency (p99)", "120ms", "500ms", "Complex queries", "Materialized Views"),
    ScaleMetric("Storage", "2TB", "50TB", "Disk space", "TTL + Tiered Storage"),
]

print("Production Scale Metrics:")
for s in scale_metrics:
    print(f"  [{s.component}] Current: {s.current} | Max: {s.max_tested}")
    print(f"    Bottleneck: {s.bottleneck} | Action: {s.action}")

เคล็ดลับ

• ENV: ทุก Config ต้องมาจาก Environment Variables ไม่ Hardcode
• Stateless: App Layer ต้อง Stateless Scale ได้ทันที
• Batch Insert: Insert ClickHouse เป็น Batch ไม่ทีละ Row
• MV: ใช้ Materialized View สำหรับ Query ที่ใช้บ่อย
• TTL: ตั้ง TTL ลบข้อมูลเก่าอัตโนมัติ ประหยัด Disk

12-Factor App คืออะไร

หลักการ 12 ข้อ Codebase Dependencies Config Backing Services Build/Release Processes Port Binding Concurrency Disposability Parity Logs Admin

สรุป

ClickHouse Analytics 12-Factor App Config ENV Stateless Backing Service Logs Concurrency MergeTree Materialized View Sharding Replication Production Scale
