Ceph Storage Cluster Stream Processing

Ceph + Stream Processing

Ceph Storage Cluster Stream Processing RADOS RGW Object Storage Kafka Flink Spark Real-time Analytics S3 API Block CephFS Production

Cluster Setup

# === Ceph Cluster Setup ===

# Bootstrap cluster on first node
# cephadm bootstrap --mon-ip 10.0.1.10 \
#   --initial-dashboard-user admin \
#   --initial-dashboard-password secret123

# Add nodes
# ceph orch host add node2 10.0.1.11
# ceph orch host add node3 10.0.1.12

# Add OSDs (auto-detect available disks)
# ceph orch apply osd --all-available-devices

# Or add specific disks
# ceph orch daemon add osd node1:/dev/sdb
# ceph orch daemon add osd node2:/dev/sdb
# ceph orch daemon add osd node3:/dev/sdb

# Create pools
# ceph osd pool create stream-data 128 128
# ceph osd pool set stream-data size 3
# ceph osd pool set stream-data min_size 2

# Enable RGW for S3 API
# ceph orch apply rgw stream-gw --placement="3 node1 node2 node3" --port=7480

# Create S3 user
# radosgw-admin user create --uid=stream-user --display-name="Stream User"
# radosgw-admin key create --uid=stream-user --key-type=s3

from dataclasses import dataclass

@dataclass
class CephComponent:
    component: str
    count: str
    role: str
    resource: str

components = [
    CephComponent("MON (Monitor)", "3 (odd number)", "Cluster state, quorum", "2 CPU, 4GB RAM"),
    CephComponent("MGR (Manager)", "2 (active-standby)", "Dashboard, metrics, modules", "2 CPU, 4GB RAM"),
    CephComponent("OSD (Object Store)", "3+ per node", "Store actual data", "1 CPU + 4GB RAM per OSD"),
    CephComponent("RGW (RADOS Gateway)", "3 (load balanced)", "S3/Swift API endpoint", "4 CPU, 8GB RAM"),
    CephComponent("MDS (Metadata)", "2 (if CephFS)", "CephFS metadata", "4 CPU, 8GB RAM"),
]

print("=== Ceph Components ===")
for c in components:
    print(f"  [{c.component}] Count: {c.count}")
    print(f"    Role: {c.role}")
    print(f"    Resource: {c.resource}")

Stream Processing Integration

# === Kafka + Ceph Integration ===

# Kafka Connect S3 Sink (to Ceph RGW)
# connector.class=io.confluent.connect.s3.S3SinkConnector
# tasks.max=3
# topics=events, logs, metrics
# s3.bucket.name=stream-events
# s3.region=default
# store.url=http://ceph-rgw:7480
# flush.size=10000
# rotate.interval.ms=60000
# storage.class=io.confluent.connect.s3.storage.S3Storage
# format.class=io.confluent.connect.s3.format.parquet.ParquetFormat
# partitioner.class=io.confluent.connect.storage.partitioner.TimeBasedPartitioner
# path.format='year'=YYYY/'month'=MM/'day'=dd/'hour'=HH
# partition.duration.ms=3600000
# locale=en-US
# timezone=Asia/Bangkok

# Flink with Ceph S3 Checkpoint
# flink-conf.yaml:
# state.backend: rocksdb
# state.checkpoints.dir: s3://flink-checkpoints/
# s3.endpoint: http://ceph-rgw:7480
# s3.path-style-access: true
# s3.access-key: ACCESS_KEY
# s3.secret-key: SECRET_KEY

# Python — Write to Ceph via boto3
# import boto3
#
# s3 = boto3.client('s3',
#     endpoint_url='http://ceph-rgw:7480',
#     aws_access_key_id='ACCESS_KEY',
#     aws_secret_access_key='SECRET_KEY',
# )
#
# # Write event batch
# s3.put_object(
#     Bucket='stream-events',
#     Key=f'events/2024/01/15/batch-001.parquet',
#     Body=parquet_data
# )
#
# # List recent events
# response = s3.list_objects_v2(
#     Bucket='stream-events',
#     Prefix='events/2024/01/15/',
# )

@dataclass
class StreamPipeline:
    stage: str
    tool: str
    ceph_usage: str
    data_format: str
    throughput: str

pipeline = [
    StreamPipeline("Ingest", "Kafka", "RBD for broker storage", "Avro/JSON", "100K events/s"),
    StreamPipeline("Buffer", "Kafka Connect", "S3 Sink to RGW", "Parquet", "50K events/s"),
    StreamPipeline("Process", "Flink/Spark", "S3 checkpoint + state", "Internal", "30K events/s"),
    StreamPipeline("Store", "Ceph RGW", "Object storage (S3)", "Parquet/ORC", "1 GB/s write"),
    StreamPipeline("Query", "Trino/Presto", "S3 scan on RGW", "SQL over Parquet", "GB/s scan"),
    StreamPipeline("Archive", "Lifecycle Policy", "Move to erasure-coded pool", "Same", "Automated"),
]

print("\n=== Stream Pipeline ===")
for s in pipeline:
    print(f"  [{s.stage}] Tool: {s.tool}")
    print(f"    Ceph: {s.ceph_usage}")
    print(f"    Format: {s.data_format} | Throughput: {s.throughput}")

Monitoring and Operations

# === Ceph Monitoring ===

# Essential commands
# ceph status                    # Overall health
# ceph health detail             # Detailed health info
# ceph osd stat                  # OSD status
# ceph osd tree                  # OSD topology
# ceph df                        # Storage usage
# ceph osd pool stats            # Pool statistics
# rados bench -p stream-data 60 write  # Write benchmark
# rados bench -p stream-data 60 seq    # Read benchmark

# Prometheus metrics endpoint
# ceph mgr module enable prometheus
# curl http://ceph-mgr:9283/metrics

# Grafana dashboards:
# - Ceph Cluster Overview
# - Ceph OSD Performance
# - Ceph RGW Performance
# - Ceph Pool Statistics

@dataclass
class AlertRule:
    metric: str
    condition: str
    severity: str
    action: str

alerts = [
    AlertRule("ceph_health_status", "!= HEALTH_OK", "CRITICAL",
        "Check ceph health detail, fix warnings"),
    AlertRule("ceph_osd_up", "< total_osds", "CRITICAL",
        "Check failed OSD, replace disk if needed"),
    AlertRule("ceph_osd_pgs_degraded", "> 0 for 10min", "WARNING",
        "Wait for recovery or check OSD status"),
    AlertRule("ceph_pool_used_bytes", "> 80% capacity", "WARNING",
        "Add OSDs or clean old data"),
    AlertRule("ceph_rgw_req_latency", "> 500ms p99", "WARNING",
        "Check RGW load, add more instances"),
    AlertRule("ceph_osd_apply_latency_ms", "> 100ms", "WARNING",
        "Check disk health, consider SSD upgrade"),
    AlertRule("ceph_slow_requests", "> 0", "WARNING",
        "Investigate blocked operations"),
]

print("Monitoring Alerts:")
for a in alerts:
    print(f"  [{a.metric}] {a.condition}")
    print(f"    Severity: {a.severity}")
    print(f"    Action: {a.action}")

# Capacity Planning
capacity = {
    "Raw Storage": "3 nodes × 4 disks × 4TB = 48TB raw",
    "Usable (3x replication)": "48TB / 3 = 16TB usable",
    "Usable (EC 4+2)": "48TB × 4/6 = 32TB usable",
    "Daily Ingestion": "~50GB/day stream data",
    "Retention": "16TB / 50GB = ~320 days (replication)",
    "Growth Plan": "Add 1 node per quarter as needed",
}

print(f"\n\nCapacity Planning:")
for k, v in capacity.items():
    print(f"  [{k}]: {v}")

เคล็ดลับ

• Pool: ใช้ Replicated Pool สำหรับ Hot Data, Erasure Coded สำหรับ Archive
• RGW: Deploy RGW อย่างน้อย 3 ตัว Load Balance ด้วย HAProxy
• OSD: ใช้ SSD สำหรับ WAL/DB แยกจาก HDD สำหรับ Data
• Network: แยก Public Network และ Cluster Network สำหรับ Replication
• Benchmark: ทำ rados bench ก่อน Production วัด IOPS Throughput

Ceph Storage Cluster คืออะไร

Open Source Distributed Storage Object Block File Scale Commodity Hardware Self-healing CRUSH OSD MON MGR OpenStack Kubernetes Enterprise

สรุป

Ceph Storage Cluster Stream Processing RADOS RGW S3 Kafka Flink Spark Object Block CephFS Monitoring Prometheus Grafana Capacity Planning Production
