CDK Construct Event Driven Design — สร้าง

CDK Event Driven

AWS CDK Construct Event Driven Architecture EventBridge SQS Lambda Step Functions Serverless TypeScript Python Production

เนื้อหาเกี่ยวข้อง — ทำความเข้าใจ C# Minimal API Cache Strategy Redis

Pattern	AWS Services	Use Case	CDK Construct Level
Fan-out	EventBridge → Lambda × N	Notify multiple services	L3 (Pattern)
Queue Processing	SQS → Lambda	Async job processing	L2 (SqsEventSource)
Saga	Step Functions	Distributed transactions	L3 (Custom)
CQRS	API GW + DynamoDB Stream	Separate read/write	L3 (Custom)
Event Sourcing	Kinesis + DynamoDB	Audit trail, replay	L3 (Custom)
DLQ	SQS DLQ + Lambda	Failed event handling	L2 (deadLetterQueue)

CDK Constructs

# === CDK Event Driven Construct ===



# TypeScript CDK Example

# import * as cdk from 'aws-cdk-lib';

# import * as lambda from 'aws-cdk-lib/aws-lambda';

# import * as sqs from 'aws-cdk-lib/aws-sqs';

# import * as events from 'aws-cdk-lib/aws-events';

# import * as targets from 'aws-cdk-lib/aws-events-targets';

# import * as sources from 'aws-cdk-lib/aws-lambda-event-sources';

# import { Construct } from 'constructs';

#

# interface OrderProcessorProps {

#   environment: string;

#   maxConcurrency: number;

#   retryAttempts: number;

# }

#

# class OrderProcessor extends Construct {

#   public readonly queue: sqs.Queue;

#   public readonly dlq: sqs.Queue;

#   public readonly processor: lambda.Function;

#

#   constructor(scope: Construct, id: string, props: OrderProcessorProps) {

#     super(scope, id);

#

#     // Dead Letter Queue

#     this.dlq = new sqs.Queue(this, 'DLQ', {

#       retentionPeriod: cdk.Duration.days(14),

#       visibilityTimeout: cdk.Duration.seconds(300),

#     });

#

#     // Main Queue

#     this.queue = new sqs.Queue(this, 'Queue', {

#       visibilityTimeout: cdk.Duration.seconds(300),

#       deadLetterQueue: {

#         queue: this.dlq,

#         maxReceiveCount: props.retryAttempts,

#       },

#     });

#

#     // Lambda Processor

#     this.processor = new lambda.Function(this, 'Fn', {

#       runtime: lambda.Runtime.NODEJS_20_X,

#       handler: 'index.handler',

#       code: lambda.Code.fromAsset('lambda/order-processor'),

#       timeout: cdk.Duration.seconds(60),

#       memorySize: 512,

#       reservedConcurrentExecutions: props.maxConcurrency,

#       environment: { ENV: props.environment, QUEUE_URL: this.queue.queueUrl },

#     });

#

#     // Connect SQS → Lambda

#     this.processor.addEventSource(new sources.SqsEventSource(this.queue, {

#       batchSize: 10,

#       maxBatchingWindow: cdk.Duration.seconds(5),

#     }));

#

#     // EventBridge Rule → SQS

#     new events.Rule(this, 'OrderRule', {

#       eventPattern: { source: ['com.myapp.orders'], detailType: ['OrderCreated'] },

#       targets: [new targets.SqsQueue(this.queue)],

#     });

#   }

# }



from dataclasses import dataclass



@dataclass

class ConstructLevel:

    level: str

    name: str

    description: str

    example: str

    when_to_use: str



levels = [

    ConstructLevel("L1", "CFN Resources",

        "CloudFormation Resource ตรงๆ ตั้งทุก Property เอง",

        "CfnBucket, CfnFunction, CfnQueue",

        "ต้องการ Control ทุก Property ไม่มี L2 สำหรับ Service นั้น"),

    ConstructLevel("L2", "AWS Constructs",

        "Higher-level มี Default ที่ดี Grant Permission ง่าย",

        "s3.Bucket, lambda.Function, sqs.Queue",

        "ใช้บ่อยที่สุด 90% ของงาน Default ดี ปรับได้"),

    ConstructLevel("L3", "Patterns",

        "รวมหลาย L2 เข้าด้วยกัน เป็น Solution Pattern",

        "LambdaRestApi, QueueProcessingFargateService",

        "Pattern ซ้ำๆ สร้างเป็น Reusable Construct"),

]



print("=== CDK Construct Levels ===")

for l in levels:

    print(f"  [{l.level}] {l.name}")

    print(f"    Description: {l.description}")

    print(f"    Example: {l.example}")

    print(f"    When: {l.when_to_use}")

Event Patterns

# === Event Driven Patterns ===



# Fan-out with EventBridge

# const bus = new events.EventBus(this, 'AppBus');

#

# // Rule 1: Order → Inventory Lambda

# new events.Rule(this, 'InventoryRule', {

#   eventBus: bus,

#   eventPattern: { detailType: ['OrderCreated'] },

#   targets: [new targets.LambdaFunction(inventoryFn)],

# });

#

# // Rule 2: Order → Notification Lambda

# new events.Rule(this, 'NotifyRule', {

#   eventBus: bus,

#   eventPattern: { detailType: ['OrderCreated'] },

#   targets: [new targets.LambdaFunction(notifyFn)],

# });

#

# // Rule 3: Order → Analytics SQS

# new events.Rule(this, 'AnalyticsRule', {

#   eventBus: bus,

#   eventPattern: { detailType: ['OrderCreated'] },

#   targets: [new targets.SqsQueue(analyticsQueue)],

# });



@dataclass

class EventPattern:

    pattern: str

    services: str

    flow: str

    benefit: str

    cdk_construct: str



patterns = [

    EventPattern("Fan-out",

        "EventBridge → Lambda/SQS/SNS × N",

        "1 Event → หลาย Consumer พร้อมกัน",

        "Loose coupling เพิ่ม Consumer ไม่กระทบ Producer",

        "events.Rule + targets.LambdaFunction/SqsQueue"),

    EventPattern("Queue Processing",

        "SQS → Lambda (Event Source Mapping)",

        "Producer → SQS Queue → Lambda Poll → Process",

        "Buffer load spikes, Retry, DLQ, Batch processing",

        "sqs.Queue + lambda.Function + SqsEventSource"),

    EventPattern("Saga (Orchestration)",

        "Step Functions → Lambda × N",

        "Step Function ควบคุม Flow: Pay → Ship → Notify",

        "Transaction management, Compensation, Visibility",

        "stepfunctions.StateMachine + tasks.LambdaInvoke"),

    EventPattern("CQRS",

        "API GW → Lambda → DynamoDB → Stream → Lambda → Read DB",

        "Write ผ่าน Command API, Read ผ่าน Query API แยกกัน",

        "Scale Read/Write แยก Optimize แต่ละด้าน",

        "apigateway.RestApi + dynamodb.Table + DynamoEventSource"),

    EventPattern("Dead Letter Queue",

        "SQS Main Queue → DLQ after N retries",

        "Failed messages ไป DLQ → Lambda/Dashboard วิเคราะห์",

        "ไม่สูญเสีย Event ที่ Fail วิเคราะห์ Root Cause ได้",

        "sqs.Queue({ deadLetterQueue: { queue, maxReceiveCount } })"),

]



print("=== Event Patterns ===")

for p in patterns:

    print(f"  [{p.pattern}] {p.services}")

    print(f"    Flow: {p.flow}")

    print(f"    Benefit: {p.benefit}")

    print(f"    CDK: {p.cdk_construct}")

Testing

# === CDK Testing ===



# import { Template, Match } from 'aws-cdk-lib/assertions';

# import { App } from 'aws-cdk-lib';

# import { OrderProcessorStack } from '../lib/order-processor-stack';

#

# test('Queue created with DLQ', () => {

#   const app = new App();

#   const stack = new OrderProcessorStack(app, 'Test');

#   const template = Template.fromStack(stack);

#

#   template.hasResourceProperties('AWS::SQS::Queue', {

#     RedrivePolicy: Match.objectLike({

#       maxReceiveCount: 3,

#     }),

#   });

# });

#

# test('Lambda has correct timeout', () => {

#   template.hasResourceProperties('AWS::Lambda::Function', {

#     Timeout: 60,

#     MemorySize: 512,

#   });

# });

#

# test('EventBridge rule targets queue', () => {

#   template.hasResourceProperties('AWS::Events::Rule', {

#     EventPattern: Match.objectLike({

#       'detail-type': ['OrderCreated'],

#     }),

#   });

# });



@dataclass

class TestType:

    test: str

    tool: str

    what: str

    example: str



tests = [

    TestType("Snapshot Test",

        "CDK Assertions Template.fromStack",

        "ตรวจ Template ไม่เปลี่ยนจากที่คาดหวัง",

        "expect(template.toJSON()).toMatchSnapshot()"),

    TestType("Fine-grained Assertion",

        "template.hasResourceProperties",

        "ตรวจ Resource มี Property ที่ถูกต้อง",

        "hasResourceProperties('AWS::SQS::Queue', {...})"),

    TestType("Resource Count",

        "template.resourceCountIs",

        "ตรวจจำนวน Resource ที่สร้าง",

        "resourceCountIs('AWS::Lambda::Function', 3)"),

    TestType("cdk-nag",

        "cdk-nag NagPacks",

        "ตรวจ Security Compliance Best Practices",

        "Aspects.of(app).add(new AwsSolutionsChecks())"),

    TestType("Integration Test",

        "AWS SDK + deployed stack",

        "ทดสอบ Event Flow จริงบน AWS",

        "Put event → Check Lambda executed → Verify output"),

]



print("=== CDK Testing ===")

for t in tests:

    print(f"  [{t.test}] Tool: {t.tool}")

    print(f"    What: {t.what}")

    print(f"    Example: {t.example}")
