Burp Suite Pro กับ Edge Computing —
บทความ

Burp Suite Pro กับ Edge Computing —

เผยแพร่ 28 พฤษภาคม 2569

Burp Suite Pro และ Edge Computing Security

Burp Suite Pro กับ Edge Computing —

Burp Suite Pro เป็นเครื่องมือมาตรฐานอุตสาหกรรมสำหรับทดสอบความปลอดภัยเว็บแอปพลิเคชัน เมื่อนำมาใช้กับ Edge Computing Applications ต้องคำนึงถึงความเสี่ยงเฉพาะ เช่น Distributed Architecture, Multi-region Endpoints และ Edge-specific APIs

Edge Computing ประมวลผลข้อมูลใกล้ผู้ใช้ ลด Latency แต่เพิ่ม Attack Surface เพราะมีหลาย Edge Locations ที่ต้องรักษาความปลอดภัย การทดสอบด้วย Burp Suite ช่วยหาช่องโหว่ก่อนที่ Attacker จะค้นพบ

Setup Burp Suite สำหรับ Edge Testing

# === Burp Suite Pro Setup สำหรับ Edge Computing Testing ===

# 1. ติดตั้ง Burp Suite Pro
# ดาวน์โหลดจาก https://portswigger.net/burp/pro
# ต้องมี License Key

# 2. ตั้งค่า Proxy
# Burp Proxy: 127.0.0.1:8080
# Browser ตั้ง Proxy ชี้ไปที่ 127.0.0.1:8080
# ติดตั้ง Burp CA Certificate สำหรับ HTTPS Interception

# 3. ตั้งค่า Scope สำหรับ Edge Endpoints
# Target > Scope > Add
# Include:
#   *.edge.example.com
#   *.cdn.example.com
#   api.example.com/edge/*
#   *.workers.dev
#   *.cloudfunctions.net

# 4. Configure Session Handling
# Project Options > Sessions > Session Handling Rules
# Add Rule: Check Session Is Valid
# - Check response for: "401" or "token_expired"
# - If invalid: Run macro to refresh token

# 5. Edge-specific Headers
# Proxy > Options > Match and Replace
# Add rules to test different Edge behaviors:
#   Add Header: X-Forwarded-For: 203.0.113.1
#   Add Header: CF-Connecting-IP: 203.0.113.1
#   Add Header: X-Real-IP: 203.0.113.1
#   Add Header: X-Edge-Location: ap-southeast-1

# 6. Configure for HTTP/2
# Project Options > HTTP > HTTP/2
# Enable HTTP/2 for target hosts

# 7. Import OpenAPI Spec
# Target > Site Map > Right-click > Import > OpenAPI
# Upload edge-api-spec.yaml
# This maps all API endpoints automatically

# 8. Extension: Edge Security Scanner (Python)
# Extender > Extensions > Add
# Type: Python
# File: edge_scanner.py (see below)

Python Extension สำหรับ Burp Suite

Burp Suite Pro กับ Edge Computing —
# edge_scanner.py — Burp Suite Extension สำหรับ Edge Security
# ใช้กับ Burp Extender API (Jython/Python)

from burp import IBurpExtender, IScannerCheck, IScanIssue
from java.net import URL
import re
import json

class BurpExtender(IBurpExtender, IScannerCheck):
    """Burp Extension ตรวจสอบ Edge Computing Vulnerabilities"""

    def registerExtenderCallbacks(self, callbacks):
        self._callbacks = callbacks
        self._helpers = callbacks.getHelpers()
        callbacks.setExtensionName("Edge Security Scanner")
        callbacks.registerScannerCheck(self)
        print("[*] Edge Security Scanner loaded")

    def doPassiveScan(self, baseRequestResponse):
        """Passive Scan — ตรวจสอบ Response Headers"""
        issues = []
        response = baseRequestResponse.getResponse()
        if response is None:
            return None

        analyzedResponse = self._helpers.analyzeResponse(response)
        headers = analyzedResponse.getHeaders()

        # Check 1: Edge Cache Headers
        cache_issues = self._check_cache_headers(headers,
                                                  baseRequestResponse)
        issues.extend(cache_issues)

        # Check 2: Security Headers
        security_issues = self._check_security_headers(headers,
                                                        baseRequestResponse)
        issues.extend(security_issues)

        # Check 3: Edge Location Disclosure
        location_issues = self._check_edge_location(headers,
                                                     baseRequestResponse)
        issues.extend(location_issues)

        return issues if issues else None

    def _check_cache_headers(self, headers, reqResp):
        """ตรวจสอบ Cache Headers ที่อาจ Cache ข้อมูลสำคัญ"""
        issues = []
        header_str = "\n".join(headers).lower()

        # ตรวจสอบว่า Response ที่มีข้อมูลส่วนตัวถูก Cache
        body = self._helpers.bytesToString(reqResp.getResponse())

        sensitive_patterns = [
            r'"email"\s*:', r'"password"\s*:', r'"token"\s*:',
            r'"api_key"\s*:', r'"secret"\s*:',
        ]

        has_sensitive = any(re.search(p, body) for p in sensitive_patterns)
        is_cached = "cache-control: public" in header_str or \
                    "x-cache: hit" in header_str

        if has_sensitive and is_cached:
            issues.append(CustomScanIssue(
                reqResp.getHttpService(),
                self._helpers.analyzeRequest(reqResp).getUrl(),
                [reqResp],
                "Edge Cache Stores Sensitive Data",
                "Response containing sensitive data is being cached "
                "at the Edge. This could expose user data to other users.",
                "High",
            ))

        return issues

    def _check_security_headers(self, headers, reqResp):
        """ตรวจสอบ Security Headers ที่ขาดหาย"""
        issues = []
        header_str = "\n".join(headers).lower()

        required_headers = {
            "strict-transport-security": "HSTS",
            "x-content-type-options": "X-Content-Type-Options",
            "x-frame-options": "X-Frame-Options",
            "content-security-policy": "CSP",
        }

        missing = []
        for header, name in required_headers.items():
            if header not in header_str:
                missing.append(name)

        if missing:
            issues.append(CustomScanIssue(
                reqResp.getHttpService(),
                self._helpers.analyzeRequest(reqResp).getUrl(),
                [reqResp],
                "Missing Security Headers at Edge",
                "Missing headers: " + ", ".join(missing),
                "Medium",
            ))

        return issues

    def _check_edge_location(self, headers, reqResp):
        """ตรวจสอบ Edge Location Information Disclosure"""
        issues = []
        edge_headers = [
            "x-served-by", "x-cache", "cf-ray", "x-amz-cf-id",
            "x-edge-location", "server-timing",
        ]

        disclosed = []
        for h in headers:
            for eh in edge_headers:
                if h.lower().startswith(eh):
                    disclosed.append(h)

        if len(disclosed) > 3:
            issues.append(CustomScanIssue(
                reqResp.getHttpService(),
                self._helpers.analyzeRequest(reqResp).getUrl(),
                [reqResp],
                "Edge Infrastructure Information Disclosure",
                "Multiple edge headers expose infrastructure details: "
                + ", ".join(disclosed[:5]),
                "Low",
            ))

        return issues

    def doActiveScan(self, baseRequestResponse, insertionPoint):
        return None

    def consolidateDuplicateIssues(self, existingIssue, newIssue):
        if existingIssue.getIssueName() == newIssue.getIssueName():
            return -1
        return 0

class CustomScanIssue(IScanIssue):
    """Custom Scan Issue"""
    def __init__(self, httpService, url, reqResps, name, detail, severity):
        self._httpService = httpService
        self._url = url
        self._reqResps = reqResps
        self._name = name
        self._detail = detail
        self._severity = severity

    def getUrl(self): return self._url
    def getIssueName(self): return self._name
    def getIssueType(self): return 0
    def getSeverity(self): return self._severity
    def getConfidence(self): return "Certain"
    def getIssueBackground(self): return None
    def getRemediationBackground(self): return None
    def getIssueDetail(self): return self._detail
    def getRemediationDetail(self): return None
    def getHttpMessages(self): return self._reqResps
    def getHttpService(self): return self._httpService

Automated Edge Security Testing

# edge_security_test.py — Automated Security Testing สำหรับ Edge APIs
import requests
import json
from urllib.parse import urljoin

class EdgeSecurityTester:
    """ทดสอบ Security ของ Edge APIs"""

    def __init__(self, base_url, auth_token=None):
        self.base_url = base_url
        self.session = requests.Session()
        if auth_token:
            self.session.headers["Authorization"] = f"Bearer {auth_token}"
        self.results = []

    def test_cors(self, endpoint="/api/data"):
        """ทดสอบ CORS Misconfiguration"""
        url = urljoin(self.base_url, endpoint)
        evil_origins = [
            "https://evil.com",
            "https://attacker.example.com",
            "null",
        ]

        for origin in evil_origins:
            resp = self.session.get(url, headers={"Origin": origin})
            acao = resp.headers.get("Access-Control-Allow-Origin", "")

            if acao == origin or acao == "*":
                self.results.append({
                    "test": "CORS", "severity": "HIGH",
                    "detail": f"Reflects origin: {origin} -> {acao}",
                })
                print(f"  [HIGH] CORS reflects: {origin}")

    def test_cache_poisoning(self, endpoint="/"):
        """ทดสอบ Cache Poisoning"""
        url = urljoin(self.base_url, endpoint)
        payloads = [
            {"X-Forwarded-Host": "evil.com"},
            {"X-Original-URL": "/admin"},
            {"X-Rewrite-URL": "/admin"},
        ]

        for headers in payloads:
            resp = self.session.get(url, headers=headers)
            body = resp.text.lower()

            for key, value in headers.items():
                if value.lower() in body:
                    self.results.append({
                        "test": "Cache Poisoning", "severity": "HIGH",
                        "detail": f"Header {key}:{value} reflected in response",
                    })
                    print(f"  [HIGH] Cache Poisoning via {key}")

    def test_rate_limiting(self, endpoint="/api/login", requests_count=100):
        """ทดสอบ Rate Limiting"""
        url = urljoin(self.base_url, endpoint)
        blocked = False

        for i in range(requests_count):
            resp = self.session.post(url, json={
                "username": "test", "password": "wrong"
            })
            if resp.status_code == 429:
                blocked = True
                print(f"  [INFO] Rate limited at request {i+1}")
                break

        if not blocked:
            self.results.append({
                "test": "Rate Limiting", "severity": "MEDIUM",
                "detail": f"No rate limiting after {requests_count} requests",
            })
            print(f"  [MEDIUM] No rate limiting detected")

    def test_edge_bypass(self, endpoint="/admin"):
        """ทดสอบ Edge WAF/ACL Bypass"""
        url = urljoin(self.base_url, endpoint)
        bypass_techniques = [
            {"path": endpoint, "headers": {}},
            {"path": endpoint.upper(), "headers": {}},
            {"path": f"{endpoint}/.", "headers": {}},
            {"path": f"{endpoint}%2f", "headers": {}},
            {"path": endpoint, "headers": {"X-Original-URL": endpoint}},
            {"path": endpoint, "headers": {"X-Forwarded-For": "127.0.0.1"}},
        ]

        for technique in bypass_techniques:
            test_url = urljoin(self.base_url, technique["path"])
            resp = self.session.get(test_url, headers=technique["headers"],
                                   allow_redirects=False)
            if resp.status_code == 200:
                self.results.append({
                    "test": "Edge Bypass", "severity": "HIGH",
                    "detail": f"Bypass: path={technique['path']} "
                              f"headers={technique['headers']}",
                })

    def print_report(self):
        """แสดงรายงาน"""
        print(f"\n{'='*50}")
        print(f"Edge Security Test Report")
        print(f"Target: {self.base_url}")
        print(f"{'='*50}")

        high = [r for r in self.results if r["severity"] == "HIGH"]
        med = [r for r in self.results if r["severity"] == "MEDIUM"]

        print(f"\nFindings: {len(self.results)} "
              f"(High: {len(high)}, Medium: {len(med)})")

        for r in self.results:
            print(f"\n  [{r['severity']}] {r['test']}")
            print(f"    {r['detail']}")

# ตัวอย่าง
# tester = EdgeSecurityTester("https://edge.example.com", "token123")
# tester.test_cors()
# tester.test_cache_poisoning()
# tester.test_rate_limiting()
# tester.test_edge_bypass()
# tester.print_report()

Edge Security Checklist

  • HTTPS Everywhere: บังคับ HTTPS ทุก Edge Location ใช้ HSTS Header
  • Authentication: ใช้ JWT หรือ mTLS สำหรับ Edge-to-Origin Authentication ตรวจสอบ Token ทุก Edge Node
  • Cache Control: ไม่ Cache Response ที่มีข้อมูลส่วนตัว ใช้ Cache-Control: private สำหรับ User-specific Data
  • Rate Limiting: ตั้ง Rate Limit ทั้งที่ Edge และ Origin ป้องกัน DDoS และ Brute Force
  • WAF Rules: ตั้ง WAF Rules ที่ Edge ป้องกัน OWASP Top 10
  • Input Validation: Validate Input ทั้งที่ Edge และ Origin อย่าพึ่ง Edge เพียงอย่างเดียว
  • Logging: เก็บ Log จากทุก Edge Location รวมศูนย์สำหรับ SIEM Analysis

Burp Suite Pro คืออะไร

เครื่องมือทดสอบความปลอดภัยเว็บแอปพลิเคชันชั้นนำ มี Proxy, Scanner, Intruder, Repeater ใช้หาช่องโหว่ SQL Injection, XSS, CSRF, Authentication Bypass และ API Vulnerabilities
